SDO HMI 2011-07-24 08:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.26 | 17.15 | 3.29 | 17.98 | -23.17 | 133.62 | 56.30 | 240.20 | 0.8827 | -229.2 | -168.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-24 08:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 1.53 | -23.29 | 138.16 | 60.84 | 241.58 | 0.9137 | 666.0 | 525.6 | |
| 0.00 | 2.00 | 0.00 | 2.34 | -23.09 | 137.33 | 60.01 | 241.54 | 0.9080 | 602.0 | 531.8 | |
| 0.00 | 1.09 | 0.00 | 1.14 | -23.14 | 133.69 | 56.37 | 240.28 | 0.8835 | -328.0 | -235.6 | |
| 0.00 | 1.27 | 0.00 | 1.29 | -22.85 | 132.56 | 55.24 | 240.19 | 0.8745 | -327.0 | -341.2 | |
| 1.63 | 2.27 | 1.66 | 2.31 | -23.06 | 132.63 | 55.31 | 239.99 | 0.8757 | -366.9 | -327.1 | |
| 0.00 | 1.09 | 0.00 | 1.17 | -25.04 | 133.83 | 56.51 | 238.32 | 0.8898 | -438.0 | -346.3 | |
| 0.00 | 4.26 | 0.00 | 4.30 | -23.00 | 132.30 | 54.98 | 239.93 | 0.8731 | -569.0 | -436.7 | |
| 1.63 | 3.90 | 1.63 | 3.90 | -22.97 | 131.94 | 54.62 | 239.82 | 0.8703 | -690.8 | -579.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
