SDO HMI 2011-06-03 23:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.60 | 154.22 | 12.51 | 81.94 | -20.92 | 18.80 | -5.21 | 166.55 | 0.3632 | 730.5 | 463.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-03 23:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.80 | 0.00 | 1.49 | -21.20 | 20.91 | -3.10 | 171.93 | 0.3608 | -752.0 | -613.0 | |
| 23.60 | 121.42 | 12.51 | 64.34 | -20.65 | 19.22 | -4.79 | 167.31 | 0.3569 | 1314.9 | 486.2 | |
| 0.00 | 1.72 | 0.00 | 0.91 | -20.98 | 18.62 | -5.38 | 166.02 | 0.3643 | 915.0 | 717.7 | |
| 0.00 | 1.36 | 0.00 | 0.72 | -21.24 | 18.52 | -5.49 | 165.94 | 0.3688 | 843.0 | 740.5 | |
| 0.00 | 1.18 | 0.00 | 0.63 | -22.31 | 18.48 | -5.53 | 166.58 | 0.3859 | 539.0 | 464.3 | |
| 0.00 | 0.45 | 0.00 | 0.24 | -21.95 | 18.19 | -5.82 | 165.67 | 0.3814 | 641.0 | 548.2 | |
| 0.00 | 5.15 | 0.00 | 2.76 | -21.76 | 18.07 | -5.94 | 165.24 | 0.3788 | 665.0 | 758.1 | |
| 0.00 | 2.89 | 0.00 | 1.54 | -21.40 | 17.99 | -6.02 | 164.77 | 0.3736 | 923.0 | 761.1 | |
| 0.00 | 1.99 | 0.00 | 1.07 | -21.89 | 17.83 | -6.18 | 164.78 | 0.3818 | 607.0 | 600.6 | |
| 0.00 | 3.07 | 0.00 | 1.64 | -21.59 | 17.81 | -6.20 | 164.51 | 0.3774 | 952.0 | 762.8 | |
| 0.00 | 5.15 | 0.00 | 2.76 | -21.72 | 17.54 | -6.46 | 163.98 | 0.3806 | 870.0 | 744.2 | |
| 0.00 | 1.08 | 0.00 | 0.58 | -22.22 | 17.49 | -6.52 | 164.23 | 0.3884 | 729.0 | 575.2 | |
| 0.00 | 1.08 | 0.00 | 0.59 | -24.50 | 16.09 | -7.91 | 162.96 | 0.4294 | 487.0 | 437.8 | |
| 0.00 | 1.08 | 0.00 | 0.59 | -22.47 | 12.68 | -11.33 | 154.25 | 0.4197 | -769.0 | -676.2 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -23.33 | 12.50 | -11.51 | 154.86 | 0.4329 | -800.0 | -537.6 | |
| 0.00 | 0.81 | 0.00 | 0.44 | -22.05 | 12.01 | -12.00 | 152.46 | 0.4185 | -788.0 | -605.1 | |
| 0.00 | 1.72 | 0.00 | 0.95 | -23.66 | 11.69 | -12.32 | 153.72 | 0.4430 | -684.0 | -503.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
