SDO HMI 2011-07-16 10:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.52 | 84.45 | 18.64 | 66.67 | -22.76 | 137.74 | -44.33 | 124.18 | 0.7800 | -101.6 | -136.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-16 10:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.73 | 0.00 | 1.24 | -21.79 | 142.81 | -39.26 | 125.92 | 0.7278 | 680.0 | 604.1 | |
| 5.36 | 14.62 | 3.98 | 10.84 | -22.75 | 141.36 | -40.71 | 126.16 | 0.7472 | 776.6 | 693.0 | |
| 0.00 | 2.18 | 0.00 | 1.63 | -22.77 | 141.00 | -41.07 | 125.96 | 0.7507 | 530.0 | 368.7 | |
| 4.90 | 10.80 | 3.68 | 8.12 | -22.10 | 140.28 | -41.79 | 124.75 | 0.7538 | 744.8 | 542.3 | |
| 0.00 | 0.54 | 0.00 | 0.41 | -21.46 | 140.20 | -41.87 | 123.95 | 0.7512 | 591.0 | 596.5 | |
| 0.00 | 0.82 | 0.00 | 0.62 | -21.98 | 139.34 | -42.73 | 124.08 | 0.7620 | 253.0 | 220.2 | |
| 0.00 | 1.18 | 0.00 | 0.90 | -22.16 | 139.18 | -42.89 | 124.20 | 0.7644 | 280.0 | 178.8 | |
| 0.45 | 3.18 | 0.35 | 2.47 | -22.43 | 138.53 | -43.54 | 124.16 | 0.7718 | -41.6 | 148.9 | |
| 0.00 | 1.36 | 0.00 | 1.07 | -23.23 | 138.21 | -43.86 | 124.91 | 0.7787 | -592.0 | -464.6 | |
| 0.00 | 0.91 | 0.00 | 0.70 | -21.84 | 138.26 | -43.81 | 123.33 | 0.7713 | -255.0 | -211.1 | |
| 0.00 | 2.36 | 0.00 | 1.85 | -22.07 | 137.71 | -44.36 | 123.31 | 0.7775 | -766.0 | -594.3 | |
| 0.00 | 3.99 | 0.00 | 3.16 | -22.39 | 137.49 | -44.58 | 123.56 | 0.7811 | -601.0 | -522.7 | |
| 0.00 | 1.00 | 0.00 | 0.81 | -23.25 | 136.65 | -45.42 | 124.12 | 0.7926 | 325.0 | 153.9 | |
| 2.91 | 3.63 | 2.32 | 2.89 | -22.38 | 136.98 | -45.09 | 123.29 | 0.7857 | -748.7 | -549.4 | |
| 0.00 | 2.63 | 0.00 | 2.11 | -22.60 | 136.70 | -45.37 | 123.40 | 0.7892 | -744.0 | -697.9 | |
| 0.00 | 6.63 | 0.00 | 5.36 | -22.69 | 136.38 | -45.69 | 123.34 | 0.7925 | -731.0 | -598.4 | |
| 1.82 | 3.00 | 1.48 | 2.44 | -22.85 | 135.97 | -46.10 | 123.32 | 0.7968 | -576.6 | -497.5 | |
| 1.63 | 5.36 | 1.34 | 4.39 | -22.93 | 135.70 | -46.37 | 123.28 | 0.7996 | -545.4 | -547.7 | |
| 0.00 | 1.91 | 0.00 | 1.58 | -23.05 | 135.40 | -46.67 | 123.27 | 0.8027 | -620.0 | -503.7 | |
| 0.00 | 2.81 | 0.00 | 2.37 | -23.84 | 134.79 | -47.28 | 123.86 | 0.8114 | -661.0 | -547.7 | |
| 3.36 | 7.63 | 2.81 | 6.37 | -23.22 | 134.93 | -47.13 | 123.23 | 0.8075 | -650.1 | -656.7 | |
| 0.00 | 0.82 | 0.00 | 0.71 | -24.69 | 133.76 | -48.31 | 124.32 | 0.8236 | -311.0 | -299.1 | |
| 0.00 | 1.00 | 0.00 | 0.85 | -23.39 | 134.36 | -47.71 | 123.15 | 0.8131 | -555.0 | -475.4 | |
| 3.09 | 4.36 | 2.68 | 3.78 | -23.82 | 133.34 | -48.73 | 123.17 | 0.8235 | -399.4 | -428.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
