SDO HMI 2011-08-19 02:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 154.12 | 826.58 | 94.64 | 508.28 | 15.92 | 61.09 | -35.71 | 72.11 | 0.5911 | -150.5 | -35.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-19 02:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.35 | 0.00 | 0.76 | 15.62 | 68.93 | -27.87 | 69.72 | 0.4818 | -633.0 | -600.7 | |
| 0.00 | 0.90 | 0.00 | 0.51 | 16.51 | 68.26 | -28.54 | 68.31 | 0.4950 | -613.0 | -453.3 | |
| 0.00 | 1.89 | 0.00 | 1.08 | 15.59 | 67.72 | -29.08 | 70.38 | 0.4990 | -976.0 | -766.0 | |
| 0.00 | 0.81 | 0.00 | 0.46 | 14.81 | 67.65 | -29.15 | 71.93 | 0.4973 | -703.0 | -607.0 | |
| 0.00 | 0.36 | 0.00 | 0.21 | 15.42 | 67.53 | -29.27 | 70.79 | 0.5012 | -278.0 | -443.2 | |
| 26.56 | 294.55 | 15.60 | 173.59 | 15.57 | 64.86 | -31.94 | 71.60 | 0.5391 | -1334.1 | -406.2 | |
| 23.32 | -6.00 | 13.77 | -6.00 | 15.63 | 64.33 | -32.47 | 71.69 | 0.5467 | -965.0 | 999999 | |
| 4.41 | -6.00 | 2.61 | -6.00 | 15.23 | 64.25 | -32.55 | 72.44 | 0.5466 | -912.6 | 999999 | |
| 0.00 | 1.80 | 0.00 | 1.10 | 19.02 | 62.37 | -34.43 | 66.63 | 0.5845 | 482.0 | 378.4 | |
| 0.00 | 0.99 | 0.00 | 0.59 | 15.76 | 62.95 | -33.85 | 71.94 | 0.5660 | -533.0 | -380.2 | |
| 9.90 | 20.89 | 6.05 | 12.76 | 18.53 | 62.05 | -34.74 | 67.57 | 0.5868 | -945.3 | -265.9 | |
| 25.03 | 206.33 | 15.17 | 125.73 | 16.96 | 62.29 | -34.51 | 70.11 | 0.5785 | -1188.4 | -253.5 | |
| 14.04 | -12.00 | 8.58 | -12.00 | 17.70 | 61.81 | -34.98 | 69.03 | 0.5871 | -944.4 | 999999 | |
| 0.00 | 0.99 | 0.00 | 0.60 | 15.58 | 62.03 | -34.77 | 72.55 | 0.5780 | 557.0 | 398.1 | |
| 0.00 | 3.15 | 0.00 | 1.91 | 15.97 | 61.87 | -34.93 | 71.93 | 0.5812 | -172.0 | -80.7 | |
| 0.00 | 1.08 | 0.00 | 0.67 | 18.25 | 61.18 | -35.62 | 68.37 | 0.5972 | -322.0 | -233.6 | |
| 0.00 | 2.52 | 0.00 | 1.54 | 15.07 | 61.35 | -35.44 | 73.60 | 0.5859 | -491.0 | -408.2 | |
| 0.00 | 1.26 | 0.00 | 0.80 | 20.30 | 59.44 | -37.35 | 65.78 | 0.6262 | -693.0 | -472.1 | |
| 0.00 | 2.07 | 0.00 | 1.28 | 16.54 | 60.27 | -36.53 | 71.47 | 0.6040 | 819.0 | 658.5 | |
| 0.00 | 1.26 | 0.00 | 0.78 | 15.21 | 59.80 | -37.00 | 73.77 | 0.6070 | 827.0 | 638.6 | |
| 0.00 | 0.90 | 0.00 | 0.56 | 13.72 | 60.05 | -36.75 | 76.17 | 0.6008 | 692.0 | 516.6 | |
| 0.00 | 1.53 | 0.00 | 0.96 | 17.40 | 59.23 | -37.57 | 70.40 | 0.6198 | 720.0 | 631.9 | |
| 0.00 | 1.08 | 0.00 | 0.67 | 15.85 | 59.59 | -37.21 | 72.79 | 0.6112 | 655.0 | 521.0 | |
