SDO HMI 2011-07-05 22:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.71 | 66.94 | 17.74 | 81.38 | 15.41 | 26.88 | 65.88 | 285.40 | 0.9140 | -177.6 | -98.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-05 22:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.90 | 51.22 | 13.64 | 64.37 | 15.27 | 27.76 | 66.76 | 285.19 | 0.9202 | -626.4 | -190.9 | |
| 0.00 | 0.91 | 0.00 | 1.07 | 13.97 | 26.14 | 65.14 | 283.85 | 0.9086 | -312.0 | -307.5 | |
| 0.00 | 0.91 | 0.00 | 1.00 | 16.12 | 24.12 | 63.12 | 286.37 | 0.8950 | 150.0 | 92.7 | |
| 0.00 | 2.00 | 0.00 | 2.17 | 16.24 | 23.63 | 62.63 | 286.55 | 0.8913 | 236.0 | 197.7 | |
| 0.00 | 0.91 | 0.00 | 0.97 | 15.75 | 23.29 | 62.29 | 286.03 | 0.8884 | 481.0 | 409.3 | |
| 3.81 | 8.08 | 4.10 | 8.72 | 16.03 | 23.37 | 62.37 | 286.34 | 0.8892 | 604.9 | 249.5 | |
| 0.00 | 1.91 | 0.00 | 2.02 | 15.96 | 22.99 | 61.99 | 286.29 | 0.8862 | 655.0 | 531.7 | |
| 0.00 | 1.00 | 0.00 | 1.06 | 16.27 | 23.09 | 62.09 | 286.63 | 0.8872 | 638.0 | 575.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
