SDO HMI 2011-08-12 13:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.05 | 20.28 | 3.94 | 15.55 | 23.38 | 134.67 | -48.62 | 64.64 | 0.7636 | 152.6 | -51.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-12 13:59:10 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.90 | 0.00 | 0.64 | 22.45 | 139.10 | -44.19 | 64.70 | 0.7150 | 439.0 | 401.6 | |
| 1.89 | 7.76 | 1.39 | 5.68 | 23.39 | 137.19 | -46.10 | 63.99 | 0.7381 | -797.7 | -558.9 | |
| 0.00 | 1.35 | 0.00 | 0.99 | 23.20 | 137.18 | -46.11 | 64.25 | 0.7377 | -650.0 | -574.9 | |
| 0.00 | 0.72 | 0.00 | 0.56 | 23.45 | 133.90 | -49.39 | 64.78 | 0.7721 | -468.0 | -426.5 | |
| 0.00 | 1.17 | 0.00 | 0.92 | 22.81 | 133.15 | -50.15 | 65.77 | 0.7783 | 568.0 | 565.2 | |
| 0.00 | 0.27 | 0.00 | 0.21 | 22.83 | 132.61 | -50.68 | 65.86 | 0.7836 | 498.0 | 542.3 | |
| 3.16 | 5.59 | 2.55 | 4.51 | 23.78 | 132.00 | -51.29 | 64.80 | 0.7914 | 653.4 | 529.9 | |
| 0.00 | 1.53 | 0.00 | 1.23 | 22.80 | 132.31 | -50.98 | 65.95 | 0.7865 | 394.0 | 363.2 | |
| 0.00 | 0.99 | 0.00 | 0.81 | 23.68 | 131.63 | -51.67 | 65.00 | 0.7948 | 331.0 | 287.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
