SDO HMI 2011-06-03 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.12 | 158.70 | 15.76 | 86.09 | -20.86 | 18.67 | -13.08 | 148.96 | 0.4104 | 619.8 | 383.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-03 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.68 | 134.00 | 13.35 | 72.43 | -20.66 | 19.22 | -12.53 | 149.62 | 0.4030 | 1262.9 | 442.6 | |
| 1.18 | -1.00 | 0.64 | -1.00 | -20.89 | 18.74 | -13.01 | 148.99 | 0.4100 | 777.0 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -22.00 | 18.47 | -13.28 | 149.93 | 0.4270 | 755.0 | 572.6 | |
| 3.26 | 4.79 | 1.77 | 2.61 | -21.08 | 18.52 | -13.23 | 148.84 | 0.4144 | 806.6 | 218.1 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -21.18 | 18.34 | -13.41 | 148.64 | 0.4172 | 712.0 | 597.4 | |
| 0.00 | 1.18 | 0.00 | 0.64 | -22.00 | 18.10 | -13.65 | 149.26 | 0.4300 | 691.0 | 600.1 | |
| 0.00 | 1.81 | 0.00 | 0.99 | -21.70 | 18.09 | -13.66 | 148.87 | 0.4261 | 813.0 | 684.8 | |
| 0.00 | 1.18 | 0.00 | 0.64 | -20.92 | 17.73 | -14.02 | 147.15 | 0.4189 | 714.0 | 565.6 | |
| 0.00 | 4.43 | 0.00 | 2.42 | -21.41 | 17.65 | -14.10 | 147.67 | 0.4260 | 743.0 | 743.2 | |
| 0.00 | 1.09 | 0.00 | 0.62 | -23.17 | 12.80 | -18.95 | 142.37 | 0.4909 | -883.0 | -749.1 | |
| 0.00 | 0.90 | 0.00 | 0.51 | -22.35 | 12.43 | -19.32 | 140.71 | 0.4851 | -793.0 | -591.9 | |
| 0.00 | 2.08 | 0.00 | 1.18 | -23.17 | 12.31 | -19.44 | 141.68 | 0.4954 | -702.0 | -544.8 | |
| 0.00 | 0.99 | 0.00 | 0.56 | -22.15 | 12.43 | -19.32 | 140.42 | 0.4829 | -846.0 | -700.1 | |
| 0.00 | 0.72 | 0.00 | 0.41 | -23.50 | 12.01 | -19.74 | 141.73 | 0.5019 | -698.0 | -602.6 | |
| 0.00 | 1.90 | 0.00 | 1.08 | -22.05 | 11.88 | -19.87 | 139.52 | 0.4872 | -794.0 | -598.0 | |
| 0.00 | 1.09 | 0.00 | 0.62 | -22.74 | 10.33 | -21.42 | 138.47 | 0.5100 | -671.0 | -621.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
