SDO HMI 2011-06-16 15:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 124.72 | 741.79 | 99.76 | 593.56 | 16.65 | 166.42 | -49.96 | 69.42 | 0.7839 | -199.4 | 1.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-16 15:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.81 | 0.00 | 1.22 | 12.74 | 175.03 | -41.35 | 72.29 | 0.6787 | -567.0 | -362.7 | |
| 0.00 | 0.45 | 0.00 | 0.31 | 12.76 | 174.15 | -42.23 | 72.53 | 0.6895 | -632.0 | -625.4 | |
| 0.00 | 1.18 | 0.00 | 0.84 | 16.64 | 172.59 | -43.79 | 67.68 | 0.7191 | -399.0 | -340.3 | |
| 0.00 | 1.00 | 0.00 | 0.78 | 21.89 | 168.98 | -47.40 | 62.20 | 0.7744 | -323.0 | -296.5 | |
| 38.62 | 382.99 | 28.66 | 284.96 | 17.34 | 170.25 | -46.13 | 67.54 | 0.7470 | -1052.5 | -208.3 | |
| 27.47 | -5.00 | 20.34 | -5.00 | 16.64 | 170.20 | -46.18 | 68.46 | 0.7455 | -1077.2 | 999999 | |
| 0.00 | 1.63 | 0.00 | 1.22 | 14.83 | 169.40 | -46.98 | 71.06 | 0.7495 | -748.0 | -578.8 | |
| 0.00 | 0.73 | 0.00 | 0.56 | 16.96 | 168.26 | -48.12 | 68.63 | 0.7671 | 569.0 | 409.0 | |
| 0.00 | 1.09 | 0.00 | 0.83 | 15.28 | 168.42 | -47.96 | 70.73 | 0.7612 | -633.0 | -530.0 | |
| 0.00 | 2.08 | 0.00 | 1.58 | 14.63 | 168.57 | -47.81 | 71.54 | 0.7581 | -580.0 | -442.4 | |
| 0.00 | 1.90 | 0.00 | 1.46 | 15.18 | 167.88 | -48.50 | 71.00 | 0.7668 | -554.0 | -437.6 | |
| 0.00 | 1.27 | 0.00 | 1.04 | 17.90 | 165.33 | -51.05 | 68.25 | 0.7989 | 529.0 | 390.9 | |
| 0.00 | 1.27 | 0.00 | 1.04 | 17.65 | 165.33 | -51.05 | 68.56 | 0.7984 | 632.0 | 514.6 | |
| 1.81 | 5.98 | 1.45 | 4.81 | 14.52 | 165.64 | -50.74 | 72.36 | 0.7887 | -574.7 | -517.3 | |
| 0.00 | 4.44 | 0.00 | 3.55 | 14.21 | 165.69 | -50.69 | 72.74 | 0.7876 | -273.0 | -182.2 | |
| 0.00 | 1.63 | 0.00 | 1.32 | 14.04 | 165.09 | -51.29 | 73.08 | 0.7935 | 399.0 | 289.3 | |
| 0.00 | 1.63 | 0.00 | 1.36 | 16.65 | 164.18 | -52.20 | 70.07 | 0.8075 | 677.0 | 578.4 | |
| 0.00 | 2.54 | 0.00 | 2.08 | 14.88 | 164.71 | -51.67 | 72.11 | 0.7988 | -748.0 | -587.5 | |
| 0.00 | 0.82 | 0.00 | 0.68 | 15.41 | 164.32 | -52.06 | 71.54 | 0.8037 | -461.0 | -344.8 | |
| 0.00 | 1.54 | 0.00 | 1.30 | 16.48 | 163.87 | -52.51 | 70.34 | 0.8101 | 644.0 | 591.5 | |
| 0.00 | 11.33 | 0.00 | 9.26 | 13.85 | 164.69 | -51.69 | 73.40 | 0.7972 | -260.0 | -110.9 | |
| 11.15 | 73.52 | 9.25 | 61.53 | 15.10 | 164.18 | -52.20 | 71.96 | 0.8045 | -741.8 | -110.9 | |
| 0.00 | 1.72 | 0.00 | 1.46 | 16.25 | 163.49 | -52.89 | 70.70 | 0.8134 | 632.0 | 455.8 | |
| 0.00 | 1.00 | 0.00 | 0.86 | 17.36 | 162.83 | -53.55 | 69.52 | 0.8218 | 480.0 | 479.4 | |
