SDO HMI 2011-06-04 13:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 64.02 | 391.70 | 36.21 | 220.97 | -22.22 | 35.16 | 18.84 | 218.62 | 0.4820 | 87.3 | 35.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-04 13:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.81 | 0.00 | 0.47 | -21.70 | 39.49 | 23.17 | 225.01 | 0.5189 | 671.0 | 573.3 | |
| 17.90 | 59.04 | 10.16 | 33.48 | -19.39 | 38.80 | 22.49 | 227.75 | 0.4893 | 1141.1 | 543.1 | |
| 0.00 | 0.99 | 0.00 | 0.58 | -23.97 | 39.25 | 22.93 | 221.53 | 0.5391 | 829.0 | 649.3 | |
| 0.00 | 1.81 | 0.00 | 1.06 | -24.24 | 39.19 | 22.87 | 221.10 | 0.5413 | 766.0 | 646.7 | |
| 0.00 | 0.81 | 0.00 | 0.48 | -23.67 | 38.94 | 22.62 | 221.57 | 0.5331 | 749.0 | 611.1 | |
| 0.54 | 8.86 | 0.32 | 5.16 | -23.84 | 38.43 | 22.12 | 220.73 | 0.5298 | 620.7 | 778.2 | |
| 0.00 | 3.44 | 0.00 | 1.99 | -23.54 | 37.84 | 21.53 | 220.41 | 0.5210 | 770.0 | 661.3 | |
| 0.00 | 1.90 | 0.00 | 1.07 | -20.17 | 37.24 | 20.93 | 224.56 | 0.4797 | 829.0 | 692.0 | |
| 0.00 | 1.27 | 0.00 | 0.71 | -20.30 | 37.12 | 20.81 | 224.20 | 0.4798 | 716.0 | 627.5 | |
| 0.00 | 4.61 | 0.00 | 2.59 | -19.62 | 36.93 | 20.61 | 225.01 | 0.4707 | 742.0 | 750.2 | |
| 0.00 | 0.54 | 0.00 | 0.31 | -23.14 | 37.42 | 21.10 | 220.42 | 0.5126 | 795.0 | 689.0 | |
| 0.00 | 5.15 | 0.00 | 2.89 | -19.91 | 36.79 | 20.48 | 224.37 | 0.4722 | 923.0 | 770.4 | |
| 0.00 | 1.18 | 0.00 | 0.66 | -19.65 | 36.59 | 20.27 | 224.51 | 0.4673 | 807.0 | 628.8 | |
| 0.00 | 4.43 | 0.00 | 2.49 | -20.14 | 36.44 | 20.13 | 223.55 | 0.4708 | 844.0 | 642.8 | |
| 4.97 | 6.96 | 2.78 | 3.90 | -20.72 | 35.59 | 19.27 | 221.46 | 0.4682 | 913.2 | 549.2 | |
| 0.00 | 1.36 | 0.00 | 0.76 | -21.28 | 35.63 | 19.31 | 220.69 | 0.4747 | 76.0 | 196.9 | |
| 1.99 | 6.51 | 1.12 | 3.65 | -21.21 | 35.35 | 19.03 | 220.38 | 0.4711 | 800.5 | 652.1 | |
| 2.17 | 101.99 | 1.24 | 57.83 | -23.78 | 35.54 | 19.22 | 217.07 | 0.5019 | 845.7 | -229.6 | |
| 0.00 | 3.26 | 0.00 | 1.88 | -25.08 | 35.71 | 19.40 | 215.64 | 0.5183 | -203.0 | -254.3 | |
| 0.00 | 1.36 | 0.00 | 0.78 | -24.71 | 35.58 | 19.27 | 215.92 | 0.5129 | -541.0 | -351.7 | |
| 0.00 | 1.45 | 0.00 | 0.83 | -24.47 | 35.51 | 19.19 | 216.12 | 0.5096 | -673.0 | -601.2 | |
| 0.00 | 0.99 | 0.00 | 0.57 | -24.84 | 35.50 | 19.18 | 215.64 | 0.5137 | -507.0 | -391.3 | |
| 0.00 | 0.90 | 0.00 | 0.52 | -24.64 | 35.32 | 19.01 | 215.65 | 0.5099 | -726.0 | -539.0 | |
| 0.00 | 2.62 | 0.00 | 1.47 | -21.73 | 34.55 | 18.24 | 218.47 | 0.4692 | 658.0 | 556.4 | |
