SDO HMI 2011-08-18 10:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.49 | 34.29 | 3.03 | 18.99 | -18.22 | 114.21 | 8.58 | 198.46 | 0.4471 | -286.8 | -230.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-18 10:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.80 | 0.00 | 1.01 | -18.23 | 118.03 | 12.40 | 205.90 | 0.4689 | 745.0 | 555.8 | |
| 0.90 | 3.42 | 0.51 | 1.92 | -18.82 | 117.29 | 11.66 | 203.99 | 0.4722 | 748.4 | 768.2 | |
| 0.00 | 1.62 | 0.00 | 0.91 | -19.00 | 116.58 | 10.95 | 202.53 | 0.4705 | 848.0 | 646.2 | |
| 0.00 | 2.16 | 0.00 | 1.21 | -19.14 | 116.46 | 10.83 | 202.20 | 0.4717 | 737.0 | 658.7 | |
| 0.00 | 0.99 | 0.00 | 0.55 | -18.45 | 115.96 | 10.33 | 201.84 | 0.4590 | 617.0 | 482.6 | |
| 0.00 | 1.89 | 0.00 | 1.04 | -17.67 | 113.88 | 8.25 | 198.32 | 0.4365 | -905.0 | -779.6 | |
| 0.00 | 3.96 | 0.00 | 2.20 | -18.67 | 113.38 | 7.74 | 196.59 | 0.4490 | -928.0 | -739.1 | |
| 0.00 | 2.70 | 0.00 | 1.49 | -18.10 | 113.35 | 7.72 | 196.92 | 0.4404 | -837.0 | -676.5 | |
| 3.24 | 3.78 | 1.78 | 2.08 | -17.73 | 113.30 | 7.67 | 197.08 | 0.4346 | -936.5 | -822.0 | |
| 1.35 | 1.89 | 0.74 | 1.03 | -16.93 | 113.27 | 7.64 | 197.59 | 0.4224 | 628.5 | 633.7 | |
| 0.00 | 2.61 | 0.00 | 1.43 | -17.50 | 113.29 | 7.66 | 197.23 | 0.4311 | -807.0 | -662.3 | |
| 0.00 | 1.26 | 0.00 | 0.70 | -18.37 | 113.27 | 7.63 | 196.57 | 0.4440 | -711.0 | -625.9 | |
| 0.00 | 3.24 | 0.00 | 1.80 | -18.83 | 113.13 | 7.49 | 195.97 | 0.4504 | -564.0 | -575.7 | |
| 0.00 | 0.81 | 0.00 | 0.44 | -17.50 | 111.24 | 5.61 | 192.79 | 0.4228 | -865.0 | -744.2 | |
| 0.00 | 2.16 | 0.00 | 1.18 | -17.49 | 110.79 | 5.16 | 191.81 | 0.4212 | -820.0 | -622.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
