SDO HMI 2011-08-08 10:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 77.54 | 211.19 | 39.58 | 107.88 | 19.57 | 241.77 | 3.94 | 344.30 | 0.2437 | 9.8 | 130.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-08 10:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.17 | 0.00 | 1.12 | 19.25 | 246.51 | 8.68 | 327.78 | 0.2684 | -855.0 | -755.8 | |
| 0.00 | 4.79 | 0.00 | 2.46 | 18.78 | 246.10 | 8.27 | 328.03 | 0.2582 | -1179.0 | -945.3 | |
| 0.00 | 1.81 | 0.00 | 0.93 | 19.42 | 245.58 | 7.75 | 330.94 | 0.2628 | -801.0 | -669.8 | |
| 0.00 | 3.52 | 0.00 | 1.80 | 18.76 | 245.42 | 7.59 | 330.12 | 0.2520 | -1016.0 | -759.6 | |
| 0.00 | 0.99 | 0.00 | 0.51 | 17.90 | 245.22 | 7.39 | 328.89 | 0.2378 | -812.0 | -647.3 | |
| 0.00 | 1.90 | 0.00 | 0.97 | 18.30 | 245.20 | 7.37 | 329.84 | 0.2435 | -989.0 | -719.7 | |
| 0.00 | 2.53 | 0.00 | 1.30 | 18.95 | 245.17 | 7.33 | 331.32 | 0.2527 | -924.0 | -629.5 | |
| 0.00 | 1.17 | 0.00 | 0.60 | 18.05 | 245.03 | 7.20 | 329.88 | 0.2385 | -859.0 | -597.2 | |
| 17.89 | 29.19 | 9.14 | 14.91 | 18.55 | 244.79 | 6.96 | 331.75 | 0.2439 | -1225.9 | -733.6 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 19.43 | 244.73 | 6.90 | 333.64 | 0.2564 | -579.0 | -451.3 | |
| 0.00 | 1.08 | 0.00 | 0.55 | 18.44 | 244.34 | 6.51 | 333.09 | 0.2385 | -661.0 | -593.5 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 18.81 | 244.22 | 6.39 | 334.22 | 0.2433 | -914.0 | -642.8 | |
| 0.00 | 2.44 | 0.00 | 1.25 | 18.81 | 244.00 | 6.16 | 335.01 | 0.2417 | -724.0 | -457.0 | |
| 0.00 | 2.53 | 0.00 | 1.29 | 18.57 | 243.41 | 5.58 | 336.70 | 0.2339 | -1172.0 | -1019.0 | |
| 10.21 | 16.72 | 5.20 | 8.52 | 18.79 | 242.96 | 5.13 | 338.74 | 0.2345 | -1124.8 | -606.6 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 19.11 | 242.78 | 4.95 | 339.92 | 0.2384 | -310.0 | -349.1 | |
| 0.00 | 0.81 | 0.00 | 0.42 | 19.26 | 242.72 | 4.89 | 340.37 | 0.2405 | -504.0 | -399.1 | |
| 0.00 | 1.08 | 0.00 | 0.56 | 20.74 | 242.34 | 4.51 | 343.64 | 0.2622 | 726.0 | 501.0 | |
| 0.81 | 5.33 | 0.42 | 2.73 | 20.52 | 242.07 | 4.24 | 344.31 | 0.2574 | 1135.3 | 817.3 | |
| 0.00 | 1.36 | 0.00 | 0.69 | 19.30 | 241.62 | 3.79 | 344.57 | 0.2356 | -464.0 | -239.4 | |
| 3.89 | 8.59 | 1.98 | 4.37 | 18.99 | 241.33 | 3.49 | 345.37 | 0.2292 | -845.0 | -672.7 | |
| 0.00 | 1.81 | 0.00 | 0.92 | 19.33 | 241.33 | 3.50 | 345.73 | 0.2348 | -489.0 | -327.8 | |
| 9.76 | 20.15 | 4.99 | 10.31 | 20.43 | 241.06 | 3.23 | 347.84 | 0.2519 | 1028.1 | 483.8 | |
| 4.16 | 10.93 | 2.11 | 5.55 | 18.62 | 240.68 | 2.84 | 347.63 | 0.2205 | 1088.5 | 717.1 | |
| 0.00 | 0.36 | 0.00 | 0.18 | 20.31 | 240.19 | 2.35 | 350.99 | 0.2472 | 566.0 | 659.5 | |
| 0.00 | 0.99 | 0.00 | 0.51 | 21.25 | 240.20 | 2.37 | 351.54 | 0.2630 | 669.0 | 574.1 | |
| 0.00 | 5.96 | 0.00 | 3.03 | 19.00 | 240.10 | 2.27 | 350.37 | 0.2249 | 1159.0 | 832.7 | |
| 0.00 | 7.50 | 0.00 | 3.86 | 21.54 | 240.01 | 2.18 | 352.37 | 0.2673 | 815.0 | 723.5 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 19.25 | 239.91 | 2.08 | 351.34 | 0.2286 | 940.0 | 808.0 | |
| 0.00 | 1.72 | 0.00 | 0.87 | 19.50 | 239.79 | 1.95 | 352.02 | 0.2325 | 1019.0 | 877.0 | |
| 21.69 | 63.62 | 11.07 | 32.50 | 20.12 | 239.70 | 1.87 | 352.74 | 0.2429 | 1136.5 | 797.1 | |
| 9.13 | -31.00 | 4.67 | -31.00 | 20.66 | 239.70 | 1.87 | 353.00 | 0.2519 | 947.8 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.64 | 18.47 | 239.52 | 1.69 | 352.49 | 0.2145 | 770.0 | 635.1 | |
| 0.00 | 3.16 | 0.00 | 1.62 | 20.22 | 239.25 | 1.41 | 354.53 | 0.2436 | -79.0 | -54.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
