SDO HMI 2011-06-04 05:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 68.20 | 428.96 | 37.59 | 236.70 | -21.97 | 35.43 | 14.73 | 212.59 | 0.4414 | 133.0 | 113.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-04 05:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16.46 | 77.52 | 9.07 | 42.72 | -19.33 | 38.79 | 18.08 | 221.93 | 0.4401 | 1228.8 | 500.5 | |
| 0.00 | 1.45 | 0.00 | 0.82 | -23.18 | 38.90 | 18.20 | 216.44 | 0.4852 | 784.0 | 675.1 | |
| 1.45 | 4.79 | 0.82 | 2.73 | -23.71 | 38.87 | 18.17 | 215.70 | 0.4912 | 857.8 | 594.8 | |
| 0.00 | 1.27 | 0.00 | 0.72 | -23.48 | 38.77 | 18.06 | 215.86 | 0.4875 | 720.0 | 716.1 | |
| 0.00 | 1.18 | 0.00 | 0.66 | -23.21 | 38.70 | 17.99 | 216.10 | 0.4837 | 820.0 | 678.8 | |
| 0.00 | 1.27 | 0.00 | 0.72 | -23.81 | 38.64 | 17.94 | 215.24 | 0.4903 | 680.0 | 555.1 | |
| 0.00 | 1.54 | 0.00 | 0.87 | -23.54 | 38.36 | 17.66 | 215.17 | 0.4847 | 943.0 | 836.0 | |
| 0.00 | 7.42 | 0.00 | 4.20 | -23.78 | 38.36 | 17.65 | 214.87 | 0.4874 | 866.0 | 806.7 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -23.35 | 38.23 | 17.52 | 215.23 | 0.4811 | 794.0 | 726.0 | |
| 0.00 | 0.72 | 0.00 | 0.40 | -19.82 | 37.25 | 16.55 | 218.73 | 0.4300 | 695.0 | 572.4 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -23.64 | 37.65 | 16.94 | 213.97 | 0.4796 | 752.0 | 689.8 | |
| 0.00 | 0.99 | 0.00 | 0.54 | -19.69 | 37.04 | 16.33 | 218.58 | 0.4263 | 784.0 | 675.1 | |
| 0.00 | 1.54 | 0.00 | 0.84 | -19.85 | 36.95 | 16.25 | 218.19 | 0.4274 | 898.0 | 755.9 | |
| 2.71 | 3.35 | 1.48 | 1.83 | -19.50 | 36.82 | 16.11 | 218.51 | 0.4218 | 991.5 | 867.9 | |
| 0.00 | 0.81 | 0.00 | 0.45 | -20.86 | 36.83 | 16.12 | 216.47 | 0.4383 | 611.0 | 529.4 | |
| 0.00 | 7.33 | 0.00 | 4.01 | -19.95 | 36.56 | 15.85 | 217.38 | 0.4248 | 430.0 | 748.7 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -20.24 | 36.56 | 15.85 | 216.93 | 0.4283 | 779.0 | 600.9 | |
| 0.00 | 1.09 | 0.00 | 0.59 | -20.17 | 36.21 | 15.51 | 216.44 | 0.4242 | 793.0 | 680.7 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -19.82 | 36.08 | 15.37 | 216.74 | 0.4186 | 786.0 | 680.0 | |
| 0.00 | 0.72 | 0.00 | 0.39 | -19.63 | 35.99 | 15.28 | 216.89 | 0.4154 | 763.0 | 654.6 | |
| 7.06 | 23.25 | 3.86 | 12.73 | -20.73 | 35.63 | 14.92 | 214.62 | 0.4257 | 1061.3 | 372.1 | |
| 4.25 | -21.00 | 2.33 | -21.00 | -20.99 | 35.56 | 14.85 | 214.12 | 0.4283 | 923.6 | 999999 | |
| 0.00 | 2.26 | 0.00 | 1.27 | -23.91 | 35.64 | 14.93 | 210.47 | 0.4665 | 656.0 | 518.0 | |
| 0.00 | 1.27 | 0.00 | 0.71 | -24.31 | 35.69 | 14.98 | 210.07 | 0.4720 | -673.0 | -539.5 | |
| 0.00 | 0.63 | 0.00 | 0.35 | -21.18 | 35.27 | 14.56 | 213.35 | 0.4283 | 775.0 | 678.3 | |
| 0.00 | 1.90 | 0.00 | 1.07 | -24.31 | 35.48 | 14.77 | 209.74 | 0.4704 | -805.0 | -528.0 | |
| 0.00 | 0.81 | 0.00 | 0.45 | -21.61 | 35.04 | 14.34 | 212.37 | 0.4318 | 495.0 | 436.1 | |
| 1.09 | 108.45 | 0.60 | 59.67 | -22.13 | 35.06 | 14.36 | 211.71 | 0.4388 | 451.7 | 356.4 | |
| 0.90 | -28.00 | 0.50 | -28.00 | -21.93 | 34.98 | 14.27 | 211.82 | 0.4355 | 717.1 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.81 | -24.28 | 35.10 | 14.39 | 209.14 | 0.4670 | -121.0 | -154.6 | |
| 4.07 | -28.00 | 2.24 | -28.00 | -22.06 | 34.75 | 14.05 | 211.25 | 0.4354 | 1046.1 | 999999 | |
