SDO HMI 2011-07-25 12:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.45 | 14.42 | 0.25 | 7.88 | 25.80 | 76.26 | 14.37 | 327.88 | 0.4234 | -65.1 | -100.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-07-25 12:59:11 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.54 | 0.00 | 0.85 | 23.68 | 81.33 | 19.44 | 316.51 | 0.4446 | -843.0 | -753.4 | |
| 0.45 | 1.27 | 0.25 | 0.70 | 23.52 | 80.32 | 18.43 | 317.65 | 0.4321 | -830.0 | -724.2 | |
| 0.00 | 1.27 | 0.00 | 0.69 | 23.71 | 78.91 | 17.02 | 320.11 | 0.4197 | -769.0 | -634.4 | |
| 0.00 | 2.27 | 0.00 | 1.24 | 25.48 | 76.88 | 14.99 | 326.20 | 0.4215 | -749.0 | -539.2 | |
| 0.00 | 1.54 | 0.00 | 0.85 | 27.18 | 76.93 | 15.04 | 328.48 | 0.4434 | -650.0 | -554.9 | |
| 0.00 | 1.18 | 0.00 | 0.64 | 27.20 | 74.43 | 12.54 | 332.81 | 0.4244 | 590.0 | 495.1 | |
| 0.00 | 1.00 | 0.00 | 0.55 | 27.50 | 74.25 | 12.36 | 333.49 | 0.4272 | 539.0 | 376.3 | |
| 0.00 | 1.63 | 0.00 | 0.90 | 28.82 | 74.09 | 12.20 | 335.27 | 0.4444 | 663.0 | 369.8 | |
| 0.00 | 1.27 | 0.00 | 0.68 | 25.43 | 72.31 | 10.42 | 334.77 | 0.3849 | 777.0 | 610.2 | |
| 0.00 | 1.45 | 0.00 | 0.78 | 25.51 | 71.87 | 9.98 | 335.78 | 0.3829 | 812.0 | 652.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
