SDO HMI 2011-08-11 13:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.82 | 27.78 | 7.34 | 17.13 | -21.87 | 173.33 | -23.19 | 141.98 | 0.5941 | -176.9 | 405.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-11 13:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.79 | 15.25 | 2.29 | 9.22 | -21.06 | 174.76 | -21.76 | 142.70 | 0.5730 | 849.1 | 617.9 | |
| 0.00 | 1.17 | 0.00 | 0.72 | -21.93 | 174.33 | -22.18 | 143.15 | 0.5861 | 433.0 | 295.1 | |
| 7.13 | 8.48 | 4.45 | 5.30 | -22.81 | 172.57 | -23.94 | 142.04 | 0.6104 | -876.7 | -674.0 | |
| 0.00 | 1.08 | 0.00 | 0.69 | -24.56 | 171.97 | -24.54 | 143.23 | 0.6334 | -566.0 | -506.5 | |
| 0.90 | 1.80 | 0.60 | 1.20 | -22.42 | 165.82 | -30.69 | 134.77 | 0.6668 | 729.0 | 654.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
