SDO HMI 2011-07-23 17:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16.69 | 45.78 | 8.76 | 24.13 | 23.91 | 79.52 | -6.05 | 16.28 | 0.3402 | -484.3 | -346.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-23 17:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.62 | 35.53 | 3.47 | 18.66 | 23.60 | 80.81 | -4.77 | 13.48 | 0.3284 | -1029.3 | -600.9 | |
| 0.00 | 1.63 | 0.00 | 0.85 | 21.33 | 80.72 | -4.86 | 15.72 | 0.2924 | -808.0 | -727.3 | |
| 4.99 | -1.00 | 2.62 | -1.00 | 23.72 | 80.50 | -5.07 | 14.20 | 0.3316 | -1076.1 | 999999 | |
| 4.35 | -1.00 | 2.29 | -1.00 | 23.85 | 80.16 | -5.41 | 14.99 | 0.3350 | -1120.6 | 999999 | |
| 0.73 | 1.72 | 0.38 | 0.91 | 23.61 | 78.77 | -6.81 | 18.83 | 0.3380 | -1004.8 | -864.4 | |
| 0.00 | 0.82 | 0.00 | 0.44 | 27.11 | 77.81 | -7.77 | 17.75 | 0.3964 | -699.0 | -513.2 | |
| 0.00 | 1.18 | 0.00 | 0.64 | 27.44 | 75.22 | -10.36 | 22.69 | 0.4155 | 746.0 | 620.9 | |
| 0.00 | 0.91 | 0.00 | 0.49 | 26.53 | 73.88 | -11.70 | 26.28 | 0.4115 | 560.0 | 578.7 | |
| 0.00 | 1.18 | 0.00 | 0.64 | 26.40 | 73.61 | -11.96 | 26.94 | 0.4115 | 827.0 | 713.2 | |
| 0.00 | 0.82 | 0.00 | 0.44 | 25.90 | 73.25 | -12.33 | 28.26 | 0.4074 | 739.0 | 587.9 | |
| 0.00 | 1.99 | 0.00 | 1.06 | 22.93 | 73.44 | -12.14 | 32.12 | 0.3657 | 862.0 | 707.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
