SDO HMI 2011-07-03 07:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.80 | 238.85 | 20.78 | 121.90 | 16.38 | 353.09 | -2.67 | 10.50 | 0.2399 | -133.3 | -121.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-03 07:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.36 | 0.00 | 1.25 | 23.45 | 358.96 | 3.19 | 351.65 | 0.3533 | 961.0 | 759.5 | |
| 0.00 | 1.18 | 0.00 | 0.61 | 19.88 | 358.39 | 2.63 | 351.51 | 0.2934 | -882.0 | -706.9 | |
| 0.00 | 0.82 | 0.00 | 0.42 | 19.69 | 357.71 | 1.94 | 353.62 | 0.2888 | -887.0 | -738.0 | |
| 0.00 | 1.36 | 0.00 | 0.70 | 19.56 | 357.48 | 1.72 | 354.32 | 0.2863 | -1008.0 | -815.1 | |
| 0.00 | 1.09 | 0.00 | 0.55 | 14.82 | 356.11 | 0.35 | 358.34 | 0.2043 | -945.0 | -690.9 | |
| 8.27 | 149.47 | 4.20 | 76.07 | 15.88 | 355.38 | -0.38 | 1.64 | 0.2224 | -1116.1 | -493.2 | |
| 6.81 | -6.00 | 3.47 | -6.00 | 16.10 | 355.00 | -0.76 | 3.24 | 0.2265 | -1276.9 | 999999 | |
| 20.63 | -6.00 | 10.50 | -6.00 | 16.35 | 354.56 | -1.21 | 5.03 | 0.2313 | -1230.5 | 999999 | |
| 1.73 | -6.00 | 0.88 | -6.00 | 16.60 | 354.40 | -1.37 | 5.59 | 0.2358 | -1007.9 | 999999 | |
| 0.00 | 4.45 | 0.00 | 2.26 | 15.50 | 353.96 | -1.80 | 8.02 | 0.2181 | -1168.0 | -922.7 | |
| 0.00 | 1.82 | 0.00 | 0.92 | 15.78 | 353.93 | -1.84 | 7.98 | 0.2229 | -950.0 | -738.9 | |
| 0.00 | 2.91 | 0.00 | 1.47 | 13.42 | 353.41 | -2.35 | 12.53 | 0.1845 | -1060.0 | -811.2 | |
| 0.00 | 1.73 | 0.00 | 0.87 | 13.57 | 353.19 | -2.57 | 13.47 | 0.1880 | -910.0 | -675.0 | |
| 0.00 | 2.73 | 0.00 | 1.39 | 16.53 | 353.09 | -2.67 | 10.87 | 0.2378 | -839.0 | -739.2 | |
| 0.00 | 1.54 | 0.00 | 0.79 | 17.32 | 352.67 | -3.10 | 11.85 | 0.2523 | -1025.0 | -822.5 | |
| 0.00 | 2.18 | 0.00 | 1.13 | 19.21 | 351.92 | -3.84 | 12.83 | 0.2861 | -1036.0 | -786.4 | |
| 0.00 | 1.18 | 0.00 | 0.62 | 20.74 | 351.39 | -4.37 | 13.22 | 0.3129 | -705.0 | -584.7 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 15.74 | 350.72 | -5.04 | 21.09 | 0.2360 | 906.0 | 765.9 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 15.05 | 350.39 | -5.37 | 23.54 | 0.2274 | 657.0 | 698.3 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 15.43 | 350.00 | -5.76 | 24.34 | 0.2358 | 1050.0 | 837.8 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 15.64 | 349.87 | -5.90 | 24.44 | 0.2401 | 818.0 | 621.8 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 15.21 | 349.78 | -5.98 | 25.55 | 0.2340 | 984.0 | 707.1 | |
