SDO HMI 2011-07-08 12:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.44 | 54.04 | 14.10 | 73.36 | 17.13 | 355.27 | 68.43 | 287.01 | 0.9309 | -429.8 | -10.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-08 12:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.44 | 40.51 | 14.10 | 55.57 | 16.93 | 355.44 | 68.60 | 286.78 | 0.9319 | -483.0 | 112.1 | |
| 0.00 | 1.73 | 0.00 | 2.23 | 16.42 | 354.45 | 67.61 | 286.27 | 0.9256 | -516.0 | -395.5 | |
| 0.00 | 1.00 | 0.00 | 1.34 | 17.51 | 355.29 | 68.45 | 287.41 | 0.9311 | -166.0 | -167.8 | |
| 0.00 | 0.82 | 0.00 | 1.09 | 17.39 | 355.11 | 68.27 | 287.29 | 0.9300 | -400.0 | -352.2 | |
| 0.00 | 1.63 | 0.00 | 2.16 | 17.57 | 354.90 | 68.05 | 287.49 | 0.9287 | -436.0 | -397.4 | |
| 0.00 | 2.72 | 0.00 | 3.66 | 18.28 | 355.22 | 68.38 | 288.24 | 0.9310 | -589.0 | -457.1 | |
| 0.00 | 1.82 | 0.00 | 2.45 | 18.76 | 355.27 | 68.43 | 288.75 | 0.9315 | 134.0 | 70.0 | |
| 0.00 | 2.54 | 0.00 | 3.34 | 18.38 | 354.69 | 67.85 | 288.38 | 0.9278 | -333.0 | -269.7 | |
| 0.00 | 1.27 | 0.00 | 1.52 | 16.40 | 352.42 | 65.58 | 286.38 | 0.9121 | -383.0 | -332.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
