SDO HMI 2011-06-17 05:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 107.13 | 328.76 | 70.50 | 214.83 | -15.21 | 246.23 | 37.59 | 244.53 | 0.6537 | -0.8 | -16.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-17 05:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.54 | 0.00 | 1.07 | -13.43 | 250.95 | 42.30 | 249.26 | 0.7023 | 565.0 | 487.9 | |
| 12.34 | 22.04 | 8.59 | 15.37 | -14.57 | 250.86 | 42.22 | 247.68 | 0.7054 | 765.6 | 470.4 | |
| 0.00 | 1.00 | 0.00 | 0.70 | -15.14 | 250.92 | 42.28 | 246.92 | 0.7081 | 342.0 | 285.4 | |
| 2.09 | 11.97 | 1.45 | 8.30 | -15.13 | 250.53 | 41.89 | 246.77 | 0.7037 | 669.7 | 579.1 | |
| 4.72 | -4.00 | 3.26 | -4.00 | -15.00 | 250.20 | 41.56 | 246.81 | 0.6994 | 815.8 | 999999 | |
| 2.45 | 4.54 | 1.68 | 3.11 | -15.37 | 249.58 | 40.93 | 246.03 | 0.6937 | 794.9 | 586.2 | |
| 0.00 | 1.27 | 0.00 | 0.87 | -15.06 | 249.50 | 40.86 | 246.43 | 0.6915 | 644.0 | 565.4 | |
| 0.00 | 2.18 | 0.00 | 1.48 | -15.46 | 249.14 | 40.49 | 245.71 | 0.6890 | 466.0 | 556.9 | |
| 0.00 | 1.54 | 0.00 | 1.05 | -14.98 | 248.94 | 40.30 | 246.28 | 0.6847 | 738.0 | 611.6 | |
| 4.26 | 5.99 | 2.87 | 4.04 | -14.54 | 248.72 | 40.08 | 246.80 | 0.6803 | 582.6 | 432.8 | |
| 5.53 | 76.01 | 3.71 | 50.67 | -14.19 | 248.52 | 39.88 | 247.21 | 0.6765 | 639.7 | 514.3 | |
| 20.86 | -11.00 | 13.92 | -11.00 | -14.40 | 248.07 | 39.43 | 246.70 | 0.6721 | 939.9 | 999999 | |
| 0.00 | 0.73 | 0.00 | 0.49 | -15.26 | 248.10 | 39.45 | 245.51 | 0.6760 | 641.0 | 547.8 | |
| 0.00 | 1.27 | 0.00 | 0.85 | -15.63 | 247.77 | 39.13 | 244.83 | 0.6738 | 441.0 | 561.1 | |
| 0.00 | 1.09 | 0.00 | 0.72 | -14.61 | 247.30 | 38.66 | 246.04 | 0.6638 | 848.0 | 665.6 | |
| 2.99 | 4.17 | 1.96 | 2.73 | -13.60 | 247.06 | 38.42 | 247.39 | 0.6566 | 833.3 | 754.5 | |
| 0.00 | 2.99 | 0.00 | 1.97 | -14.80 | 247.06 | 38.42 | 245.66 | 0.6617 | 765.0 | 627.1 | |
| 3.27 | 11.88 | 2.14 | 7.77 | -13.97 | 246.81 | 38.17 | 246.72 | 0.6551 | 903.9 | 433.1 | |
| 0.00 | 2.63 | 0.00 | 1.74 | -15.81 | 246.80 | 38.15 | 244.08 | 0.6632 | -586.0 | -350.0 | |
| 0.00 | 1.00 | 0.00 | 0.65 | -14.66 | 246.35 | 37.71 | 245.50 | 0.6526 | 360.0 | 395.1 | |
| 0.00 | 2.18 | 0.00 | 1.42 | -15.17 | 246.30 | 37.65 | 244.74 | 0.6542 | -388.0 | -332.0 | |
| 0.00 | 2.27 | 0.00 | 1.48 | -14.94 | 246.21 | 37.57 | 245.02 | 0.6521 | -362.0 | -316.6 | |
