SDO HMI 2011-07-03 19:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 84.71 | 220.53 | 53.49 | 139.39 | 16.11 | 25.92 | 36.79 | 292.26 | 0.6238 | -169.9 | -209.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-03 19:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.09 | 0.00 | 2.67 | 16.26 | 28.23 | 39.09 | 291.54 | 0.6531 | -435.0 | -439.4 | |
| 0.00 | 1.45 | 0.00 | 0.95 | 16.64 | 28.07 | 38.94 | 292.17 | 0.6525 | -614.0 | -452.6 | |
| 0.00 | 1.82 | 0.00 | 1.18 | 16.27 | 27.70 | 38.56 | 291.77 | 0.6466 | -604.0 | -468.9 | |
| 12.26 | 80.90 | 7.85 | 51.77 | 15.48 | 27.03 | 37.90 | 290.82 | 0.6356 | -1061.0 | -544.7 | |
| 12.26 | -4.00 | 7.87 | -4.00 | 15.98 | 27.14 | 38.01 | 291.54 | 0.6387 | -898.9 | 999999 | |
| 1.73 | 34.59 | 1.10 | 22.06 | 16.50 | 26.70 | 37.56 | 292.50 | 0.6350 | -707.3 | -280.0 | |
| 0.00 | 0.91 | 0.00 | 0.57 | 13.11 | 25.98 | 36.84 | 287.50 | 0.6145 | 654.0 | 523.5 | |
| 13.71 | 18.61 | 8.68 | 11.79 | 15.03 | 26.30 | 37.17 | 290.41 | 0.6248 | -905.1 | -720.5 | |
| 12.35 | -6.00 | 7.89 | -6.00 | 16.88 | 26.47 | 37.33 | 293.19 | 0.6335 | -747.2 | 999999 | |
| 0.00 | 2.54 | 0.00 | 1.59 | 14.49 | 25.72 | 36.58 | 289.78 | 0.6155 | -721.0 | -575.4 | |
| 1.27 | 2.09 | 0.80 | 1.31 | 15.77 | 25.66 | 36.53 | 291.82 | 0.6192 | 369.1 | 306.7 | |
| 0.45 | 1.91 | 0.29 | 1.20 | 16.02 | 25.72 | 36.58 | 292.19 | 0.6208 | 652.4 | 432.9 | |
| 1.27 | 29.96 | 0.79 | 18.65 | 16.31 | 24.71 | 35.58 | 293.07 | 0.6092 | 652.4 | 325.4 | |
| 16.89 | -13.00 | 10.52 | -13.00 | 16.63 | 24.55 | 35.41 | 293.65 | 0.6083 | 867.7 | 999999 | |
| 1.54 | 10.44 | 0.97 | 6.51 | 17.35 | 24.70 | 35.57 | 294.71 | 0.6134 | 442.3 | 612.9 | |
| 0.00 | 0.91 | 0.00 | 0.56 | 16.03 | 24.42 | 35.29 | 292.77 | 0.6043 | 599.0 | 398.3 | |
| 0.00 | 1.00 | 0.00 | 0.62 | 16.32 | 24.13 | 35.00 | 293.37 | 0.6018 | 237.0 | 218.7 | |
| 0.00 | 1.18 | 0.00 | 0.74 | 17.61 | 24.37 | 35.23 | 295.28 | 0.6103 | 662.0 | 546.1 | |
| 0.00 | 2.45 | 0.00 | 1.52 | 17.20 | 24.20 | 35.07 | 294.73 | 0.6064 | 730.0 | 726.8 | |
| 1.45 | -13.00 | 0.90 | -13.00 | 16.74 | 23.98 | 34.85 | 294.10 | 0.6017 | -633.4 | 999999 | |
| 0.45 | -15.00 | 0.28 | -15.00 | 17.46 | 24.14 | 35.00 | 295.16 | 0.6068 | 815.0 | 999999 | |
| 0.00 | 2.81 | 0.00 | 1.73 | 16.72 | 23.44 | 34.30 | 294.35 | 0.5946 | -728.0 | -547.9 | |
| 9.08 | 17.43 | 5.55 | 10.65 | 15.85 | 23.15 | 34.02 | 293.08 | 0.5871 | 836.5 | 348.8 | |
| 0.00 | 1.54 | 0.00 | 0.95 | 16.38 | 23.25 | 34.12 | 293.89 | 0.5908 | 726.0 | 557.8 | |
| 0.00 | 2.27 | 0.00 | 1.39 | 16.42 | 22.96 | 33.82 | 294.11 | 0.5871 | 795.0 | 529.6 | |
| 0.00 | 1.63 | 0.00 | 0.98 | 16.45 | 20.99 | 31.85 | 295.22 | 0.5616 | 670.0 | 495.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