| 3.98 | 133.64 | 2.24 | 74.94 | -22.16 | 34.51 | 18.19 | 217.79 | 0.4737 | 1010.5 | -71.7 | |
| 0.00 | 2.26 | 0.00 | 1.26 | -21.57 | 34.39 | 18.08 | 218.46 | 0.4658 | 993.0 | 796.2 | |
| 0.00 | 1.72 | 0.00 | 0.95 | -19.95 | 34.19 | 17.88 | 220.60 | 0.4452 | -988.0 | -817.8 | |
| 3.89 | -25.00 | 2.19 | -25.00 | -22.42 | 34.40 | 18.09 | 217.27 | 0.4758 | 935.6 | 999999 | |
| 2.71 | 7.23 | 1.52 | 4.05 | -21.90 | 34.23 | 17.91 | 217.75 | 0.4680 | 903.8 | 678.4 | |
| 1.27 | -18.00 | 0.72 | -18.00 | -23.58 | 34.46 | 18.14 | 215.80 | 0.4898 | -743.4 | 999999 | |
| 16.55 | -18.00 | 9.42 | -18.00 | -24.08 | 34.32 | 18.00 | 214.96 | 0.4945 | -921.5 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.65 | -20.21 | 33.71 | 17.40 | 219.45 | 0.4434 | -909.0 | -758.8 | |
| 1.63 | -18.00 | 0.92 | -18.00 | -23.48 | 33.89 | 17.57 | 215.10 | 0.4835 | 443.9 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -20.95 | 33.53 | 17.21 | 218.04 | 0.4503 | -894.0 | -729.5 | |
| 2.53 | 3.53 | 1.40 | 1.95 | -21.15 | 33.18 | 16.86 | 217.20 | 0.4492 | -915.0 | -930.9 | |
| 0.00 | 1.63 | 0.00 | 0.92 | -24.21 | 33.33 | 17.01 | 213.33 | 0.4875 | -723.0 | -645.5 | |
| 2.71 | -25.00 | 1.52 | -25.00 | -22.49 | 33.03 | 16.71 | 215.10 | 0.4640 | -888.6 | 999999 | |
| 0.00 | 0.90 | 0.00 | 0.49 | -16.81 | 32.37 | 16.05 | 222.91 | 0.3903 | -707.0 | -570.6 | |
| 0.00 | 1.72 | 0.00 | 0.95 | -21.47 | 32.74 | 16.42 | 216.03 | 0.4490 | -844.0 | -725.5 | |
| 1.18 | -25.00 | 0.66 | -25.00 | -22.52 | 32.80 | 16.48 | 214.68 | 0.4623 | -1083.8 | 999999 | |
| 0.00 | 1.72 | 0.00 | 0.97 | -23.48 | 32.85 | 16.53 | 213.52 | 0.4745 | -471.0 | -533.2 | |
| 0.00 | 0.90 | 0.00 | 0.50 | -22.03 | 32.63 | 16.32 | 215.09 | 0.4549 | -840.0 | -703.1 | |
| 0.00 | 2.26 | 0.00 | 1.25 | -22.06 | 32.30 | 15.98 | 214.50 | 0.4523 | -805.0 | -663.6 | |
| 0.00 | 1.27 | 0.00 | 0.70 | -21.93 | 32.11 | 15.79 | 214.37 | 0.4490 | -915.0 | -797.7 | |
| 0.00 | 0.72 | 0.00 | 0.40 | -22.59 | 31.98 | 15.66 | 213.29 | 0.4561 | -550.0 | -500.1 | |
| 0.00 | 2.17 | 0.00 | 1.20 | -21.67 | 31.67 | 15.35 | 214.00 | 0.4419 | -875.0 | -712.2 | |
| 0.00 | 0.99 | 0.00 | 0.55 | -22.10 | 31.69 | 15.37 | 213.45 | 0.4473 | -660.0 | -594.4 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -22.52 | 31.60 | 15.28 | 212.74 | 0.4520 | -691.0 | -537.2 | |
| 0.00 | 2.35 | 0.00 | 1.30 | -21.90 | 31.12 | 14.80 | 212.75 | 0.4400 | -922.0 | -799.4 | |
| 0.00 | 1.09 | 0.00 | 0.61 | -24.81 | 29.63 | 13.31 | 206.71 | 0.4668 | -757.0 | -659.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
