SDO HMI 2011-06-30 16:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.53 | 39.68 | 5.88 | 20.22 | 14.89 | 24.83 | -5.68 | 24.44 | 0.2320 | -157.5 | -54.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-06-30 16:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.63 | 13.35 | 0.83 | 6.75 | 13.12 | 25.95 | -4.56 | 23.33 | 0.1966 | 1144.8 | 789.7 | |
| 3.09 | -1.00 | 1.56 | -1.00 | 13.21 | 25.76 | -4.75 | 23.99 | 0.1994 | 1007.6 | 999999 | |
| 0.00 | 2.27 | 0.00 | 1.16 | 15.61 | 25.55 | -4.96 | 20.56 | 0.2384 | -843.0 | -739.6 | |
| 0.00 | 1.27 | 0.00 | 0.65 | 15.54 | 24.91 | -5.60 | 23.02 | 0.2414 | -918.0 | -761.6 | |
| 0.00 | 1.82 | 0.00 | 0.93 | 15.79 | 24.49 | -6.02 | 24.11 | 0.2481 | -1053.0 | -807.7 | |
| 6.81 | 14.71 | 3.49 | 7.53 | 16.17 | 24.29 | -6.22 | 24.18 | 0.2553 | -923.0 | -724.8 | |
| 0.00 | 1.82 | 0.00 | 0.92 | 13.67 | 24.23 | -6.28 | 29.30 | 0.2180 | 784.0 | 591.3 | |
| 0.00 | 1.54 | 0.00 | 0.79 | 15.45 | 24.18 | -6.33 | 25.81 | 0.2450 | -849.0 | -746.6 | |
| 0.00 | 1.27 | 0.00 | 0.65 | 14.07 | 23.81 | -6.70 | 29.97 | 0.2275 | 779.0 | 565.4 | |
| 0.00 | 1.63 | 0.00 | 0.84 | 16.22 | 23.07 | -7.44 | 28.09 | 0.2652 | 770.0 | 578.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
