SDO HMI 2011-06-14 15:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 58.18 | 156.53 | 30.01 | 80.77 | -14.85 | 246.34 | 3.48 | 192.29 | 0.2814 | 237.1 | -109.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-14 15:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 0.71 | -15.07 | 252.24 | 9.39 | 209.78 | 0.3185 | 868.0 | 664.0 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -14.87 | 249.40 | 6.55 | 202.05 | 0.2948 | 907.0 | 658.8 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -13.74 | 248.52 | 5.66 | 200.76 | 0.2717 | 898.0 | 712.2 | |
| 0.00 | 3.17 | 0.00 | 1.63 | -13.92 | 248.37 | 5.51 | 200.00 | 0.2738 | 959.0 | 723.3 | |
| 0.00 | 2.54 | 0.00 | 1.30 | -13.67 | 248.33 | 5.47 | 200.20 | 0.2696 | 876.0 | 681.6 | |
| 8.70 | 12.23 | 4.50 | 6.32 | -14.71 | 248.32 | 5.47 | 198.88 | 0.2860 | 1076.4 | 811.5 | |
| 0.00 | 0.91 | 0.00 | 0.47 | -15.22 | 247.92 | 5.07 | 197.05 | 0.2920 | 897.0 | 831.3 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -14.93 | 247.88 | 5.03 | 197.23 | 0.2872 | 781.0 | 669.7 | |
| 0.00 | 1.81 | 0.00 | 0.94 | -14.93 | 247.66 | 4.81 | 196.52 | 0.2861 | 736.0 | 598.2 | |
| 39.78 | 57.81 | 20.50 | 29.78 | -14.30 | 247.59 | 4.73 | 196.93 | 0.2756 | 1117.5 | 453.4 | |
| 0.72 | 5.89 | 0.38 | 3.05 | -15.15 | 247.60 | 4.75 | 196.10 | 0.2894 | 580.1 | 564.6 | |
| 0.00 | 0.91 | 0.00 | 0.47 | -14.93 | 247.19 | 4.33 | 194.97 | 0.2840 | 646.0 | 480.2 | |
| 1.09 | 2.45 | 0.56 | 1.26 | -13.89 | 246.98 | 4.13 | 195.28 | 0.2661 | 1010.8 | 815.0 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -14.90 | 246.49 | 3.64 | 192.68 | 0.2806 | 710.0 | 711.6 | |
| 0.00 | 1.81 | 0.00 | 0.93 | -13.39 | 245.75 | 2.89 | 191.24 | 0.2530 | 465.0 | 411.1 | |
| 0.00 | 1.72 | 0.00 | 0.88 | -13.54 | 245.41 | 2.55 | 189.83 | 0.2546 | -592.0 | -369.3 | |
| 3.90 | 17.67 | 2.01 | 9.14 | -15.56 | 244.96 | 2.10 | 187.09 | 0.2872 | -995.1 | -662.6 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -14.65 | 244.76 | 1.90 | 186.83 | 0.2714 | -809.0 | -632.4 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -14.30 | 244.72 | 1.87 | 186.86 | 0.2656 | -803.0 | -610.8 | |
| 2.27 | 6.89 | 1.17 | 3.56 | -15.75 | 244.55 | 1.69 | 185.65 | 0.2896 | -976.6 | -803.4 | |
| 0.00 | 4.62 | 0.00 | 2.37 | -14.17 | 244.53 | 1.68 | 186.22 | 0.2631 | -1223.0 | -893.7 | |
| 1.72 | 2.81 | 0.89 | 1.45 | -15.15 | 244.41 | 1.56 | 185.42 | 0.2793 | -1053.4 | -810.9 | |
| 0.00 | 1.54 | 0.00 | 0.79 | -14.90 | 244.13 | 1.27 | 184.51 | 0.2746 | -995.0 | -765.1 | |
| 0.00 | 1.45 | 0.00 | 0.75 | -14.49 | 244.03 | 1.18 | 184.28 | 0.2676 | -1007.0 | -875.9 | |
| 0.00 | 1.09 | 0.00 | 0.57 | -18.32 | 243.70 | 0.85 | 182.44 | 0.3312 | 778.0 | 609.4 | |
| 0.00 | 1.72 | 0.00 | 0.89 | -15.82 | 243.44 | 0.58 | 181.95 | 0.2894 | -922.0 | -802.5 | |
| 0.00 | 1.54 | 0.00 | 0.80 | -16.26 | 243.41 | 0.55 | 181.80 | 0.2969 | -788.0 | -566.2 | |
| 0.00 | 1.09 | 0.00 | 0.56 | -15.69 | 243.34 | 0.49 | 181.65 | 0.2872 | -1102.0 | -937.2 | |
| 0.00 | 1.27 | 0.00 | 0.66 | -15.44 | 243.31 | 0.46 | 181.56 | 0.2830 | -1013.0 | -816.6 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -16.36 | 243.22 | 0.36 | 181.17 | 0.2984 | -740.0 | -659.3 | |
| 0.00 | 1.90 | 0.00 | 0.99 | -15.95 | 243.19 | 0.33 | 181.10 | 0.2914 | -937.0 | -737.1 | |
| 0.00 | 1.09 | 0.00 | 0.56 | -16.10 | 242.87 | 0.01 | 180.05 | 0.2941 | -949.0 | -637.2 | |
| 0.00 | 2.36 | 0.00 | 1.22 | -15.72 | 242.84 | -0.02 | 179.94 | 0.2877 | -1154.0 | -860.5 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -15.47 | 242.84 | -0.02 | 179.94 | 0.2834 | -1036.0 | -801.0 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -16.42 | 242.81 | -0.05 | 179.84 | 0.2994 | -999.0 | -846.7 | |
| 0.00 | 1.27 | 0.00 | 0.66 | -17.32 | 242.68 | -0.18 | 179.46 | 0.3144 | -797.0 | -621.1 | |
| 0.00 | 0.91 | 0.00 | 0.47 | -16.39 | 242.65 | -0.21 | 179.33 | 0.2989 | -821.0 | -666.7 | |
| 0.00 | 1.45 | 0.00 | 0.75 | -15.95 | 242.36 | -0.49 | 178.37 | 0.2915 | -979.0 | -748.4 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -16.20 | 242.30 | -0.56 | 178.19 | 0.2958 | -913.0 | -681.3 | |
| 0.00 | 1.09 | 0.00 | 0.57 | -17.32 | 241.75 | -1.10 | 176.64 | 0.3149 | -803.0 | -654.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