| 0.00 | 2.53 | 0.00 | 1.41 | -24.08 | 34.94 | 14.23 | 209.11 | 0.4632 | -409.0 | -359.1 | |
| 0.00 | 0.81 | 0.00 | 0.44 | -19.66 | 34.46 | 13.75 | 214.04 | 0.4016 | -740.0 | -685.3 | |
| 0.00 | 1.36 | 0.00 | 0.76 | -25.11 | 34.99 | 14.28 | 208.03 | 0.4772 | -749.0 | -548.2 | |
| 3.71 | -28.00 | 2.04 | -28.00 | -22.29 | 34.57 | 13.87 | 210.64 | 0.4369 | 957.4 | 999999 | |
| 6.60 | -28.00 | 3.62 | -28.00 | -21.84 | 34.53 | 13.82 | 211.14 | 0.4305 | 945.5 | 999999 | |
| 0.99 | 92.44 | 0.55 | 51.40 | -23.98 | 34.72 | 14.01 | 208.86 | 0.4603 | -598.7 | -150.8 | |
| 0.00 | 1.18 | 0.00 | 0.65 | -23.18 | 34.53 | 13.82 | 209.47 | 0.4483 | 615.0 | 376.9 | |
| 1.81 | -37.00 | 1.00 | -37.00 | -23.55 | 34.40 | 13.69 | 208.81 | 0.4521 | -817.0 | 999999 | |
| 13.57 | -37.00 | 7.55 | -37.00 | -23.98 | 34.38 | 13.67 | 208.27 | 0.4577 | -1066.9 | 999999 | |
| 0.45 | -37.00 | 0.25 | -37.00 | -23.75 | 34.35 | 13.64 | 208.49 | 0.4544 | -992.6 | 999999 | |
| 0.00 | 2.35 | 0.00 | 1.27 | -19.98 | 33.99 | 13.28 | 212.67 | 0.4016 | -902.0 | -724.6 | |
| 0.00 | 1.45 | 0.00 | 0.79 | -21.05 | 33.71 | 13.01 | 210.67 | 0.4135 | -977.0 | -832.2 | |
| 0.00 | 0.90 | 0.00 | 0.49 | -21.22 | 33.43 | 12.72 | 209.91 | 0.4134 | -850.0 | -640.3 | |
| 0.00 | 9.77 | 0.00 | 5.39 | -23.28 | 33.55 | 12.85 | 207.62 | 0.4423 | -354.0 | -312.4 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -20.99 | 33.34 | 12.63 | 210.04 | 0.4096 | -741.0 | -660.6 | |
| 0.00 | 2.08 | 0.00 | 1.13 | -21.67 | 33.30 | 12.59 | 209.08 | 0.4186 | -539.0 | -556.6 | |
| 0.00 | 0.54 | 0.00 | 0.30 | -21.31 | 33.27 | 12.56 | 209.48 | 0.4135 | -735.0 | -639.2 | |
| 0.36 | 21.26 | 0.20 | 11.62 | -22.26 | 33.25 | 12.55 | 208.27 | 0.4262 | -930.8 | -552.8 | |
| 0.00 | 1.99 | 0.00 | 1.08 | -20.50 | 33.10 | 12.39 | 210.22 | 0.4011 | -943.0 | -776.1 | |
| 1.45 | 6.33 | 0.79 | 3.45 | -21.71 | 33.10 | 12.40 | 208.67 | 0.4175 | -913.0 | -746.5 | |
| 0.00 | 1.54 | 0.00 | 0.85 | -24.28 | 33.35 | 12.64 | 206.15 | 0.4544 | -788.0 | -587.2 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -22.53 | 33.11 | 12.40 | 207.69 | 0.4287 | -889.0 | -741.1 | |
| 0.00 | 2.53 | 0.00 | 1.39 | -23.25 | 33.04 | 12.33 | 206.73 | 0.4382 | -677.0 | -694.6 | |
| 0.00 | 1.18 | 0.00 | 0.64 | -21.58 | 32.82 | 12.12 | 208.29 | 0.4136 | -1021.0 | -853.4 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -16.97 | 32.32 | 11.61 | 213.88 | 0.3469 | -875.0 | -688.3 | |
| 1.27 | 3.71 | 0.69 | 2.03 | -22.66 | 32.68 | 11.98 | 206.73 | 0.4275 | -958.6 | -867.2 | |
| 0.00 | 1.27 | 0.00 | 0.70 | -23.42 | 32.68 | 11.98 | 205.88 | 0.4380 | -709.0 | -643.8 | |
| 0.00 | 0.99 | 0.00 | 0.54 | -22.10 | 32.47 | 11.76 | 206.96 | 0.4182 | -816.0 | -713.8 | |
| 0.00 | 1.72 | 0.00 | 0.94 | -22.89 | 32.47 | 11.76 | 206.06 | 0.4292 | -755.0 | -576.8 | |
| 0.00 | 1.54 | 0.00 | 0.85 | -23.85 | 32.49 | 11.78 | 205.06 | 0.4426 | -582.0 | -461.2 | |
| 0.00 | 0.90 | 0.00 | 0.50 | -23.55 | 32.32 | 11.62 | 205.07 | 0.4374 | -715.0 | -533.5 | |
| 0.00 | 2.53 | 0.00 | 1.38 | -22.00 | 32.06 | 11.35 | 206.27 | 0.4139 | -710.0 | -603.2 | |
| 0.00 | 2.80 | 0.00 | 1.53 | -22.36 | 31.65 | 10.94 | 205.06 | 0.4162 | -581.0 | -447.5 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -24.72 | 29.67 | 8.97 | 198.92 | 0.4385 | -688.0 | -541.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
