SDO HMI 2011-07-20 23:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 88.42 | 472.01 | 51.08 | 272.60 | -22.73 | 136.01 | 14.06 | 205.83 | 0.5154 | -62.3 | -171.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-20 23:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.54 | 0.00 | 0.32 | -18.72 | 143.30 | 21.36 | 221.18 | 0.5259 | 653.0 | 610.5 | |
| 0.00 | 1.18 | 0.00 | 0.70 | -21.99 | 142.51 | 20.57 | 216.12 | 0.5548 | 723.0 | 569.8 | |
| 0.00 | 1.36 | 0.00 | 0.81 | -22.21 | 142.06 | 20.11 | 215.27 | 0.5535 | 872.0 | 736.4 | |
| 0.00 | 0.73 | 0.00 | 0.43 | -21.97 | 141.92 | 19.97 | 215.35 | 0.5495 | 696.0 | 524.8 | |
| 0.00 | 2.18 | 0.00 | 1.30 | -22.93 | 142.03 | 20.08 | 214.43 | 0.5615 | 550.0 | 494.9 | |
| 0.00 | 2.99 | 0.00 | 1.78 | -22.31 | 141.79 | 19.85 | 214.81 | 0.5523 | 826.0 | 705.4 | |
| 0.00 | 2.45 | 0.00 | 1.45 | -22.30 | 141.44 | 19.49 | 214.35 | 0.5493 | 849.0 | 700.0 | |
| 0.00 | 1.18 | 0.00 | 0.70 | -22.46 | 141.18 | 19.24 | 213.83 | 0.5491 | 510.0 | 462.3 | |
| 0.00 | 2.09 | 0.00 | 1.23 | -22.32 | 140.99 | 19.04 | 213.72 | 0.5459 | 840.0 | 758.7 | |
| 0.00 | 1.00 | 0.00 | 0.60 | -23.79 | 140.57 | 18.63 | 211.60 | 0.5600 | 552.0 | 531.0 | |
| 0.00 | 0.91 | 0.00 | 0.54 | -23.72 | 140.46 | 18.51 | 211.51 | 0.5583 | 717.0 | 618.9 | |
| 2.45 | 49.34 | 1.44 | 28.96 | -22.64 | 140.20 | 18.25 | 212.28 | 0.5434 | 777.2 | 639.3 | |
| 0.00 | 1.54 | 0.00 | 0.91 | -23.29 | 140.26 | 18.31 | 211.67 | 0.5517 | 687.0 | 554.6 | |
| 12.15 | -12.00 | 7.14 | -12.00 | -22.36 | 140.09 | 18.15 | 212.43 | 0.5392 | 1013.4 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.65 | -23.64 | 140.20 | 18.26 | 211.24 | 0.5554 | 486.0 | 514.7 | |
| 0.00 | 2.18 | 0.00 | 1.29 | -23.43 | 140.06 | 18.12 | 211.27 | 0.5518 | 708.0 | 656.2 | |
| 0.00 | 1.09 | 0.00 | 0.62 | -19.80 | 139.36 | 17.42 | 214.26 | 0.5022 | 756.0 | 599.1 | |
| 0.00 | 1.81 | 0.00 | 1.07 | -23.42 | 139.78 | 17.84 | 210.89 | 0.5496 | 864.0 | 681.0 | |
| 7.53 | 13.42 | 4.42 | 7.88 | -22.69 | 139.65 | 17.70 | 211.45 | 0.5398 | 917.9 | 648.9 | |
| 0.00 | 3.27 | 0.00 | 1.90 | -21.66 | 139.48 | 17.54 | 212.32 | 0.5259 | 703.0 | 611.0 | |
| 0.00 | 3.81 | 0.00 | 2.26 | -23.65 | 139.54 | 17.59 | 210.31 | 0.5507 | 608.0 | 537.6 | |
| 2.81 | 5.26 | 1.64 | 3.06 | -21.93 | 139.24 | 17.29 | 211.67 | 0.5272 | 989.4 | 854.1 | |
| 0.00 | 1.18 | 0.00 | 0.67 | -20.09 | 138.82 | 16.87 | 213.09 | 0.5012 | 835.0 | 692.1 | |
| 0.00 | 1.63 | 0.00 | 0.95 | -22.23 | 138.97 | 17.02 | 210.96 | 0.5288 | 670.0 | 554.0 | |
| 0.00 | 2.81 | 0.00 | 1.62 | -20.99 | 138.61 | 16.67 | 211.76 | 0.5108 | 807.0 | 659.7 | |
| 0.00 | 1.36 | 0.00 | 0.79 | -22.12 | 138.64 | 16.70 | 210.60 | 0.5250 | 820.0 | 690.3 | |
| 0.00 | 0.91 | 0.00 | 0.52 | -20.79 | 138.39 | 16.44 | 211.64 | 0.5064 | 720.0 | 608.3 | |
