SDO HMI 2011-06-10 01:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.76 | 26.44 | 14.26 | 25.34 | -15.98 | 246.17 | -57.33 | 109.01 | 0.8574 | 316.9 | 321.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-10 01:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.61 | 8.60 | 5.18 | 7.94 | -15.86 | 247.58 | -55.92 | 109.16 | 0.8455 | 671.7 | 550.0 | |
| 1.00 | 1.81 | 0.93 | 1.69 | -15.89 | 247.16 | -56.33 | 109.11 | 0.8492 | 280.1 | 354.9 | |
| 0.00 | 1.00 | 0.00 | 0.93 | -15.57 | 247.13 | -56.37 | 108.73 | 0.8490 | 539.0 | 481.6 | |
| 0.00 | 1.90 | 0.00 | 1.80 | -16.02 | 246.70 | -56.79 | 109.16 | 0.8534 | 380.0 | 306.7 | |
| 4.62 | 8.33 | 4.36 | 7.85 | -15.74 | 246.65 | -56.84 | 108.82 | 0.8534 | 448.9 | 380.5 | |
| 1.90 | 2.90 | 1.98 | 3.02 | -16.33 | 243.31 | -60.18 | 108.85 | 0.8817 | -385.2 | -409.5 | |
| 1.63 | 1.90 | 1.81 | 2.11 | -17.01 | 241.48 | -62.01 | 109.29 | 0.8965 | -386.8 | -412.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
