SDO HMI 2011-06-06 11:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.93 | 83.23 | 9.00 | 50.13 | -20.91 | 19.18 | 28.23 | 231.06 | 0.5706 | 803.2 | 442.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-06 11:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.27 | 0.00 | 0.17 | -20.51 | 21.17 | 30.22 | 233.43 | 0.5891 | 754.0 | 637.0 | |
| 0.00 | 1.81 | 0.00 | 1.11 | -22.47 | 20.26 | 29.31 | 229.85 | 0.5939 | 689.0 | 619.8 | |
| 14.93 | 74.10 | 9.00 | 44.69 | -20.57 | 19.65 | 28.70 | 232.05 | 0.5724 | 1186.0 | 497.1 | |
| 0.00 | 0.63 | 0.00 | 0.39 | -22.41 | 19.41 | 28.46 | 229.19 | 0.5843 | 533.0 | 502.7 | |
| 0.00 | 1.09 | 0.00 | 0.65 | -22.14 | 18.50 | 27.55 | 228.71 | 0.5723 | 711.0 | 500.2 | |
| 0.00 | 0.90 | 0.00 | 0.54 | -24.16 | 15.46 | 24.50 | 222.81 | 0.5590 | 821.0 | 693.7 | |
| 0.00 | 1.90 | 0.00 | 1.11 | -24.29 | 12.54 | 21.59 | 219.24 | 0.5323 | -672.0 | -426.5 | |
| 0.00 | 2.53 | 0.00 | 1.47 | -25.30 | 10.32 | 19.37 | 215.10 | 0.5235 | -659.0 | -523.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
