SDO HMI 2011-06-04 11:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.16 | 134.02 | 11.72 | 70.91 | -20.78 | 19.20 | 1.78 | 184.77 | 0.3531 | 1057.4 | 481.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-04 11:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.89 | 122.90 | 11.05 | 64.98 | -20.67 | 19.36 | 1.94 | 185.19 | 0.3513 | 1369.4 | 473.8 | |
| 0.00 | 1.09 | 0.00 | 0.58 | -22.44 | 18.59 | 1.17 | 182.87 | 0.3791 | 515.0 | 434.2 | |
| 0.00 | 0.90 | 0.00 | 0.48 | -21.36 | 18.42 | 1.00 | 182.59 | 0.3614 | 820.0 | 763.0 | |
| 1.27 | 3.44 | 0.67 | 1.83 | -21.85 | 18.10 | 0.68 | 181.71 | 0.3692 | 914.1 | 920.0 | |
| 0.00 | 0.81 | 0.00 | 0.43 | -22.01 | 17.64 | 0.22 | 180.55 | 0.3717 | 936.0 | 786.9 | |
| 0.00 | 2.89 | 0.00 | 1.54 | -21.88 | 17.47 | 0.05 | 180.14 | 0.3695 | 760.0 | 643.8 | |
| 0.00 | 0.90 | 0.00 | 0.49 | -24.12 | 15.77 | -1.64 | 176.29 | 0.4066 | 676.0 | 542.7 | |
| 0.00 | 1.09 | 0.00 | 0.58 | -21.36 | 14.76 | -2.66 | 173.15 | 0.3636 | -714.0 | -543.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
