SDO HMI 2011-08-10 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.05 | 66.27 | 12.19 | 38.93 | 19.74 | 242.17 | 30.23 | 297.76 | 0.5364 | 253.8 | 34.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-10 09:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.17 | 0.00 | 0.74 | 20.03 | 248.80 | 36.86 | 294.51 | 0.6216 | -442.0 | -473.8 | |
| 2.17 | 3.79 | 1.36 | 2.38 | 19.10 | 248.51 | 36.57 | 293.18 | 0.6147 | -723.5 | -610.9 | |
| 0.00 | 3.97 | 0.00 | 2.47 | 19.04 | 247.97 | 36.04 | 293.30 | 0.6077 | -846.0 | -640.7 | |
| 0.00 | 1.72 | 0.00 | 1.06 | 18.50 | 247.60 | 35.66 | 292.58 | 0.6010 | -800.0 | -647.8 | |
| 0.00 | 0.99 | 0.00 | 0.61 | 19.05 | 247.38 | 35.44 | 293.55 | 0.6001 | -612.0 | -497.4 | |
| 1.26 | 7.86 | 0.76 | 4.75 | 18.27 | 245.67 | 33.74 | 293.02 | 0.5751 | -817.9 | -796.4 | |
| 0.00 | 1.45 | 0.00 | 0.87 | 18.58 | 245.36 | 33.42 | 293.67 | 0.5722 | -735.0 | -692.6 | |
| 0.00 | 1.08 | 0.00 | 0.65 | 18.31 | 244.61 | 32.67 | 293.56 | 0.5612 | -604.0 | -521.5 | |
| 2.08 | 5.42 | 1.23 | 3.22 | 18.18 | 244.01 | 32.08 | 293.64 | 0.5528 | -926.0 | -362.2 | |
| 0.00 | 1.26 | 0.00 | 0.73 | 19.69 | 241.03 | 29.09 | 298.02 | 0.5206 | 791.0 | 607.0 | |
| 0.00 | 3.79 | 0.00 | 2.20 | 20.87 | 240.79 | 28.85 | 300.28 | 0.5242 | 773.0 | 690.6 | |
| 0.00 | 1.26 | 0.00 | 0.73 | 21.49 | 240.51 | 28.57 | 301.56 | 0.5243 | 463.0 | 310.0 | |
| 0.00 | 0.72 | 0.00 | 0.42 | 21.92 | 240.05 | 28.11 | 302.67 | 0.5213 | 775.0 | 733.5 | |
| 7.95 | 15.44 | 4.52 | 8.78 | 19.87 | 238.76 | 26.82 | 299.97 | 0.4918 | 1017.3 | 793.8 | |
| 1.45 | 2.44 | 0.82 | 1.39 | 20.53 | 238.84 | 26.91 | 301.12 | 0.4970 | 586.8 | 558.0 | |
| 2.26 | -14.00 | 1.28 | -14.00 | 20.06 | 238.65 | 26.71 | 300.42 | 0.4915 | 956.7 | 999999 | |
| 3.88 | 9.21 | 2.22 | 5.26 | 21.10 | 238.77 | 26.83 | 302.22 | 0.4998 | 944.4 | 744.0 | |
| 0.00 | 3.25 | 0.00 | 1.85 | 20.87 | 238.25 | 26.32 | 302.23 | 0.4916 | 1001.0 | 781.8 | |
| 0.00 | 1.45 | 0.00 | 0.82 | 22.52 | 236.83 | 24.89 | 306.50 | 0.4856 | 720.0 | 507.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
