SDO HMI 2011-06-16 17:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 130.25 | 742.52 | 102.23 | 580.96 | 16.64 | 166.43 | -48.84 | 69.13 | 0.7725 | -206.8 | -2.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-16 17:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.91 | 0.00 | 0.60 | 12.61 | 175.39 | -39.88 | 72.02 | 0.6601 | -606.0 | -541.9 | |
| 0.00 | 0.82 | 0.00 | 0.57 | 14.22 | 171.81 | -43.46 | 70.87 | 0.7080 | -463.0 | -426.4 | |
| 39.70 | 389.04 | 28.89 | 283.90 | 17.35 | 170.28 | -44.99 | 67.14 | 0.7346 | -1117.3 | -216.1 | |
| 27.65 | -3.00 | 20.09 | -3.00 | 16.66 | 170.18 | -45.09 | 68.10 | 0.7336 | -1129.8 | 999999 | |
| 0.00 | 1.99 | 0.00 | 1.46 | 14.75 | 169.41 | -45.86 | 70.86 | 0.7369 | -700.0 | -586.5 | |
| 0.00 | 0.54 | 0.00 | 0.41 | 16.75 | 168.03 | -47.24 | 68.64 | 0.7572 | 552.0 | 516.3 | |
| 0.00 | 1.27 | 0.00 | 0.94 | 14.61 | 168.58 | -46.69 | 71.27 | 0.7458 | -655.0 | -487.8 | |
| 0.00 | 1.27 | 0.00 | 0.95 | 15.37 | 168.32 | -46.95 | 70.35 | 0.7505 | -618.0 | -503.6 | |
| 0.00 | 0.63 | 0.00 | 0.48 | 15.39 | 167.75 | -47.52 | 70.48 | 0.7567 | -356.0 | -307.6 | |
| 0.00 | 1.00 | 0.00 | 0.80 | 17.96 | 165.37 | -49.90 | 67.88 | 0.7877 | 344.0 | 332.1 | |
| 0.00 | 7.25 | 0.00 | 5.69 | 14.51 | 165.62 | -49.65 | 72.14 | 0.7774 | -640.0 | -501.1 | |
| 0.00 | 1.54 | 0.00 | 1.20 | 14.13 | 165.74 | -49.53 | 72.59 | 0.7754 | -208.0 | -184.1 | |
| 0.00 | 1.45 | 0.00 | 1.18 | 16.76 | 164.26 | -51.01 | 69.65 | 0.7960 | 538.0 | 453.0 | |
| 0.00 | 3.17 | 0.00 | 2.51 | 14.03 | 165.13 | -50.14 | 72.85 | 0.7816 | 444.0 | 261.3 | |
| 0.00 | 1.72 | 0.00 | 1.38 | 14.87 | 164.82 | -50.45 | 71.86 | 0.7865 | -596.0 | -541.3 | |
| 0.00 | 2.54 | 0.00 | 2.08 | 16.57 | 163.98 | -51.29 | 69.95 | 0.7984 | 684.0 | 693.6 | |
| 0.00 | 15.50 | 0.00 | 12.37 | 13.77 | 164.67 | -50.61 | 73.28 | 0.7860 | 82.0 | -9.5 | |
| 10.61 | 58.92 | 8.59 | 47.96 | 15.12 | 164.19 | -51.08 | 71.70 | 0.7934 | -779.2 | -240.6 | |
| 0.00 | 0.45 | 0.00 | 0.38 | 16.43 | 163.31 | -51.96 | 70.28 | 0.8047 | 308.0 | 307.0 | |
| 5.17 | 103.88 | 4.45 | 89.22 | 18.45 | 162.10 | -53.17 | 68.12 | 0.8203 | 705.2 | 410.0 | |
| 4.26 | 10.24 | 3.54 | 8.52 | 15.51 | 163.13 | -52.14 | 71.44 | 0.8047 | 694.3 | 603.5 | |
| 4.44 | -20.00 | 3.80 | -20.00 | 17.72 | 162.21 | -53.06 | 68.98 | 0.8178 | 895.9 | 999999 | |
| 0.00 | 1.36 | 0.00 | 1.16 | 17.11 | 162.25 | -53.02 | 69.69 | 0.8162 | 429.0 | 485.0 | |
| 1.36 | -20.00 | 1.17 | -20.00 | 17.90 | 161.86 | -53.41 | 68.83 | 0.8215 | 472.8 | 999999 | |
| 0.54 | 30.18 | 0.46 | 25.42 | 16.54 | 162.37 | -52.90 | 70.35 | 0.8140 | 753.8 | 620.5 | |
| 0.00 | 1.99 | 0.00 | 1.63 | 12.94 | 163.46 | -51.82 | 74.55 | 0.7970 | 361.0 | 223.1 | |
| 0.00 | 0.91 | 0.00 | 0.77 | 16.26 | 162.33 | -52.94 | 70.71 | 0.8139 | 674.0 | 591.1 | |
| 0.00 | 0.63 | 0.00 | 0.58 | 20.33 | 160.41 | -54.86 | 66.32 | 0.8394 | 335.0 | 386.7 | |
| 4.89 | -20.00 | 4.22 | -20.00 | 17.23 | 161.83 | -53.45 | 69.64 | 0.8205 | 692.3 | 999999 | |
| 7.34 | 88.19 | 6.23 | 75.46 | 15.94 | 162.24 | -53.03 | 71.11 | 0.8141 | 757.7 | 169.3 | |
| 1.81 | -20.00 | 1.58 | -20.00 | 17.68 | 161.53 | -53.74 | 69.18 | 0.8241 | 374.5 | 999999 | |
| 4.26 | 4.89 | 3.67 | 4.21 | 16.79 | 161.79 | -53.48 | 70.19 | 0.8199 | 521.1 | 362.0 | |
| 1.00 | -30.00 | 0.85 | -30.00 | 16.22 | 161.92 | -53.35 | 70.84 | 0.8177 | 391.1 | 999999 | |
| 15.59 | -30.00 | 13.27 | -30.00 | 15.53 | 162.02 | -53.25 | 71.66 | 0.8155 | 850.9 | 999999 | |
| 1.63 | 3.44 | 1.42 | 3.00 | 17.13 | 161.33 | -53.94 | 69.88 | 0.8249 | 309.7 | 219.9 | |
| 0.00 | 1.09 | 0.00 | 0.96 | 17.22 | 160.69 | -54.59 | 69.91 | 0.8310 | 338.0 | 283.3 | |
| 0.00 | 1.09 | 0.00 | 0.98 | 18.07 | 159.96 | -55.31 | 69.06 | 0.8391 | 327.0 | 353.0 | |
| 0.00 | 2.08 | 0.00 | 1.87 | 17.21 | 160.19 | -55.08 | 70.03 | 0.8355 | 475.0 | 341.1 | |
| 0.00 | 1.00 | 0.00 | 0.89 | 16.67 | 160.37 | -54.90 | 70.62 | 0.8330 | 257.0 | 204.0 | |
| 0.00 | 0.63 | 0.00 | 0.57 | 16.95 | 160.02 | -55.25 | 70.36 | 0.8366 | 335.0 | 284.0 | |
| 0.00 | 0.91 | 0.00 | 0.86 | 14.29 | 157.69 | -57.58 | 73.89 | 0.8535 | 439.0 | 416.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
