SDO HMI 2011-06-07 17:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.53 | 134.43 | 11.32 | 67.61 | 9.45 | 336.95 | 2.55 | 344.77 | 0.1706 | -934.2 | -501.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-07 17:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 0.73 | 8.04 | 339.49 | 5.09 | 327.56 | 0.1647 | -992.0 | -766.4 | |
| 0.00 | 3.89 | 0.00 | 1.96 | 8.34 | 339.47 | 5.07 | 328.68 | 0.1689 | -601.0 | -626.3 | |
| 0.00 | 0.72 | 0.00 | 0.36 | 8.19 | 339.03 | 4.63 | 330.44 | 0.1628 | -809.0 | -749.2 | |
| 0.00 | 2.62 | 0.00 | 1.32 | 8.34 | 338.97 | 4.57 | 331.22 | 0.1646 | -938.0 | -808.5 | |
| 21.17 | 118.70 | 10.64 | 59.69 | 9.54 | 336.98 | 2.58 | 344.88 | 0.1710 | -1442.3 | -499.8 | |
| 1.36 | -5.00 | 0.68 | -5.00 | 9.30 | 336.67 | 2.27 | 346.28 | 0.1655 | -1029.0 | 999999 | |
| 0.00 | 1.99 | 0.00 | 1.00 | 7.97 | 336.63 | 2.23 | 344.31 | 0.1432 | -1155.0 | -927.4 | |
| 0.00 | 2.08 | 0.00 | 1.04 | 8.71 | 336.27 | 1.87 | 347.89 | 0.1541 | -1149.0 | -965.2 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 12.61 | 332.02 | -2.38 | 10.58 | 0.2216 | 856.0 | 570.3 | |
| 0.00 | 0.90 | 0.00 | 0.45 | 6.99 | 329.70 | -4.70 | 34.08 | 0.1459 | 1027.0 | 850.1 | |
| 0.00 | 0.72 | 0.00 | 0.37 | 14.86 | 329.22 | -5.18 | 18.87 | 0.2708 | 823.0 | 651.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
