SDO HMI 2011-07-22 09:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.10 | 180.39 | 23.11 | 104.30 | 24.42 | 78.04 | -25.19 | 48.61 | 0.5178 | -139.9 | -197.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-22 09:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.08 | 84.84 | 2.88 | 48.19 | 23.86 | 80.24 | -22.99 | 47.27 | 0.4882 | -1184.0 | -523.8 | |
| 15.42 | -1.00 | 8.78 | -1.00 | 24.11 | 79.87 | -23.36 | 47.28 | 0.4946 | -1004.7 | 999999 | |
| 0.64 | -1.00 | 0.36 | -1.00 | 24.32 | 79.61 | -23.62 | 47.22 | 0.4995 | -531.3 | 999999 | |
| 2.00 | 4.63 | 1.15 | 2.65 | 24.04 | 78.79 | -24.44 | 48.56 | 0.5061 | -709.1 | -730.9 | |
| 0.00 | 1.18 | 0.00 | 0.69 | 26.24 | 78.31 | -24.92 | 45.62 | 0.5309 | -766.0 | -597.8 | |
| 0.00 | 1.54 | 0.00 | 0.88 | 23.06 | 78.61 | -24.61 | 50.34 | 0.4998 | -861.0 | -652.8 | |
| 1.00 | 15.70 | 0.58 | 9.10 | 24.86 | 78.13 | -25.10 | 47.92 | 0.5206 | -798.3 | -727.3 | |
| 2.27 | -7.00 | 1.32 | -7.00 | 24.75 | 77.90 | -25.33 | 48.32 | 0.5223 | -987.4 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.68 | 23.75 | 78.11 | -25.12 | 49.71 | 0.5114 | -700.0 | -610.4 | |
| 3.54 | -7.00 | 2.05 | -7.00 | 24.49 | 77.88 | -25.35 | 48.75 | 0.5203 | -888.5 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.74 | 25.23 | 77.49 | -25.74 | 47.98 | 0.5308 | -757.0 | -688.9 | |
| 1.54 | 21.23 | 0.90 | 12.38 | 24.86 | 77.39 | -25.84 | 48.65 | 0.5289 | -626.2 | -312.7 | |
| 3.08 | 4.54 | 1.81 | 2.67 | 25.80 | 77.13 | -26.10 | 47.45 | 0.5396 | -753.6 | -547.8 | |
| 1.45 | -12.00 | 0.85 | -12.00 | 24.60 | 77.26 | -25.97 | 49.19 | 0.5281 | -508.0 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.69 | 24.58 | 76.85 | -26.38 | 49.60 | 0.5326 | -437.0 | -282.2 | |
| 0.00 | 0.45 | 0.00 | 0.27 | 24.64 | 76.65 | -26.58 | 49.70 | 0.5353 | -174.0 | -217.8 | |
| 0.00 | 1.18 | 0.00 | 0.69 | 24.23 | 76.18 | -27.05 | 50.77 | 0.5373 | 219.0 | 203.8 | |
| 1.81 | 9.71 | 1.07 | 5.71 | 24.18 | 75.67 | -27.56 | 51.32 | 0.5428 | 1058.6 | 566.3 | |
| 0.00 | 1.63 | 0.00 | 0.99 | 26.86 | 74.79 | -28.44 | 48.02 | 0.5735 | 721.0 | 556.7 | |
| 0.00 | 1.54 | 0.00 | 0.91 | 24.08 | 75.47 | -27.76 | 51.66 | 0.5443 | 920.0 | 721.3 | |
| 0.00 | 1.45 | 0.00 | 0.86 | 24.69 | 75.32 | -27.91 | 50.83 | 0.5507 | 624.0 | 539.4 | |
| 0.00 | 1.72 | 0.00 | 1.01 | 23.62 | 75.46 | -27.77 | 52.38 | 0.5410 | 828.0 | 641.3 | |
| 0.00 | 1.91 | 0.00 | 1.13 | 24.81 | 75.10 | -28.13 | 50.83 | 0.5541 | 847.0 | 663.5 | |
| 0.00 | 0.82 | 0.00 | 0.49 | 24.94 | 74.99 | -28.24 | 50.73 | 0.5563 | 630.0 | 510.2 | |
| 0.00 | 3.54 | 0.00 | 2.10 | 24.68 | 74.98 | -28.25 | 51.14 | 0.5544 | 816.0 | 682.2 | |
| 0.00 | 2.90 | 0.00 | 1.75 | 26.49 | 74.39 | -28.84 | 48.92 | 0.5748 | 874.0 | 813.2 | |
| 0.00 | 1.00 | 0.00 | 0.59 | 24.22 | 74.90 | -28.33 | 51.92 | 0.5519 | 752.0 | 568.8 | |
| 0.00 | 1.09 | 0.00 | 0.65 | 24.44 | 74.81 | -28.42 | 51.65 | 0.5546 | 747.0 | 575.2 | |
| 0.00 | 1.00 | 0.00 | 0.60 | 25.34 | 74.43 | -28.80 | 50.60 | 0.5656 | 633.0 | 565.9 | |
| 0.00 | 2.00 | 0.00 | 1.18 | 23.66 | 74.73 | -28.50 | 52.94 | 0.5497 | 820.0 | 661.4 | |
| 2.27 | 3.08 | 1.36 | 1.85 | 24.84 | 74.29 | -28.94 | 51.47 | 0.5635 | 803.7 | 570.0 | |
| 0.00 | 1.00 | 0.00 | 0.59 | 24.14 | 74.47 | -28.76 | 52.42 | 0.5563 | 805.0 | 694.9 | |
| 0.00 | 1.45 | 0.00 | 0.88 | 26.07 | 73.92 | -29.31 | 49.93 | 0.5768 | 676.0 | 501.4 | |
| 0.00 | 0.73 | 0.00 | 0.43 | 23.56 | 74.57 | -28.66 | 53.24 | 0.5509 | 681.0 | 583.4 | |
| 0.00 | 1.27 | 0.00 | 0.76 | 24.96 | 73.91 | -29.32 | 51.60 | 0.5686 | 640.0 | 543.5 | |
| 0.00 | 1.54 | 0.00 | 0.93 | 25.11 | 73.71 | -29.51 | 51.53 | 0.5719 | 609.0 | 450.5 | |
| 0.00 | 1.09 | 0.00 | 0.66 | 25.20 | 73.50 | -29.73 | 51.57 | 0.5750 | 711.0 | 573.1 | |
| 0.00 | 1.00 | 0.00 | 0.60 | 25.29 | 73.28 | -29.95 | 51.61 | 0.5781 | 622.0 | 534.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
