SDO HMI 2011-07-04 07:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 37.36 | 205.41 | 19.44 | 106.93 | 16.68 | 354.20 | 11.67 | 320.76 | 0.3070 | -497.3 | -347.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-04 07:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.18 | 0.00 | 0.63 | 16.96 | 359.04 | 16.52 | 311.44 | 0.3643 | -654.0 | -472.7 | |
| 0.00 | 1.36 | 0.00 | 0.73 | 20.22 | 358.59 | 16.07 | 318.63 | 0.3946 | -705.0 | -531.7 | |
| 0.00 | 0.64 | 0.00 | 0.34 | 17.73 | 358.12 | 15.59 | 314.65 | 0.3613 | -306.0 | -249.7 | |
| 6.09 | 166.92 | 3.17 | 86.99 | 16.16 | 355.30 | 12.77 | 316.75 | 0.3112 | -1150.2 | -456.3 | |
| 23.90 | -4.00 | 12.46 | -4.00 | 16.54 | 355.00 | 12.47 | 318.27 | 0.3123 | -1343.5 | 999999 | |
| 2.91 | -4.00 | 1.51 | -4.00 | 16.58 | 354.51 | 11.98 | 319.45 | 0.3074 | -1256.6 | 999999 | |
| 1.82 | -4.00 | 0.95 | -4.00 | 16.83 | 354.40 | 11.87 | 320.26 | 0.3093 | -579.3 | 999999 | |
| 0.00 | 2.27 | 0.00 | 1.18 | 16.36 | 354.14 | 11.61 | 319.83 | 0.3008 | -799.0 | -593.6 | |
| 0.00 | 1.27 | 0.00 | 0.66 | 16.08 | 354.09 | 11.56 | 319.31 | 0.2968 | -919.0 | -794.1 | |
| 0.00 | 1.36 | 0.00 | 0.72 | 20.09 | 353.97 | 11.44 | 327.44 | 0.3475 | -779.0 | -587.3 | |
| 0.00 | 1.54 | 0.00 | 0.81 | 19.46 | 353.36 | 10.83 | 327.76 | 0.3337 | -955.0 | -799.4 | |
| 0.00 | 1.18 | 0.00 | 0.62 | 18.46 | 352.18 | 9.66 | 328.92 | 0.3096 | -823.0 | -569.7 | |
| 0.00 | 1.27 | 0.00 | 0.66 | 19.70 | 351.04 | 8.52 | 333.91 | 0.3184 | -884.0 | -675.7 | |
| 0.00 | 3.18 | 0.00 | 1.66 | 19.96 | 350.83 | 8.30 | 334.84 | 0.3206 | -846.0 | -710.0 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 19.71 | 350.78 | 8.26 | 334.60 | 0.3166 | -825.0 | -576.2 | |
| 0.00 | 0.82 | 0.00 | 0.42 | 15.49 | 350.30 | 7.78 | 328.58 | 0.2512 | 701.0 | 551.2 | |
| 0.00 | 2.00 | 0.00 | 1.02 | 15.74 | 349.99 | 7.47 | 330.12 | 0.2522 | 1053.0 | 752.8 | |
| 0.00 | 1.18 | 0.00 | 0.62 | 19.87 | 350.04 | 7.51 | 336.84 | 0.3139 | -794.0 | -662.4 | |
| 0.00 | 1.54 | 0.00 | 0.79 | 14.78 | 349.83 | 7.30 | 328.57 | 0.2368 | 839.0 | 576.4 | |
| 0.00 | 1.54 | 0.00 | 0.79 | 15.96 | 349.75 | 7.22 | 331.38 | 0.2533 | 1076.0 | 931.0 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 16.22 | 348.83 | 6.30 | 334.97 | 0.2502 | 887.0 | 754.3 | |
| 2.64 | 4.18 | 1.35 | 2.14 | 16.82 | 348.69 | 6.16 | 336.46 | 0.2583 | 1008.6 | 808.4 | |
| 0.00 | 1.27 | 0.00 | 0.65 | 16.85 | 348.21 | 5.68 | 338.15 | 0.2557 | 1187.0 | 957.4 | |
| 0.00 | 1.54 | 0.00 | 0.79 | 17.04 | 347.96 | 5.43 | 339.30 | 0.2571 | 743.0 | 663.9 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 16.54 | 347.75 | 5.23 | 339.29 | 0.2480 | 843.0 | 594.1 | |
| 0.00 | 2.18 | 0.00 | 1.12 | 18.21 | 347.32 | 4.79 | 342.98 | 0.2722 | 613.0 | 606.7 | |
| 0.00 | 1.54 | 0.00 | 0.78 | 13.24 | 346.92 | 4.39 | 336.88 | 0.1907 | 931.0 | 784.2 | |
| 0.00 | 1.82 | 0.00 | 0.94 | 18.30 | 346.77 | 4.25 | 344.92 | 0.2713 | 783.0 | 675.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
