SDO HMI 2011-06-04 21:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 48.56 | 225.93 | 25.47 | 118.65 | 17.21 | 20.10 | 8.22 | 335.59 | 0.3337 | -413.5 | -355.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-04 21:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.71 | 0.00 | 1.45 | 19.65 | 22.33 | 10.45 | 333.36 | 0.3826 | -798.0 | -544.4 | |
| 25.86 | 184.99 | 13.58 | 97.16 | 16.80 | 21.19 | 9.31 | 332.16 | 0.3331 | -1255.2 | -478.0 | |
| 5.52 | -2.00 | 2.90 | -2.00 | 17.18 | 21.08 | 9.20 | 332.99 | 0.3378 | -998.6 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.43 | 18.72 | 20.87 | 8.99 | 335.53 | 0.3588 | -808.0 | -580.4 | |
| 3.98 | -2.00 | 2.09 | -2.00 | 17.08 | 20.63 | 8.75 | 334.00 | 0.3330 | -1070.3 | 999999 | |
| 0.00 | 0.90 | 0.00 | 0.47 | 17.15 | 18.38 | 6.50 | 340.11 | 0.3194 | -885.0 | -766.4 | |
| 0.00 | 0.99 | 0.00 | 0.53 | 20.10 | 18.47 | 6.58 | 342.81 | 0.3658 | -753.0 | -610.7 | |
| 2.71 | 3.25 | 1.42 | 1.70 | 18.07 | 16.55 | 4.67 | 346.17 | 0.3253 | -868.8 | -801.8 | |
| 0.00 | 1.45 | 0.00 | 0.75 | 16.83 | 16.52 | 4.64 | 345.24 | 0.3051 | -939.0 | -647.9 | |
| 0.00 | 1.27 | 0.00 | 0.66 | 16.38 | 16.35 | 4.47 | 345.37 | 0.2972 | -650.0 | -559.6 | |
| 0.00 | 1.63 | 0.00 | 0.86 | 19.87 | 14.98 | 3.10 | 351.59 | 0.3495 | 765.0 | 622.9 | |
| 0.00 | 1.08 | 0.00 | 0.56 | 16.79 | 14.74 | 2.86 | 350.76 | 0.2984 | 915.0 | 780.0 | |
| 6.51 | 11.21 | 3.41 | 5.87 | 18.62 | 14.54 | 2.66 | 352.26 | 0.3279 | 1057.8 | 750.9 | |
| 3.98 | 5.06 | 2.07 | 2.63 | 17.30 | 14.39 | 2.51 | 352.10 | 0.3060 | 1065.5 | 803.2 | |
| 0.00 | 4.07 | 0.00 | 2.13 | 18.13 | 14.21 | 2.33 | 353.01 | 0.3193 | 663.0 | 891.6 | |
| 0.00 | 1.27 | 0.00 | 0.66 | 18.71 | 14.22 | 2.34 | 353.22 | 0.3288 | 829.0 | 680.1 | |
| 0.00 | 1.08 | 0.00 | 0.57 | 18.91 | 14.19 | 2.31 | 353.37 | 0.3319 | 800.0 | 626.2 | |
| 0.00 | 1.63 | 0.00 | 0.87 | 21.63 | 13.74 | 1.86 | 355.37 | 0.3757 | 740.0 | 574.6 | |
| 0.00 | 1.63 | 0.00 | 0.88 | 23.52 | 13.70 | 1.82 | 355.87 | 0.4059 | 731.0 | 539.8 | |
| 0.00 | 0.90 | 0.00 | 0.47 | 19.07 | 13.55 | 1.67 | 355.25 | 0.3335 | 670.0 | 589.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
