SDO HMI 2011-06-16 21:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 136.50 | 785.18 | 103.24 | 589.58 | 16.70 | 166.30 | -46.75 | 68.45 | 0.7505 | -191.2 | -8.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-16 21:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.82 | 0.00 | 0.53 | 12.80 | 174.31 | -38.74 | 71.37 | 0.6462 | -652.0 | -529.8 | |
| 0.00 | 0.73 | 0.00 | 0.47 | 13.67 | 174.11 | -38.94 | 70.14 | 0.6516 | -647.0 | -595.2 | |
| 0.00 | 1.00 | 0.00 | 0.72 | 21.41 | 169.42 | -43.63 | 61.34 | 0.7343 | -521.0 | -461.4 | |
| 0.00 | 1.72 | 0.00 | 1.17 | 13.79 | 171.53 | -41.52 | 70.87 | 0.6837 | -641.0 | -442.6 | |
| 39.07 | 401.23 | 27.42 | 282.03 | 17.37 | 170.23 | -42.82 | 66.36 | 0.7104 | -1191.7 | -272.7 | |
| 28.37 | -5.00 | 19.88 | -5.00 | 16.67 | 170.13 | -42.92 | 67.35 | 0.7092 | -1200.2 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.83 | 14.80 | 169.45 | -43.60 | 70.14 | 0.7112 | -804.0 | -637.2 | |
| 0.00 | 0.91 | 0.00 | 0.66 | 17.31 | 168.43 | -44.62 | 67.08 | 0.7303 | 676.0 | 616.7 | |
| 0.00 | 1.27 | 0.00 | 0.93 | 18.64 | 167.82 | -45.23 | 65.55 | 0.7412 | -389.0 | -271.9 | |
| 0.00 | 0.73 | 0.00 | 0.52 | 15.26 | 168.49 | -44.56 | 69.81 | 0.7235 | -586.0 | -546.2 | |
| 0.00 | 1.45 | 0.00 | 1.03 | 14.63 | 168.61 | -44.44 | 70.62 | 0.7204 | -595.0 | -504.8 | |
| 0.00 | 1.09 | 0.00 | 0.78 | 15.03 | 168.06 | -44.99 | 70.25 | 0.7277 | -610.0 | -511.8 | |
| 0.00 | 1.09 | 0.00 | 0.78 | 14.27 | 167.82 | -45.23 | 71.34 | 0.7285 | -504.0 | -439.4 | |
| 0.00 | 0.82 | 0.00 | 0.59 | 14.49 | 167.62 | -45.43 | 71.10 | 0.7313 | -663.0 | -554.1 | |
| 0.00 | 1.09 | 0.00 | 0.83 | 18.42 | 165.51 | -47.54 | 66.61 | 0.7648 | 670.0 | 557.5 | |
| 0.00 | 2.27 | 0.00 | 1.68 | 14.19 | 166.11 | -46.94 | 71.91 | 0.7475 | -29.0 | 30.9 | |
| 0.00 | 3.35 | 0.00 | 2.53 | 14.59 | 165.49 | -47.56 | 71.55 | 0.7552 | -723.0 | -572.0 | |
| 0.00 | 4.17 | 0.00 | 3.14 | 14.27 | 165.34 | -47.71 | 72.00 | 0.7561 | 267.0 | 20.0 | |
| 0.00 | 0.36 | 0.00 | 0.27 | 13.83 | 165.09 | -47.96 | 72.63 | 0.7579 | 465.0 | 513.2 | |
| 1.72 | 75.51 | 1.32 | 58.94 | 15.14 | 164.52 | -48.53 | 71.08 | 0.7669 | -734.4 | -176.0 | |
| 0.00 | 2.81 | 0.00 | 2.20 | 16.61 | 163.99 | -49.06 | 69.34 | 0.7759 | 765.0 | 719.1 | |
| 0.00 | 11.60 | 0.00 | 8.85 | 13.76 | 164.63 | -48.41 | 72.83 | 0.7627 | 162.0 | 178.7 | |
| 7.52 | -20.00 | 5.83 | -20.00 | 15.16 | 164.08 | -48.97 | 71.16 | 0.7716 | -773.7 | 999999 | |
| 0.00 | 1.81 | 0.00 | 1.39 | 13.47 | 164.29 | -48.76 | 73.28 | 0.7658 | 246.0 | 205.8 | |
