SDO HMI 2011-06-01 05:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.87 | 184.00 | 25.36 | 127.34 | -20.25 | 19.74 | -40.67 | 118.92 | 0.7006 | 288.5 | 328.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-01 05:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.81 | 0.00 | 0.54 | -19.55 | 22.83 | -37.58 | 119.54 | 0.6628 | -701.0 | -566.1 | |
| 0.00 | 1.45 | 0.00 | 0.94 | -17.95 | 23.25 | -37.16 | 117.50 | 0.6501 | -798.0 | -591.1 | |
| 0.00 | 0.63 | 0.00 | 0.42 | -19.19 | 22.89 | -37.52 | 119.08 | 0.6604 | -695.0 | -580.7 | |
| 0.00 | 0.99 | 0.00 | 0.65 | -18.90 | 22.80 | -37.61 | 118.62 | 0.6600 | -652.0 | -535.3 | |
| 5.33 | 7.41 | 3.53 | 4.90 | -19.00 | 22.41 | -38.00 | 118.54 | 0.6650 | -653.7 | -466.0 | |
| 0.00 | 0.45 | 0.00 | 0.30 | -19.35 | 22.31 | -38.10 | 118.99 | 0.6678 | -497.0 | -384.6 | |
| 0.00 | 1.36 | 0.00 | 0.88 | -16.83 | 22.71 | -37.70 | 115.61 | 0.6513 | -311.0 | -296.7 | |
| 0.00 | 2.62 | 0.00 | 1.73 | -18.00 | 22.26 | -38.15 | 117.07 | 0.6620 | -470.0 | -364.9 | |
| 4.16 | 5.42 | 2.78 | 3.62 | -18.61 | 21.57 | -38.84 | 117.57 | 0.6728 | -639.1 | -513.3 | |
| 22.14 | 156.80 | 15.36 | 108.97 | -20.36 | 19.66 | -40.75 | 119.02 | 0.7021 | 1046.8 | 412.8 | |
| 2.80 | -10.00 | 1.97 | -10.00 | -20.75 | 19.06 | -41.35 | 119.25 | 0.7104 | 706.5 | 999999 | |
| 2.44 | -10.00 | 1.72 | -10.00 | -20.81 | 18.73 | -41.68 | 119.17 | 0.7141 | 591.8 | 999999 | |
| 0.00 | 0.72 | 0.00 | 0.51 | -19.74 | 18.65 | -41.76 | 117.73 | 0.7105 | 462.0 | 390.9 | |
| 0.00 | 1.27 | 0.00 | 0.92 | -22.14 | 17.45 | -42.95 | 120.30 | 0.7333 | 496.0 | 337.4 | |
| 0.00 | 1.27 | 0.00 | 0.90 | -20.39 | 18.00 | -42.41 | 118.28 | 0.7202 | 538.0 | 404.4 | |
| 0.00 | 1.90 | 0.00 | 1.35 | -20.03 | 18.03 | -42.38 | 117.83 | 0.7183 | -321.0 | -352.2 | |
| 0.00 | 0.90 | 0.00 | 0.71 | -22.37 | 13.39 | -47.02 | 118.88 | 0.7748 | -678.0 | -626.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
