SDO HMI 2011-06-07 02:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.75 | 135.50 | 23.84 | 87.86 | 17.26 | 19.39 | 36.74 | 297.53 | 0.6458 | -320.9 | -222.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-07 02:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.81 | 0.00 | 0.61 | 21.76 | 27.06 | 44.41 | 299.68 | 0.7504 | -495.0 | -417.0 | |
| 0.00 | 1.90 | 0.00 | 1.35 | 21.04 | 24.55 | 41.90 | 299.92 | 0.7214 | -477.0 | -440.7 | |
| 2.90 | 90.24 | 1.91 | 59.50 | 16.97 | 21.00 | 38.35 | 296.17 | 0.6635 | -771.2 | -380.0 | |
| 23.17 | -3.00 | 15.26 | -3.00 | 16.78 | 20.87 | 38.22 | 295.97 | 0.6611 | -889.9 | 999999 | |
| 1.54 | -3.00 | 1.01 | -3.00 | 17.07 | 20.86 | 38.21 | 296.38 | 0.6623 | -651.7 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.86 | 17.51 | 17.23 | 34.58 | 299.05 | 0.6213 | -723.0 | -544.3 | |
| 2.44 | 7.87 | 1.53 | 4.94 | 17.35 | 16.85 | 34.20 | 299.05 | 0.6159 | -742.7 | -666.5 | |
| 0.00 | 0.91 | 0.00 | 0.57 | 17.07 | 16.75 | 34.10 | 298.68 | 0.6131 | -878.0 | -714.1 | |
| 0.00 | 2.53 | 0.00 | 1.59 | 18.15 | 16.29 | 33.63 | 300.60 | 0.6137 | -578.0 | -511.7 | |
| 0.00 | 1.09 | 0.00 | 0.67 | 17.07 | 15.75 | 33.10 | 299.32 | 0.6009 | -742.0 | -649.0 | |
| 0.00 | 1.54 | 0.00 | 0.95 | 16.97 | 15.58 | 32.93 | 299.28 | 0.5983 | -815.0 | -584.4 | |
| 0.00 | 0.91 | 0.00 | 0.56 | 18.54 | 15.49 | 32.84 | 301.71 | 0.6065 | 488.0 | 406.7 | |
| 0.00 | 1.18 | 0.00 | 0.73 | 18.28 | 15.35 | 32.70 | 301.42 | 0.6034 | 435.0 | 277.9 | |
| 0.00 | 2.08 | 0.00 | 1.29 | 18.44 | 15.20 | 32.55 | 301.77 | 0.6025 | 627.0 | 504.4 | |
| 0.00 | 1.18 | 0.00 | 0.72 | 17.42 | 14.99 | 32.34 | 300.36 | 0.5937 | 458.0 | 402.1 | |
| 6.70 | 9.59 | 4.13 | 5.92 | 18.09 | 15.09 | 32.43 | 301.31 | 0.5990 | 780.0 | 720.9 | |
| 0.00 | 1.45 | 0.00 | 0.90 | 19.15 | 15.31 | 32.66 | 302.73 | 0.6083 | 628.0 | 494.6 | |
| 0.00 | 4.89 | 0.00 | 3.01 | 17.77 | 14.94 | 32.29 | 300.93 | 0.5953 | 685.0 | 612.3 | |
| 0.00 | 4.16 | 0.00 | 2.58 | 18.92 | 14.92 | 32.27 | 302.68 | 0.6022 | 851.0 | 700.7 | |
| 0.00 | 1.09 | 0.00 | 0.67 | 19.18 | 14.60 | 31.95 | 303.30 | 0.6001 | 705.0 | 466.8 | |
| 0.00 | 0.72 | 0.00 | 0.44 | 16.87 | 14.13 | 31.48 | 300.12 | 0.5799 | 670.0 | 494.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