| 0.00 | 1.64 | 0.00 | 0.83 | 15.49 | 349.52 | -6.24 | 25.98 | 0.2402 | 1056.0 | 884.1 | |
| 0.00 | 1.27 | 0.00 | 0.65 | 15.77 | 349.45 | -6.31 | 25.71 | 0.2450 | 929.0 | 822.9 | |
| 0.00 | 1.54 | 0.00 | 0.79 | 16.92 | 349.38 | -6.38 | 23.95 | 0.2632 | 777.0 | 629.2 | |
| 0.00 | 2.36 | 0.00 | 1.20 | 14.89 | 349.41 | -6.35 | 27.55 | 0.2321 | 960.0 | 785.4 | |
| 0.00 | 4.45 | 0.00 | 2.27 | 15.42 | 349.30 | -6.46 | 26.89 | 0.2409 | 993.0 | 942.4 | |
| 0.00 | 1.27 | 0.00 | 0.65 | 15.76 | 349.29 | -6.47 | 26.27 | 0.2462 | 950.0 | 735.8 | |
| 0.00 | 5.45 | 0.00 | 2.80 | 16.92 | 349.16 | -6.61 | 24.69 | 0.2647 | 547.0 | 892.0 | |
| 1.09 | 1.45 | 0.56 | 0.74 | 15.89 | 349.06 | -6.70 | 26.82 | 0.2498 | 967.3 | 930.0 | |
| 0.00 | 7.45 | 0.00 | 3.82 | 16.58 | 348.98 | -6.79 | 25.87 | 0.2608 | 987.0 | 850.3 | |
| 0.00 | 2.00 | 0.00 | 1.02 | 15.70 | 348.94 | -6.82 | 27.60 | 0.2479 | 1036.0 | 893.2 | |
| 0.00 | 1.82 | 0.00 | 0.93 | 16.61 | 348.62 | -7.14 | 26.97 | 0.2639 | 973.0 | 855.5 | |
| 0.00 | 2.36 | 0.00 | 1.21 | 16.82 | 348.49 | -7.28 | 27.01 | 0.2682 | 983.0 | 707.3 | |
| 0.00 | 2.45 | 0.00 | 1.26 | 15.85 | 348.52 | -7.24 | 28.71 | 0.2535 | 738.0 | 712.6 | |
| 0.00 | 3.09 | 0.00 | 1.59 | 16.95 | 348.32 | -7.44 | 27.31 | 0.2713 | 704.0 | 637.6 | |
| 0.00 | 0.73 | 0.00 | 0.37 | 16.66 | 347.82 | -7.95 | 29.38 | 0.2711 | 927.0 | 683.5 | |
| 0.00 | 1.18 | 0.00 | 0.61 | 17.04 | 347.54 | -8.22 | 29.50 | 0.2788 | 1171.0 | 937.2 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 17.23 | 347.50 | -8.26 | 29.27 | 0.2819 | 845.0 | 732.0 | |
| 0.00 | 1.00 | 0.00 | 0.52 | 17.95 | 347.44 | -8.33 | 28.19 | 0.2929 | 889.0 | 676.6 | |
| 0.00 | 4.18 | 0.00 | 2.15 | 16.79 | 347.46 | -8.30 | 30.23 | 0.2759 | 881.0 | 786.2 | |
| 2.27 | 3.18 | 1.17 | 1.64 | 16.44 | 347.38 | -8.39 | 31.14 | 0.2717 | 957.6 | 826.4 | |
| 0.00 | 2.00 | 0.00 | 1.04 | 18.64 | 347.21 | -8.55 | 27.68 | 0.3048 | 707.0 | 581.2 | |
| 0.00 | 1.36 | 0.00 | 0.71 | 18.26 | 347.20 | -8.57 | 28.34 | 0.2994 | 884.0 | 722.6 | |
| 0.00 | 2.45 | 0.00 | 1.27 | 17.63 | 346.55 | -9.22 | 31.23 | 0.2957 | 585.0 | 525.9 | |
| 0.00 | 1.64 | 0.00 | 0.85 | 16.45 | 345.35 | -10.42 | 36.77 | 0.2909 | 681.0 | 467.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