| 0.00 | 0.81 | 0.00 | 0.53 | 21.02 | 57.61 | -39.19 | 65.38 | 0.6510 | 588.0 | 526.1 | |
| 0.00 | 1.17 | 0.00 | 0.73 | 13.75 | 59.18 | -37.62 | 76.29 | 0.6125 | 679.0 | 572.2 | |
| 0.00 | 2.88 | 0.00 | 1.81 | 14.50 | 58.96 | -37.84 | 75.11 | 0.6168 | 780.0 | 652.5 | |
| 12.60 | 44.38 | 7.96 | 27.96 | 15.31 | 58.63 | -38.17 | 73.88 | 0.6227 | 900.5 | 711.9 | |
| 0.00 | 6.03 | 0.00 | 3.79 | 13.76 | 58.90 | -37.90 | 76.32 | 0.6162 | 473.0 | 615.3 | |
| 0.00 | 0.81 | 0.00 | 0.51 | 14.40 | 58.74 | -38.06 | 75.33 | 0.6195 | 738.0 | 585.0 | |
| 0.36 | 2.88 | 0.23 | 1.83 | 15.67 | 58.39 | -38.41 | 73.38 | 0.6265 | 683.5 | 564.2 | |
| 0.00 | 0.90 | 0.00 | 0.59 | 19.97 | 57.10 | -39.70 | 67.12 | 0.6539 | 785.0 | 712.4 | |
| 8.19 | 20.26 | 5.40 | 13.32 | 19.89 | 56.44 | -40.36 | 67.45 | 0.6616 | 925.8 | 767.1 | |
| 0.00 | 1.35 | 0.00 | 0.90 | 20.55 | 55.89 | -40.90 | 66.67 | 0.6700 | 573.0 | 436.8 | |
| 0.00 | 1.17 | 0.00 | 0.76 | 16.19 | 57.04 | -39.76 | 72.88 | 0.6449 | 686.0 | 522.6 | |
| 0.00 | 1.17 | 0.00 | 0.78 | 19.71 | 56.03 | -40.77 | 67.86 | 0.6660 | 765.0 | 646.8 | |
| 0.00 | 3.24 | 0.00 | 2.15 | 19.98 | 55.90 | -40.89 | 67.49 | 0.6683 | 632.0 | 556.0 | |
| 0.00 | 0.90 | 0.00 | 0.60 | 20.46 | 55.62 | -41.18 | 66.88 | 0.6730 | 631.0 | 529.9 | |
| 0.00 | 0.99 | 0.00 | 0.64 | 16.50 | 56.68 | -40.12 | 72.48 | 0.6502 | 749.0 | 575.0 | |
| 0.00 | 1.44 | 0.00 | 0.96 | 19.40 | 55.78 | -41.01 | 68.37 | 0.6681 | 882.0 | 705.8 | |
| 0.00 | 1.17 | 0.00 | 0.78 | 19.77 | 55.59 | -41.21 | 67.90 | 0.6715 | 568.0 | 469.5 | |
| 0.00 | 1.80 | 0.00 | 1.20 | 19.12 | 55.70 | -41.10 | 68.82 | 0.6684 | 700.0 | 619.3 | |
| 0.00 | 1.71 | 0.00 | 1.14 | 18.63 | 55.46 | -41.34 | 69.61 | 0.6700 | 733.0 | 659.9 | |
| 0.00 | 2.07 | 0.00 | 1.38 | 18.81 | 55.37 | -41.43 | 69.37 | 0.6716 | 681.0 | 574.0 | |
| 28.45 | 180.14 | 18.45 | 116.93 | 14.11 | 56.53 | -40.27 | 76.18 | 0.6478 | 1164.4 | 376.0 | |
| 0.72 | 1.35 | 0.47 | 0.89 | 15.86 | 55.92 | -40.88 | 73.63 | 0.6584 | 577.8 | 493.7 | |
| 0.54 | -44.00 | 0.35 | -44.00 | 14.44 | 56.00 | -40.80 | 75.76 | 0.6551 | 536.5 | 999999 | |
| 0.00 | 1.53 | 0.00 | 1.04 | 18.53 | 54.24 | -42.56 | 70.06 | 0.6845 | 597.0 | 522.9 | |
| 0.00 | 0.72 | 0.00 | 0.50 | 19.89 | 53.53 | -43.27 | 68.29 | 0.6960 | 572.0 | 470.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
