SDO HMI 2011-06-08 03:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.81 | 137.44 | 12.08 | 69.71 | 9.48 | 336.89 | 8.02 | 319.71 | 0.2139 | -1010.0 | -430.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-08 03:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.65 | 8.39 | 339.56 | 10.69 | 307.98 | 0.2339 | -863.0 | -613.8 | |
| 23.81 | 128.29 | 12.08 | 65.08 | 9.50 | 337.00 | 8.13 | 319.35 | 0.2151 | -1372.2 | -443.1 | |
| 0.00 | 1.81 | 0.00 | 0.91 | 8.51 | 336.32 | 7.46 | 318.58 | 0.1948 | -885.0 | -605.8 | |
| 0.00 | 1.54 | 0.00 | 0.78 | 8.23 | 336.32 | 7.45 | 317.62 | 0.1913 | -826.0 | -656.0 | |
| 0.00 | 2.17 | 0.00 | 1.10 | 8.97 | 335.06 | 6.19 | 325.21 | 0.1876 | -787.0 | -559.8 | |
| 0.00 | 1.00 | 0.00 | 0.50 | 10.92 | 332.39 | 3.53 | 342.09 | 0.1972 | 917.0 | 709.8 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 10.64 | 331.98 | 3.12 | 343.63 | 0.1906 | 758.0 | 595.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