| 0.00 | 1.63 | 0.00 | 1.39 | 16.38 | 163.12 | -53.26 | 70.63 | 0.8171 | 444.0 | 428.6 | |
| 1.27 | -22.00 | 1.08 | -22.00 | 15.62 | 163.31 | -53.07 | 71.51 | 0.8140 | 532.0 | 999999 | |
| 6.25 | 106.60 | 5.54 | 94.18 | 18.43 | 162.07 | -54.31 | 68.41 | 0.8308 | 564.7 | 353.9 | |
| 1.09 | -27.00 | 0.96 | -27.00 | 18.05 | 162.25 | -54.13 | 68.82 | 0.8284 | 649.8 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.67 | 13.00 | 164.14 | -52.24 | 74.56 | 0.8014 | 498.0 | 413.9 | |
| 0.00 | 22.21 | 0.00 | 19.20 | 16.75 | 162.70 | -53.68 | 70.27 | 0.8218 | 799.0 | 601.4 | |
| 4.80 | -27.00 | 4.22 | -27.00 | 17.70 | 162.24 | -54.14 | 69.24 | 0.8278 | 884.2 | 999999 | |
| 0.00 | 2.08 | 0.00 | 1.82 | 17.35 | 162.39 | -53.99 | 69.62 | 0.8258 | 685.0 | 650.8 | |
| 0.00 | 5.35 | 0.00 | 4.61 | 16.28 | 162.79 | -53.59 | 70.82 | 0.8201 | 827.0 | 698.3 | |
| 3.44 | -22.00 | 2.94 | -22.00 | 15.49 | 163.04 | -53.34 | 71.72 | 0.8163 | 703.2 | 999999 | |
| 0.36 | -27.00 | 0.32 | -27.00 | 17.91 | 161.76 | -54.62 | 69.09 | 0.8326 | 411.5 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.71 | 16.30 | 162.29 | -54.09 | 70.90 | 0.8248 | 660.0 | 582.7 | |
| 0.00 | 1.00 | 0.00 | 0.84 | 12.92 | 163.44 | -52.94 | 74.77 | 0.8083 | 300.0 | 259.8 | |
| 4.53 | -27.00 | 4.01 | -27.00 | 17.24 | 161.78 | -54.60 | 69.88 | 0.8312 | 692.1 | 999999 | |
| 0.73 | -27.00 | 0.65 | -27.00 | 17.72 | 161.51 | -54.87 | 69.38 | 0.8345 | 372.6 | 999999 | |
| 3.35 | 85.84 | 2.92 | 75.40 | 15.89 | 162.24 | -54.14 | 71.40 | 0.8246 | 820.3 | 216.4 | |
| 4.44 | 5.08 | 3.92 | 4.48 | 16.77 | 161.82 | -54.56 | 70.44 | 0.8300 | 510.6 | 490.7 | |
| 0.45 | -40.00 | 0.40 | -40.00 | 16.01 | 162.08 | -54.30 | 71.29 | 0.8263 | 565.4 | 999999 | |
| 12.51 | -40.00 | 10.93 | -40.00 | 15.51 | 162.06 | -54.32 | 71.89 | 0.8256 | 858.3 | 999999 | |
| 1.00 | -27.00 | 0.89 | -27.00 | 17.14 | 161.32 | -55.06 | 70.10 | 0.8352 | 358.9 | 999999 | |
| 1.45 | -40.00 | 1.28 | -40.00 | 15.97 | 161.55 | -54.84 | 71.44 | 0.8312 | 253.8 | 999999 | |
| 0.00 | 2.27 | 0.00 | 2.03 | 16.06 | 161.12 | -55.26 | 71.42 | 0.8352 | 146.0 | 87.8 | |
| 0.00 | 1.54 | 0.00 | 1.43 | 18.05 | 160.04 | -56.34 | 69.30 | 0.8481 | 378.0 | 330.2 | |
| 0.00 | 1.09 | 0.00 | 1.00 | 17.25 | 160.19 | -56.19 | 70.19 | 0.8454 | 433.0 | 353.9 | |
| 0.00 | 1.00 | 0.00 | 0.91 | 16.68 | 160.40 | -55.98 | 70.82 | 0.8427 | 269.0 | 245.7 | |
| 0.00 | 0.91 | 0.00 | 0.84 | 16.96 | 159.98 | -56.40 | 70.57 | 0.8468 | 373.0 | 289.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