| 0.00 | 1.45 | 0.00 | 0.94 | -14.87 | 245.64 | 37.00 | 244.82 | 0.6449 | -614.0 | -442.6 | |
| 2.27 | 7.62 | 1.46 | 4.91 | -14.46 | 245.48 | 36.84 | 245.34 | 0.6410 | -693.2 | -582.4 | |
| 0.00 | 1.00 | 0.00 | 0.64 | -14.74 | 245.49 | 36.85 | 244.94 | 0.6426 | -598.0 | -468.6 | |
| 0.00 | 1.54 | 0.00 | 1.00 | -16.11 | 245.50 | 36.86 | 242.96 | 0.6493 | 254.0 | 231.0 | |
| 0.00 | 0.91 | 0.00 | 0.59 | -15.79 | 245.23 | 36.59 | 243.28 | 0.6445 | -480.0 | -360.9 | |
| 0.00 | 6.71 | 0.00 | 4.30 | -15.27 | 244.77 | 36.13 | 243.77 | 0.6364 | -514.0 | -391.9 | |
| 4.26 | 26.76 | 2.75 | 17.23 | -16.01 | 244.89 | 36.24 | 242.76 | 0.6414 | -653.8 | -228.6 | |
| 7.26 | 11.70 | 4.63 | 7.47 | -15.49 | 244.39 | 35.75 | 243.23 | 0.6328 | -790.4 | -470.3 | |
| 1.54 | -29.00 | 0.99 | -29.00 | -16.16 | 244.49 | 35.84 | 242.31 | 0.6375 | -571.8 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.75 | -14.41 | 244.10 | 35.46 | 244.67 | 0.6239 | -465.0 | -459.9 | |
| 0.00 | 2.18 | 0.00 | 1.40 | -17.50 | 243.84 | 35.19 | 239.99 | 0.6370 | -634.0 | -507.7 | |
| 0.00 | 1.09 | 0.00 | 0.68 | -14.75 | 243.28 | 34.64 | 243.69 | 0.6154 | -732.0 | -518.1 | |
| 33.29 | 94.07 | 21.09 | 59.51 | -16.05 | 243.49 | 34.85 | 241.87 | 0.6249 | -869.5 | -444.8 | |
| 0.00 | 1.63 | 0.00 | 1.04 | -17.21 | 243.69 | 35.05 | 240.31 | 0.6337 | -787.0 | -721.2 | |
| 0.00 | 1.18 | 0.00 | 0.74 | -15.44 | 243.02 | 34.38 | 242.49 | 0.6159 | -547.0 | -460.7 | |
| 0.00 | 1.18 | 0.00 | 0.74 | -16.23 | 242.79 | 34.15 | 241.16 | 0.6175 | -814.0 | -723.8 | |
| 0.00 | 2.36 | 0.00 | 1.47 | -14.99 | 242.48 | 33.84 | 242.84 | 0.6068 | -783.0 | -698.2 | |
| 0.00 | 0.91 | 0.00 | 0.57 | -16.01 | 242.63 | 33.99 | 241.40 | 0.6143 | -822.0 | -707.3 | |
| 0.00 | 1.00 | 0.00 | 0.63 | -16.58 | 242.63 | 33.99 | 240.54 | 0.6176 | -648.0 | -546.6 | |
| 0.00 | 2.00 | 0.00 | 1.25 | -15.69 | 242.46 | 33.82 | 241.76 | 0.6104 | -681.0 | -654.6 | |
| 0.00 | 1.36 | 0.00 | 0.85 | -16.67 | 242.11 | 33.47 | 240.07 | 0.6119 | -462.0 | -499.8 | |
| 0.00 | 0.82 | 0.00 | 0.51 | -15.68 | 241.92 | 33.28 | 241.43 | 0.6038 | -840.0 | -662.2 | |
| 0.00 | 1.09 | 0.00 | 0.68 | -16.13 | 241.82 | 33.18 | 240.69 | 0.6051 | -705.0 | -534.3 | |
| 0.00 | 0.73 | 0.00 | 0.45 | -18.62 | 240.80 | 32.16 | 236.28 | 0.6086 | -550.0 | -404.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