| 0.00 | 1.54 | 0.00 | 0.91 | -23.60 | 138.66 | 16.71 | 209.13 | 0.5436 | 721.0 | 491.9 | |
| 0.00 | 1.36 | 0.00 | 0.79 | -22.21 | 138.31 | 16.37 | 210.01 | 0.5237 | 952.0 | 720.8 | |
| 0.00 | 2.45 | 0.00 | 1.43 | -22.58 | 138.12 | 16.17 | 209.34 | 0.5270 | 489.0 | 592.1 | |
| 0.00 | 1.18 | 0.00 | 0.70 | -25.16 | 138.35 | 16.40 | 207.22 | 0.5610 | 705.0 | 584.8 | |
| 0.00 | 1.18 | 0.00 | 0.68 | -21.25 | 137.86 | 15.91 | 210.33 | 0.5081 | 683.0 | 518.7 | |
| 0.00 | 1.09 | 0.00 | 0.65 | -25.08 | 138.16 | 16.22 | 207.02 | 0.5588 | 577.0 | 429.2 | |
| 0.00 | 1.27 | 0.00 | 0.74 | -22.71 | 137.75 | 15.81 | 208.66 | 0.5260 | 435.0 | 551.2 | |
| 0.00 | 2.00 | 0.00 | 1.16 | -22.92 | 137.68 | 15.73 | 208.35 | 0.5280 | 628.0 | 603.7 | |
| 2.81 | 3.99 | 1.63 | 2.32 | -22.67 | 137.54 | 15.60 | 208.38 | 0.5240 | 872.9 | 693.9 | |
| 1.90 | 10.79 | 1.12 | 6.34 | -24.01 | 137.33 | 15.38 | 206.79 | 0.5397 | 831.9 | 679.3 | |
| 0.00 | 1.54 | 0.00 | 0.89 | -22.14 | 136.60 | 14.65 | 207.44 | 0.5104 | -211.0 | -155.0 | |
| 0.00 | 6.89 | 0.00 | 3.95 | -21.93 | 136.34 | 14.39 | 207.23 | 0.5058 | -244.0 | -271.6 | |
| 6.71 | 252.79 | 3.89 | 144.93 | -23.35 | 135.70 | 13.76 | 204.90 | 0.5206 | -705.4 | -459.2 | |
| 0.00 | 1.81 | 0.00 | 1.06 | -24.40 | 135.71 | 13.77 | 204.02 | 0.5345 | 546.0 | 475.5 | |
| 0.00 | 1.63 | 0.00 | 0.95 | -24.42 | 135.30 | 13.36 | 203.37 | 0.5324 | -341.0 | -189.8 | |
| 2.72 | 14.97 | 1.58 | 8.70 | -23.93 | 135.01 | 13.07 | 203.32 | 0.5241 | -847.0 | -744.1 | |
| 26.39 | -40.00 | 15.09 | -40.00 | -22.34 | 134.72 | 12.77 | 204.21 | 0.5007 | -1237.2 | 999999 | |
| 0.00 | 2.99 | 0.00 | 1.74 | -24.20 | 134.70 | 12.75 | 202.60 | 0.5259 | -658.0 | -526.1 | |
| 8.89 | -40.00 | 5.09 | -40.00 | -22.84 | 134.29 | 12.35 | 203.06 | 0.5051 | -987.4 | 999999 | |
| 0.73 | -40.00 | 0.41 | -40.00 | -22.29 | 134.24 | 12.30 | 203.45 | 0.4972 | -1059.0 | 999999 | |
| 0.00 | 0.54 | 0.00 | 0.31 | -22.28 | 133.74 | 11.79 | 202.60 | 0.4941 | -763.0 | -619.5 | |
| 13.33 | 40.82 | 7.63 | 23.36 | -22.93 | 133.56 | 11.61 | 201.76 | 0.5021 | -1089.4 | -579.4 | |
| 0.00 | 1.36 | 0.00 | 0.79 | -25.49 | 132.28 | 10.34 | 197.82 | 0.5313 | -682.0 | -599.5 | |
| 0.00 | 1.81 | 0.00 | 1.04 | -24.15 | 132.00 | 10.06 | 198.23 | 0.5112 | -819.0 | -726.0 | |
| 0.00 | 1.00 | 0.00 | 0.58 | -24.46 | 131.58 | 9.64 | 197.33 | 0.5137 | -642.0 | -588.1 | |
| 0.00 | 3.08 | 0.00 | 1.77 | -24.08 | 131.55 | 9.61 | 197.53 | 0.5081 | -701.0 | -662.5 | |
| 0.00 | 4.26 | 0.00 | 2.44 | -23.66 | 131.42 | 9.48 | 197.57 | 0.5015 | -445.0 | -653.7 | |
| 0.00 | 1.27 | 0.00 | 0.73 | -23.86 | 131.30 | 9.36 | 197.23 | 0.5039 | -707.0 | -555.5 | |
| 0.00 | 1.09 | 0.00 | 0.63 | -25.57 | 130.51 | 8.56 | 194.88 | 0.5250 | -765.0 | -619.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