| 0.00 | 2.27 | 0.00 | 1.79 | 15.81 | 163.38 | -49.67 | 70.51 | 0.7803 | 679.0 | 539.1 | |
| 6.07 | -20.00 | 4.80 | -20.00 | 15.53 | 163.23 | -49.82 | 70.91 | 0.7812 | 702.5 | 999999 | |
| 3.90 | 104.79 | 3.20 | 85.70 | 18.40 | 162.11 | -50.94 | 67.63 | 0.7989 | 792.4 | 449.7 | |
| 1.72 | -27.00 | 1.42 | -27.00 | 18.66 | 161.90 | -51.15 | 67.37 | 0.8016 | 490.6 | 999999 | |
| 0.00 | 4.99 | 0.00 | 3.98 | 16.22 | 162.84 | -50.21 | 70.14 | 0.7867 | 762.0 | 622.7 | |
| 0.00 | 0.63 | 0.00 | 0.51 | 17.23 | 162.47 | -50.58 | 68.98 | 0.7926 | 737.0 | 651.1 | |
| 3.81 | -27.00 | 3.11 | -27.00 | 17.80 | 162.20 | -50.85 | 68.35 | 0.7966 | 945.8 | 999999 | |
| 3.08 | 28.83 | 2.49 | 23.16 | 16.85 | 162.52 | -50.53 | 69.44 | 0.7914 | 733.2 | 603.6 | |
| 1.45 | -32.00 | 1.17 | -32.00 | 16.50 | 162.39 | -50.66 | 69.90 | 0.7918 | 772.8 | 999999 | |
| 0.00 | 1.81 | 0.00 | 1.51 | 18.62 | 161.40 | -51.65 | 67.55 | 0.8063 | 369.0 | 264.5 | |
| 0.00 | 1.36 | 0.00 | 1.12 | 18.08 | 161.63 | -51.42 | 68.15 | 0.8029 | 250.0 | 181.7 | |
| 0.00 | 0.73 | 0.00 | 0.59 | 16.27 | 162.27 | -50.78 | 70.21 | 0.7926 | 706.0 | 641.0 | |
| 4.35 | 95.19 | 3.51 | 77.23 | 15.93 | 162.35 | -50.70 | 70.62 | 0.7911 | 868.9 | 275.7 | |
| 5.44 | -27.00 | 4.46 | -27.00 | 17.25 | 161.80 | -51.24 | 69.12 | 0.7993 | 721.8 | 999999 | |
| 1.99 | -27.00 | 1.65 | -27.00 | 17.69 | 161.48 | -51.57 | 68.66 | 0.8035 | 451.0 | 999999 | |
| 3.63 | 4.99 | 2.97 | 4.08 | 16.80 | 161.77 | -51.28 | 69.67 | 0.7987 | 531.2 | 450.1 | |
| 1.36 | -37.00 | 1.10 | -37.00 | 16.02 | 162.01 | -51.04 | 70.59 | 0.7946 | 518.8 | 999999 | |
| 1.81 | 2.09 | 1.48 | 1.70 | 16.23 | 161.88 | -51.17 | 70.35 | 0.7964 | 365.8 | 224.3 | |
| 15.77 | -37.00 | 12.77 | -37.00 | 15.54 | 162.08 | -50.97 | 71.16 | 0.7930 | 889.9 | 999999 | |
| 0.00 | 4.80 | 0.00 | 3.98 | 17.15 | 161.38 | -51.67 | 69.35 | 0.8032 | 316.0 | 256.6 | |
| 0.00 | 2.45 | 0.00 | 2.08 | 18.60 | 160.46 | -52.59 | 67.81 | 0.8152 | 140.0 | 217.5 | |
| 0.00 | 0.73 | 0.00 | 0.62 | 18.73 | 160.40 | -52.65 | 67.67 | 0.8160 | 405.0 | 292.4 | |
| 0.00 | 0.91 | 0.00 | 0.75 | 16.10 | 161.21 | -51.84 | 70.67 | 0.8027 | 344.0 | 256.4 | |
| 0.00 | 0.63 | 0.00 | 0.53 | 17.23 | 160.62 | -52.43 | 69.43 | 0.8108 | 366.0 | 337.9 | |
| 3.81 | 7.16 | 3.27 | 6.14 | 18.11 | 159.98 | -53.07 | 68.51 | 0.8186 | 456.3 | 292.4 | |
| 1.63 | 3.81 | 1.39 | 3.24 | 17.26 | 160.18 | -52.86 | 69.50 | 0.8150 | 398.7 | 312.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
