SDO HMI 2011-07-20 19:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 99.39 | 429.95 | 56.89 | 246.03 | -22.66 | 136.13 | 11.98 | 202.50 | 0.5013 | -64.5 | -189.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-20 19:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.74 | -22.05 | 142.40 | 18.24 | 212.92 | 0.5358 | 737.0 | 677.5 | |
| 0.00 | 1.54 | 0.00 | 0.90 | -22.28 | 142.05 | 17.89 | 212.17 | 0.5358 | 884.0 | 773.2 | |
| 0.00 | 1.09 | 0.00 | 0.64 | -22.07 | 141.98 | 17.83 | 212.31 | 0.5328 | 593.0 | 549.2 | |
| 0.00 | 1.72 | 0.00 | 1.02 | -23.03 | 142.01 | 17.85 | 211.33 | 0.5447 | 608.0 | 467.9 | |
| 0.00 | 1.36 | 0.00 | 0.80 | -22.62 | 141.85 | 17.69 | 211.54 | 0.5384 | 679.0 | 490.8 | |
| 0.00 | 1.18 | 0.00 | 0.69 | -22.10 | 141.75 | 17.59 | 211.94 | 0.5313 | 663.0 | 530.0 | |
| 0.00 | 3.90 | 0.00 | 2.28 | -22.37 | 141.64 | 17.48 | 211.50 | 0.5338 | 785.0 | 676.2 | |
| 0.00 | 1.09 | 0.00 | 0.64 | -22.40 | 141.34 | 17.18 | 211.03 | 0.5318 | 605.0 | 609.7 | |
| 0.00 | 1.72 | 0.00 | 1.00 | -22.26 | 141.22 | 17.06 | 211.00 | 0.5291 | 827.0 | 642.5 | |
| 0.00 | 1.36 | 0.00 | 0.79 | -22.53 | 141.18 | 17.02 | 210.67 | 0.5322 | 640.0 | 521.0 | |
| 0.00 | 4.08 | 0.00 | 2.38 | -22.35 | 140.92 | 16.76 | 210.46 | 0.5280 | 828.0 | 700.3 | |
| 0.00 | 1.18 | 0.00 | 0.69 | -22.38 | 140.54 | 16.38 | 209.88 | 0.5255 | 755.0 | 624.8 | |
| 1.36 | 2.18 | 0.79 | 1.27 | -22.61 | 140.47 | 16.31 | 209.53 | 0.5280 | 664.5 | 552.7 | |
| 0.00 | 1.36 | 0.00 | 0.79 | -21.89 | 140.18 | 16.02 | 209.83 | 0.5167 | 200.0 | 225.1 | |
| 0.00 | 2.54 | 0.00 | 1.49 | -23.71 | 140.36 | 16.21 | 208.29 | 0.5411 | 713.0 | 548.8 | |
| 2.54 | 38.36 | 1.48 | 22.23 | -22.64 | 140.13 | 15.97 | 209.00 | 0.5259 | 729.6 | 647.8 | |
| 15.96 | -16.00 | 9.24 | -16.00 | -22.22 | 139.98 | 15.82 | 209.18 | 0.5195 | 1064.9 | 999999 | |
| 0.00 | 1.72 | 0.00 | 1.01 | -23.57 | 140.14 | 15.98 | 208.10 | 0.5377 | 698.0 | 601.5 | |
| 1.45 | -16.00 | 0.84 | -16.00 | -22.53 | 139.81 | 15.65 | 208.62 | 0.5221 | 890.4 | 999999 | |
| 0.00 | 5.80 | 0.00 | 3.40 | -23.59 | 139.73 | 15.57 | 207.47 | 0.5352 | 646.0 | 663.2 | |
| 6.62 | 12.97 | 3.85 | 7.54 | -22.83 | 139.57 | 15.41 | 207.96 | 0.5243 | 938.1 | 584.7 | |
| 5.44 | 12.70 | 3.13 | 7.31 | -21.87 | 139.25 | 15.09 | 208.43 | 0.5097 | 1001.4 | 706.6 | |
| 0.00 | 1.27 | 0.00 | 0.72 | -19.96 | 138.72 | 14.56 | 209.56 | 0.4809 | 888.0 | 785.1 | |
| 0.00 | 1.63 | 0.00 | 0.93 | -21.11 | 138.77 | 14.61 | 208.42 | 0.4963 | 838.0 | 697.2 | |
| 0.00 | 1.36 | 0.00 | 0.78 | -22.23 | 138.85 | 14.69 | 207.43 | 0.5116 | 714.0 | 557.7 | |
| 1.00 | 2.36 | 0.57 | 1.35 | -22.02 | 138.62 | 14.47 | 207.28 | 0.5073 | 883.7 | 731.4 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -20.79 | 138.40 | 14.24 | 208.14 | 0.4895 | 925.0 | 835.9 | |
