SDO HMI 2011-06-05 03:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.71 | 120.86 | 11.69 | 65.11 | -20.76 | 19.42 | 10.85 | 206.64 | 0.3943 | 1179.7 | 531.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-05 03:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 19.54 | 111.82 | 10.52 | 60.22 | -20.66 | 19.52 | 10.95 | 206.95 | 0.3936 | 1311.1 | 516.4 | |
| 0.00 | 0.72 | 0.00 | 0.39 | -22.59 | 18.86 | 10.29 | 203.42 | 0.4167 | 775.0 | 632.8 | |
| 2.17 | 4.52 | 1.17 | 2.44 | -21.87 | 18.27 | 9.70 | 202.97 | 0.4025 | 900.9 | 768.8 | |
| 0.00 | 2.44 | 0.00 | 1.32 | -21.60 | 18.26 | 9.69 | 203.21 | 0.3986 | 935.0 | 787.0 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -22.36 | 17.71 | 9.14 | 201.29 | 0.4063 | 773.0 | 611.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
