SDO HMI 2011-07-07 18:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.41 | 128.57 | 33.73 | 121.78 | 17.23 | 354.70 | 57.95 | 288.10 | 0.8532 | -311.6 | -123.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-07 18:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.27 | 0.00 | 0.28 | 17.74 | 357.30 | 60.55 | 288.35 | 0.8758 | -367.0 | -351.0 | |
| 14.62 | 77.62 | 14.19 | 75.16 | 16.90 | 355.70 | 58.95 | 287.58 | 0.8618 | -557.8 | -99.1 | |
| 0.00 | 0.45 | 0.00 | 0.44 | 18.13 | 355.85 | 59.10 | 288.98 | 0.8643 | -282.0 | -247.0 | |
| 2.81 | -2.00 | 2.69 | -2.00 | 17.03 | 355.08 | 58.33 | 287.80 | 0.8567 | -719.4 | 999999 | |
| 0.82 | -2.00 | 0.78 | -2.00 | 17.38 | 355.02 | 58.27 | 288.22 | 0.8565 | -558.3 | 999999 | |
| 1.82 | 3.36 | 1.71 | 3.17 | 16.89 | 354.71 | 57.96 | 287.68 | 0.8534 | -690.5 | -529.1 | |
| 0.82 | 2.18 | 0.78 | 2.09 | 17.72 | 355.13 | 58.38 | 288.60 | 0.8579 | -337.2 | -282.1 | |
| 1.18 | -2.00 | 1.12 | -2.00 | 17.24 | 354.70 | 57.95 | 288.09 | 0.8537 | -513.4 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.85 | 16.71 | 354.44 | 57.69 | 287.51 | 0.8509 | -587.0 | -518.3 | |
| 0.00 | 1.18 | 0.00 | 1.14 | 18.57 | 355.40 | 58.65 | 289.54 | 0.8611 | -580.0 | -412.4 | |
| 2.00 | 2.72 | 1.89 | 2.58 | 17.61 | 354.77 | 58.02 | 288.52 | 0.8547 | -540.1 | -499.2 | |
| 0.00 | 1.45 | 0.00 | 1.35 | 16.85 | 354.21 | 57.46 | 287.70 | 0.8490 | -643.0 | -570.4 | |
| 3.99 | 5.54 | 3.83 | 5.31 | 18.88 | 355.02 | 58.27 | 289.95 | 0.8582 | 433.8 | 146.9 | |
| 4.36 | 12.26 | 4.15 | 11.67 | 18.47 | 354.79 | 58.04 | 289.52 | 0.8558 | -445.2 | -375.6 | |
| 0.00 | 0.91 | 0.00 | 0.84 | 16.77 | 353.88 | 57.13 | 287.65 | 0.8460 | -659.0 | -572.3 | |
| 0.00 | 1.09 | 0.00 | 1.02 | 18.60 | 354.14 | 57.39 | 289.76 | 0.8503 | 386.0 | 356.7 | |
| 1.72 | 3.09 | 1.54 | 2.77 | 16.26 | 352.72 | 55.97 | 287.20 | 0.8349 | -607.1 | -493.1 | |
| 0.00 | 0.82 | 0.00 | 0.73 | 16.46 | 352.63 | 55.88 | 287.45 | 0.8343 | -650.0 | -587.9 | |
| 0.00 | 1.91 | 0.00 | 1.71 | 16.71 | 352.63 | 55.88 | 287.75 | 0.8346 | -569.0 | -484.0 | |
| 0.00 | 0.73 | 0.00 | 0.67 | 21.66 | 352.87 | 56.12 | 293.55 | 0.8438 | -465.0 | -372.9 | |
| 0.00 | 0.91 | 0.00 | 0.77 | 16.66 | 350.33 | 53.58 | 288.04 | 0.8130 | 251.0 | 232.4 | |
| 0.00 | 1.36 | 0.00 | 1.15 | 16.86 | 350.20 | 53.45 | 288.30 | 0.8119 | 290.0 | 226.1 | |
| 0.00 | 1.00 | 0.00 | 0.83 | 15.54 | 349.42 | 52.67 | 286.80 | 0.8025 | 483.0 | 313.1 | |
| 0.00 | 3.54 | 0.00 | 2.95 | 16.98 | 349.61 | 52.86 | 288.55 | 0.8064 | 353.0 | 315.5 | |
| 0.00 | 1.09 | 0.00 | 0.90 | 16.18 | 349.14 | 52.39 | 287.65 | 0.8005 | 279.0 | 343.8 | |
| 1.27 | 2.09 | 1.05 | 1.72 | 16.72 | 349.13 | 52.38 | 288.31 | 0.8013 | 547.9 | 528.1 | |
| 0.00 | 1.18 | 0.00 | 0.97 | 16.51 | 348.90 | 52.15 | 288.09 | 0.7986 | 597.0 | 485.3 | |
| 0.00 | 0.91 | 0.00 | 0.71 | 18.87 | 345.91 | 49.16 | 291.68 | 0.7726 | 226.0 | 261.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
