SDO HMI 2011-07-25 08:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 15.22 | 0.00 | 8.25 | 24.47 | 78.46 | 14.37 | 325.88 | 0.4056 | -263.5 | -350.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-25 08:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.54 | 0.00 | 1.93 | 23.62 | 81.24 | 17.16 | 319.74 | 0.4200 | -953.0 | -720.7 | |
| 0.00 | 1.90 | 0.00 | 1.04 | 23.44 | 80.84 | 16.75 | 320.08 | 0.4137 | -894.0 | -712.4 | |
| 0.00 | 1.36 | 0.00 | 0.74 | 23.52 | 80.29 | 16.21 | 321.09 | 0.4091 | -846.0 | -768.8 | |
| 0.00 | 1.09 | 0.00 | 0.59 | 23.74 | 79.01 | 14.92 | 323.65 | 0.3993 | -819.0 | -595.9 | |
| 0.00 | 3.08 | 0.00 | 1.66 | 25.07 | 76.99 | 12.90 | 329.37 | 0.3985 | -874.0 | -672.0 | |
| 0.00 | 1.90 | 0.00 | 1.02 | 24.53 | 76.59 | 12.50 | 329.36 | 0.3880 | 781.0 | 521.0 | |
| 0.00 | 1.72 | 0.00 | 0.93 | 26.75 | 74.46 | 10.37 | 336.41 | 0.4033 | 735.0 | 577.7 | |
| 0.00 | 0.63 | 0.00 | 0.34 | 26.36 | 74.15 | 10.06 | 336.60 | 0.3958 | 762.0 | 585.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
