SDO HMI 2011-06-13 02:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 8.52 | 0.00 | 4.45 | 14.17 | 251.20 | -12.03 | 41.44 | 0.3133 | -149.9 | -181.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-13 02:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.67 | 18.14 | 254.73 | -8.50 | 25.16 | 0.3319 | -744.0 | -582.0 | |
| 0.00 | 1.63 | 0.00 | 0.85 | 15.22 | 253.17 | -10.07 | 33.98 | 0.3031 | -921.0 | -631.2 | |
| 0.00 | 1.18 | 0.00 | 0.60 | 10.52 | 251.66 | -11.58 | 49.26 | 0.2616 | 872.0 | 673.0 | |
| 0.00 | 1.36 | 0.00 | 0.70 | 10.27 | 250.46 | -12.77 | 52.70 | 0.2747 | 832.0 | 648.7 | |
| 0.00 | 1.36 | 0.00 | 0.72 | 15.65 | 249.40 | -13.84 | 41.79 | 0.3471 | -852.0 | -699.3 | |
| 0.00 | 1.09 | 0.00 | 0.58 | 16.13 | 249.10 | -14.13 | 41.44 | 0.3559 | -962.0 | -716.6 | |
| 0.00 | 0.63 | 0.00 | 0.33 | 11.59 | 247.36 | -15.88 | 54.87 | 0.3291 | 726.0 | 512.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
