SDO HMI 2011-06-17 09:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 101.16 | 308.56 | 68.82 | 207.75 | -15.27 | 246.13 | 39.68 | 245.46 | 0.6787 | -28.2 | -64.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-17 09:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.00 | 0.00 | 0.75 | -13.53 | 253.56 | 47.10 | 250.76 | 0.7566 | 260.0 | 255.7 | |
| 0.00 | 1.54 | 0.00 | 1.12 | -15.11 | 251.25 | 44.80 | 247.94 | 0.7363 | 89.0 | 18.5 | |
| 14.88 | 18.32 | 10.77 | 13.28 | -14.50 | 251.00 | 44.55 | 248.65 | 0.7315 | 721.0 | 137.6 | |
| 0.00 | 2.00 | 0.00 | 1.45 | -15.29 | 250.85 | 44.40 | 247.55 | 0.7325 | -43.0 | -39.5 | |
| 2.00 | 15.15 | 1.44 | 10.92 | -15.03 | 250.70 | 44.25 | 247.83 | 0.7299 | 643.5 | 480.9 | |
| 3.54 | -5.00 | 2.54 | -5.00 | -15.00 | 250.38 | 43.93 | 247.76 | 0.7263 | 804.6 | 999999 | |
| 2.09 | 3.08 | 1.49 | 2.19 | -15.37 | 249.73 | 43.28 | 247.01 | 0.7204 | 726.7 | 700.2 | |
| 0.00 | 1.63 | 0.00 | 1.16 | -15.08 | 249.61 | 43.16 | 247.35 | 0.7180 | 548.0 | 474.7 | |
| 0.00 | 1.09 | 0.00 | 0.77 | -15.39 | 249.26 | 42.81 | 246.79 | 0.7152 | 634.0 | 557.8 | |
| 0.00 | 1.18 | 0.00 | 0.83 | -14.91 | 249.01 | 42.56 | 247.33 | 0.7106 | 735.0 | 528.4 | |
| 2.54 | 4.99 | 1.77 | 3.48 | -14.56 | 248.71 | 42.26 | 247.69 | 0.7059 | 567.5 | 456.2 | |
| 4.17 | 65.85 | 2.89 | 45.42 | -14.11 | 248.48 | 42.03 | 248.20 | 0.7016 | 676.5 | 514.2 | |
| 5.08 | -12.00 | 3.52 | -12.00 | -14.68 | 248.27 | 41.82 | 247.35 | 0.7012 | 683.3 | 999999 | |
| 11.97 | -12.00 | 8.25 | -12.00 | -14.36 | 248.07 | 41.62 | 247.70 | 0.6977 | 975.3 | 999999 | |
| 3.08 | 4.08 | 2.09 | 2.76 | -13.55 | 247.10 | 40.65 | 248.41 | 0.6833 | 816.1 | 685.4 | |
| 0.82 | 10.79 | 0.55 | 7.30 | -14.15 | 246.94 | 40.49 | 247.51 | 0.6837 | 809.2 | 724.9 | |
| 3.54 | -16.00 | 2.39 | -16.00 | -13.90 | 246.80 | 40.35 | 247.80 | 0.6811 | 929.0 | 999999 | |
| 1.18 | 1.63 | 0.80 | 1.11 | -14.85 | 246.92 | 40.47 | 246.53 | 0.6863 | 675.0 | 462.8 | |
| 0.00 | 0.91 | 0.00 | 0.61 | -13.67 | 246.22 | 39.77 | 247.88 | 0.6732 | 765.0 | 689.6 | |
| 0.00 | 1.54 | 0.00 | 1.05 | -15.76 | 246.64 | 40.19 | 245.14 | 0.6868 | -518.0 | -348.0 | |
| 0.00 | 2.99 | 0.00 | 2.01 | -14.90 | 246.19 | 39.74 | 246.13 | 0.6779 | -164.0 | -28.2 | |
| 0.00 | 1.54 | 0.00 | 1.03 | -14.71 | 246.07 | 39.62 | 246.34 | 0.6757 | -511.0 | -319.9 | |
| 0.00 | 0.73 | 0.00 | 0.49 | -15.09 | 246.15 | 39.70 | 245.84 | 0.6783 | -545.0 | -445.0 | |
| 0.00 | 1.72 | 0.00 | 1.15 | -14.92 | 245.79 | 39.34 | 245.90 | 0.6733 | -624.0 | -413.7 | |
| 1.36 | 3.27 | 0.92 | 2.20 | -15.88 | 245.97 | 39.51 | 244.65 | 0.6795 | 516.2 | 472.6 | |
| 5.62 | 9.25 | 3.73 | 6.14 | -14.54 | 245.42 | 38.97 | 246.27 | 0.6673 | -742.4 | -506.5 | |
