SDO HMI 2011-06-05 00:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.61 | 132.40 | 11.58 | 70.98 | -20.78 | 19.38 | 9.15 | 202.97 | 0.3829 | 1100.5 | 510.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-05 00:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.90 | 119.11 | 10.12 | 63.81 | -20.65 | 19.49 | 9.26 | 203.35 | 0.3816 | 1292.7 | 494.1 | |
| 0.00 | 2.44 | 0.00 | 1.32 | -22.55 | 18.74 | 8.52 | 199.82 | 0.4053 | 746.0 | 703.8 | |
| 0.00 | 1.81 | 0.00 | 0.98 | -22.39 | 18.50 | 8.28 | 199.45 | 0.4015 | 707.0 | 584.7 | |
| 0.00 | 2.17 | 0.00 | 1.17 | -22.16 | 18.42 | 8.20 | 199.48 | 0.3977 | 690.0 | 500.5 | |
| 0.00 | 2.71 | 0.00 | 1.46 | -21.50 | 18.28 | 8.06 | 199.79 | 0.3871 | 896.0 | 794.3 | |
| 2.71 | 2.98 | 1.46 | 1.61 | -21.83 | 18.20 | 7.98 | 199.30 | 0.3916 | 874.9 | 811.7 | |
| 0.00 | 1.18 | 0.00 | 0.63 | -21.21 | 18.04 | 7.81 | 199.50 | 0.3813 | 847.0 | 700.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
