SDO HMI 2011-06-07 12:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.06 | 134.67 | 13.09 | 67.64 | 9.41 | 336.79 | -0.38 | 0.10 | 0.1636 | -1120.6 | -529.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-07 12:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 0.72 | 7.91 | 339.42 | 2.26 | 344.02 | 0.1424 | -1029.0 | -825.6 | |
| 24.07 | 116.83 | 12.09 | 58.69 | 9.51 | 336.97 | -0.20 | 1.20 | 0.1646 | -1400.0 | -502.6 | |
| 0.00 | 3.44 | 0.00 | 1.72 | 7.97 | 336.44 | -0.72 | 5.18 | 0.1385 | -1111.0 | -889.2 | |
| 1.99 | 2.99 | 1.00 | 1.50 | 8.77 | 336.23 | -0.94 | 6.11 | 0.1527 | -950.2 | -723.1 | |
| 0.00 | 3.17 | 0.00 | 1.59 | 8.21 | 335.55 | -1.61 | 11.13 | 0.1449 | -1006.0 | -819.9 | |
| 0.00 | 2.08 | 0.00 | 1.05 | 10.68 | 335.23 | -1.93 | 10.21 | 0.1878 | -857.0 | -622.0 | |
| 0.00 | 1.45 | 0.00 | 0.73 | 9.69 | 335.14 | -2.02 | 11.75 | 0.1714 | -817.0 | -538.2 | |
| 0.00 | 1.00 | 0.00 | 0.50 | 9.38 | 335.05 | -2.11 | 12.66 | 0.1665 | -919.0 | -772.3 | |
| 0.00 | 1.45 | 0.00 | 0.73 | 9.26 | 333.67 | -3.50 | 20.67 | 0.1714 | -917.0 | -680.8 | |
| 0.00 | 0.81 | 0.00 | 0.41 | 6.98 | 329.75 | -7.42 | 46.81 | 0.1766 | 899.0 | 635.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
