SDO HMI 2011-06-01 16:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.10 | 196.32 | 25.66 | 126.00 | -20.57 | 19.27 | -35.09 | 122.50 | 0.6402 | 589.8 | 387.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-01 16:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.08 | 0.00 | 0.65 | -18.15 | 24.77 | -29.59 | 122.78 | 0.5602 | 563.0 | 433.2 | |
| 2.89 | 3.16 | 1.78 | 1.95 | -19.29 | 22.25 | -32.11 | 122.64 | 0.5979 | -750.4 | -676.7 | |
| 0.00 | 1.26 | 0.00 | 0.78 | -19.74 | 22.00 | -32.36 | 123.13 | 0.6038 | -579.0 | -480.9 | |
| 1.72 | 2.26 | 1.06 | 1.40 | -18.67 | 21.59 | -32.77 | 121.26 | 0.6021 | -656.4 | -429.0 | |
| 23.66 | 170.26 | 15.15 | 109.06 | -20.40 | 19.58 | -34.78 | 122.45 | 0.6358 | 1093.0 | 416.0 | |
| 0.00 | 1.35 | 0.00 | 0.88 | -21.73 | 19.06 | -35.30 | 123.98 | 0.6496 | 692.0 | 474.7 | |
| 0.00 | 1.35 | 0.00 | 0.89 | -22.32 | 18.73 | -35.63 | 124.57 | 0.6567 | -598.0 | -458.5 | |
| 0.45 | -5.00 | 0.29 | -5.00 | -20.53 | 19.11 | -35.25 | 122.33 | 0.6419 | 718.0 | 999999 | |
| 2.53 | 3.79 | 1.64 | 2.47 | -21.27 | 18.83 | -35.53 | 123.19 | 0.6494 | 584.1 | 429.8 | |
| 6.86 | -5.00 | 4.45 | -5.00 | -20.79 | 18.84 | -35.52 | 122.52 | 0.6464 | 767.9 | 999999 | |
| 1.99 | -5.00 | 1.29 | -5.00 | -20.91 | 18.44 | -35.91 | 122.45 | 0.6516 | 547.1 | 999999 | |
| 0.00 | 1.17 | 0.00 | 0.77 | -20.59 | 18.13 | -36.23 | 121.81 | 0.6533 | 415.0 | 295.5 | |
| 0.00 | 0.90 | 0.00 | 0.59 | -20.88 | 17.85 | -36.51 | 122.04 | 0.6581 | 489.0 | 404.6 | |
| 0.00 | 0.63 | 0.00 | 0.42 | -22.18 | 17.26 | -37.10 | 123.46 | 0.6719 | 530.0 | 407.6 | |
| 0.00 | 3.07 | 0.00 | 2.04 | -21.92 | 17.26 | -37.10 | 123.11 | 0.6704 | 806.0 | 532.5 | |
| 0.00 | 0.99 | 0.00 | 0.66 | -20.78 | 16.98 | -37.38 | 121.39 | 0.6672 | -582.0 | -476.4 | |
| 0.00 | 4.06 | 0.00 | 2.74 | -22.21 | 16.42 | -37.94 | 123.01 | 0.6811 | 633.0 | 490.3 | |
| 0.00 | 0.99 | 0.00 | 0.70 | -22.45 | 13.13 | -41.23 | 121.55 | 0.7171 | -692.0 | -627.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