| 0.00 | 1.72 | 0.00 | 1.13 | -13.68 | 245.08 | 38.63 | 247.34 | 0.6596 | -613.0 | -545.5 | |
| 0.00 | 1.00 | 0.00 | 0.67 | -16.51 | 245.21 | 38.76 | 243.40 | 0.6736 | -331.0 | -104.0 | |
| 3.08 | 7.71 | 2.05 | 5.12 | -16.06 | 244.86 | 38.41 | 243.85 | 0.6674 | -566.6 | -518.9 | |
| 1.45 | 4.26 | 0.96 | 2.81 | -15.35 | 244.62 | 38.17 | 244.72 | 0.6613 | -433.4 | -451.5 | |
| 2.00 | 4.72 | 1.33 | 3.13 | -16.60 | 244.70 | 38.25 | 243.01 | 0.6681 | -416.8 | -161.7 | |
| 0.00 | 1.72 | 0.00 | 1.13 | -15.16 | 244.26 | 37.81 | 244.82 | 0.6561 | -633.0 | -436.6 | |
| 0.00 | 1.18 | 0.00 | 0.78 | -16.05 | 244.33 | 37.88 | 243.59 | 0.6612 | -620.0 | -498.3 | |
| 2.18 | 6.35 | 1.43 | 4.16 | -15.60 | 244.20 | 37.74 | 244.15 | 0.6574 | -835.7 | -727.1 | |
| 0.00 | 1.18 | 0.00 | 0.78 | -15.92 | 244.27 | 37.81 | 243.73 | 0.6598 | -711.0 | -587.8 | |
| 1.27 | 2.90 | 0.82 | 1.88 | -14.39 | 243.90 | 37.45 | 245.74 | 0.6483 | -510.9 | -430.3 | |
| 0.82 | 9.07 | 0.54 | 5.99 | -16.14 | 244.15 | 37.70 | 243.36 | 0.6595 | -410.8 | -70.0 | |
| 0.00 | 0.82 | 0.00 | 0.54 | -16.62 | 244.14 | 37.69 | 242.68 | 0.6617 | -227.0 | -222.2 | |
| 0.00 | 1.00 | 0.00 | 0.66 | -17.36 | 244.08 | 37.62 | 241.61 | 0.6646 | -457.0 | -337.5 | |
| 0.00 | 1.27 | 0.00 | 0.82 | -14.89 | 243.53 | 37.08 | 244.82 | 0.6461 | -679.0 | -478.1 | |
| 17.42 | 89.89 | 11.37 | 58.37 | -16.07 | 243.66 | 37.21 | 243.19 | 0.6533 | -790.2 | -446.6 | |
| 0.00 | 2.45 | 0.00 | 1.61 | -17.45 | 243.78 | 37.32 | 241.31 | 0.6616 | -513.0 | -389.2 | |
| 0.00 | 2.54 | 0.00 | 1.67 | -17.22 | 243.64 | 37.19 | 241.55 | 0.6589 | -811.0 | -678.6 | |
| 1.36 | -41.00 | 0.89 | -41.00 | -16.29 | 243.31 | 36.86 | 242.69 | 0.6503 | -739.6 | 999999 | |
| 1.27 | -41.00 | 0.82 | -41.00 | -16.03 | 243.17 | 36.72 | 242.98 | 0.6474 | -980.9 | 999999 | |
| 8.44 | -41.00 | 5.46 | -41.00 | -16.16 | 242.92 | 36.47 | 242.66 | 0.6450 | -1064.7 | 999999 | |
| 0.00 | 1.72 | 0.00 | 1.10 | -14.97 | 242.48 | 36.03 | 244.13 | 0.6338 | -785.0 | -703.8 | |
| 0.00 | 1.90 | 0.00 | 1.23 | -16.63 | 242.79 | 36.34 | 241.90 | 0.6459 | -613.0 | -524.2 | |
| 0.00 | 1.00 | 0.00 | 0.64 | -16.50 | 242.60 | 36.15 | 241.97 | 0.6430 | -829.0 | -689.7 | |
| 0.00 | 0.63 | 0.00 | 0.41 | -16.02 | 242.42 | 35.97 | 242.56 | 0.6383 | -442.0 | -506.9 | |
| 0.00 | 1.36 | 0.00 | 0.87 | -16.72 | 242.10 | 35.65 | 241.36 | 0.6382 | -555.0 | -509.3 | |
| 0.00 | 1.36 | 0.00 | 0.86 | -14.99 | 241.75 | 35.30 | 243.68 | 0.6249 | -711.0 | -600.4 | |
| 0.00 | 4.90 | 0.00 | 3.13 | -16.21 | 241.95 | 35.50 | 242.02 | 0.6337 | -769.0 | -580.4 | |
| 0.00 | 1.63 | 0.00 | 1.04 | -16.39 | 241.72 | 35.27 | 241.60 | 0.6319 | -735.0 | -653.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
