SDO HMI 2011-08-07 10:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 31.37 | 92.68 | 17.14 | 50.55 | -16.88 | 242.18 | -8.87 | 159.51 | 0.4201 | -320.3 | -84.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-07 10:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.45 | 5.88 | 0.77 | 3.13 | -14.89 | 246.13 | -4.92 | 167.00 | 0.3702 | 859.1 | 851.8 | |
| 1.18 | 1.27 | 0.63 | 0.68 | -15.49 | 245.10 | -5.95 | 164.84 | 0.3837 | 764.3 | 770.0 | |
| 0.00 | 1.72 | 0.00 | 0.93 | -16.58 | 244.34 | -6.72 | 163.81 | 0.4039 | -864.0 | -708.1 | |
| 5.06 | 33.18 | 2.75 | 18.00 | -16.75 | 243.72 | -7.33 | 162.55 | 0.4094 | 940.5 | 40.5 | |
| 0.72 | -4.00 | 0.39 | -4.00 | -17.02 | 243.58 | -7.47 | 162.45 | 0.4141 | -800.1 | 999999 | |
| 1.36 | 2.08 | 0.73 | 1.12 | -15.51 | 243.61 | -7.45 | 161.29 | 0.3910 | 910.7 | 877.4 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -17.58 | 243.53 | -7.53 | 162.75 | 0.4229 | -729.0 | -577.1 | |
| 1.81 | -4.00 | 0.98 | -4.00 | -16.66 | 243.50 | -7.55 | 161.99 | 0.4090 | 1031.4 | 999999 | |
| 0.00 | 2.62 | 0.00 | 1.42 | -16.43 | 243.19 | -7.87 | 161.11 | 0.4072 | 411.0 | 350.0 | |
| 0.00 | 3.16 | 0.00 | 1.71 | -16.07 | 242.98 | -8.07 | 160.34 | 0.4029 | 990.0 | 784.0 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -17.10 | 242.84 | -8.21 | 160.90 | 0.4190 | -907.0 | -676.8 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -17.13 | 240.97 | -10.09 | 157.00 | 0.4301 | -711.0 | -593.2 | |
| 3.16 | 5.06 | 1.73 | 2.77 | -16.94 | 240.62 | -10.43 | 156.12 | 0.4295 | -987.6 | -776.2 | |
| 13.56 | 30.01 | 7.47 | 16.53 | -17.32 | 240.08 | -10.97 | 155.41 | 0.4383 | -963.3 | -577.1 | |
| 3.07 | -14.00 | 1.69 | -14.00 | -16.95 | 240.11 | -10.95 | 155.08 | 0.4330 | -1075.1 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.72 | -21.29 | 238.88 | -12.18 | 156.82 | 0.5014 | 682.0 | 485.5 | |
| 0.00 | 2.53 | 0.00 | 1.42 | -18.51 | 237.61 | -13.44 | 152.02 | 0.4718 | -817.0 | -648.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