| 0.00 | 1.72 | 0.00 | 1.00 | -22.91 | 138.62 | 14.46 | 206.42 | 0.5189 | 836.0 | 673.7 | |
| 1.81 | 2.45 | 1.04 | 1.41 | -22.22 | 138.24 | 14.08 | 206.47 | 0.5072 | 885.3 | 845.4 | |
| 0.00 | 2.18 | 0.00 | 1.29 | -25.17 | 138.36 | 14.20 | 204.05 | 0.5469 | 638.0 | 545.1 | |
| 0.00 | 1.18 | 0.00 | 0.68 | -22.93 | 138.01 | 13.85 | 205.43 | 0.5152 | 754.0 | 540.9 | |
| 0.00 | 1.09 | 0.00 | 0.64 | -24.53 | 138.18 | 14.02 | 204.31 | 0.5375 | 730.0 | 516.2 | |
| 2.36 | 2.63 | 1.35 | 1.51 | -22.62 | 137.57 | 13.41 | 205.02 | 0.5081 | 797.8 | 717.5 | |
| 0.00 | 2.00 | 0.00 | 1.16 | -23.79 | 137.51 | 13.36 | 203.91 | 0.5236 | 857.0 | 750.2 | |
| 0.00 | 4.81 | 0.00 | 2.79 | -24.02 | 137.16 | 13.00 | 203.16 | 0.5246 | 711.0 | 638.4 | |
| 0.00 | 5.17 | 0.00 | 2.94 | -21.84 | 136.41 | 12.25 | 203.79 | 0.4904 | -219.0 | -295.5 | |
| 0.00 | 3.36 | 0.00 | 1.91 | -22.11 | 136.27 | 12.11 | 203.30 | 0.4932 | -191.0 | -295.6 | |
| 4.08 | 11.43 | 2.35 | 6.58 | -23.44 | 135.91 | 11.76 | 201.61 | 0.5096 | -706.5 | -263.5 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -21.45 | 135.58 | 11.42 | 202.67 | 0.4799 | 333.0 | 162.5 | |
| 3.81 | 214.83 | 2.16 | 121.97 | -22.03 | 135.39 | 11.23 | 201.85 | 0.4869 | -909.4 | -462.9 | |
| 1.63 | -40.00 | 0.93 | -40.00 | -22.50 | 135.33 | 11.17 | 201.36 | 0.4933 | -659.1 | 999999 | |
| 0.45 | 3.81 | 0.26 | 2.19 | -23.92 | 135.45 | 11.29 | 200.47 | 0.5137 | -529.2 | -693.6 | |
| 0.00 | 1.63 | 0.00 | 0.94 | -24.19 | 135.03 | 10.87 | 199.58 | 0.5154 | -620.0 | -531.2 | |
| 27.75 | -40.00 | 15.74 | -40.00 | -22.36 | 134.84 | 10.69 | 200.63 | 0.4886 | -1302.7 | 999999 | |
| 1.18 | 11.70 | 0.68 | 6.74 | -23.84 | 134.90 | 10.74 | 199.61 | 0.5098 | -906.8 | -760.7 | |
| 0.73 | -45.00 | 0.42 | -45.00 | -24.36 | 134.57 | 10.41 | 198.70 | 0.5154 | -683.8 | 999999 | |
| 9.70 | -40.00 | 5.52 | -40.00 | -22.76 | 134.41 | 10.25 | 199.56 | 0.4921 | -1006.8 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.63 | -24.46 | 134.34 | 10.18 | 198.25 | 0.5158 | -471.0 | -433.9 | |
| 0.00 | 1.72 | 0.00 | 0.99 | -23.69 | 133.84 | 9.68 | 197.92 | 0.5025 | -596.0 | -441.0 | |
| 11.52 | 36.09 | 6.54 | 20.50 | -22.96 | 133.68 | 9.52 | 198.14 | 0.4913 | -1121.4 | -626.5 | |
| 0.00 | 1.72 | 0.00 | 0.99 | -24.18 | 131.91 | 7.76 | 194.27 | 0.5016 | -893.0 | -718.1 | |
| 0.00 | 1.45 | 0.00 | 0.84 | -24.92 | 131.76 | 7.60 | 193.61 | 0.5117 | -793.0 | -594.8 | |
| 0.00 | 3.17 | 0.00 | 1.80 | -23.62 | 131.68 | 7.52 | 194.15 | 0.4925 | -900.0 | -676.4 | |
| 0.00 | 2.36 | 0.00 | 1.35 | -24.11 | 131.57 | 7.41 | 193.70 | 0.4992 | -697.0 | -647.1 | |
| 0.00 | 1.27 | 0.00 | 0.73 | -24.74 | 131.48 | 7.32 | 193.21 | 0.5081 | -712.0 | -564.1 | |
| 0.00 | 2.63 | 0.00 | 1.52 | -25.61 | 130.41 | 6.25 | 190.98 | 0.5174 | -793.0 | -623.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
