SDO HMI 2011-08-19 14:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 165.56 | 852.81 | 94.75 | 488.29 | 15.86 | 61.18 | -29.03 | 69.59 | 0.4993 | -157.7 | -72.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-19 14:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.25 | 0.00 | 1.21 | 15.87 | 69.05 | -21.16 | 64.57 | 0.3861 | -797.0 | -644.2 | |
| 0.00 | 0.90 | 0.00 | 0.49 | 17.29 | 68.20 | -22.01 | 62.03 | 0.4069 | -573.0 | -473.2 | |
| 0.00 | 3.69 | 0.00 | 1.99 | 14.98 | 67.62 | -22.59 | 67.88 | 0.4023 | -747.0 | -643.9 | |
| 23.12 | 303.03 | 12.78 | 167.99 | 15.56 | 64.86 | -25.35 | 68.43 | 0.4453 | -1306.8 | -408.9 | |
| 21.95 | -4.00 | 12.19 | -4.00 | 15.62 | 64.33 | -25.88 | 68.62 | 0.4533 | -1009.6 | 999999 | |
| 2.25 | 3.06 | 1.24 | 1.68 | 12.79 | 64.68 | -25.53 | 74.65 | 0.4377 | -882.1 | -823.6 | |
| 0.00 | 1.35 | 0.00 | 0.74 | 12.68 | 64.41 | -25.80 | 75.00 | 0.4414 | -746.0 | -632.9 | |
| 8.28 | -4.00 | 4.60 | -4.00 | 15.18 | 64.04 | -26.17 | 69.73 | 0.4556 | -914.8 | 999999 | |
| 0.00 | 1.80 | 0.00 | 1.01 | 16.44 | 63.37 | -26.84 | 67.50 | 0.4707 | -725.0 | -587.6 | |
| 0.00 | 2.88 | 0.00 | 1.62 | 16.77 | 63.17 | -27.04 | 66.94 | 0.4749 | -56.0 | -21.2 | |
| 0.00 | 1.17 | 0.00 | 0.65 | 13.09 | 63.46 | -26.75 | 74.48 | 0.4568 | -666.0 | -480.2 | |
| 0.00 | 0.90 | 0.00 | 0.50 | 15.07 | 63.21 | -27.00 | 70.40 | 0.4673 | -518.0 | -289.3 | |
| 10.80 | 11.70 | 6.14 | 6.65 | 18.56 | 62.45 | -27.76 | 63.88 | 0.4938 | -831.0 | -826.6 | |
| 0.00 | 1.08 | 0.00 | 0.62 | 20.20 | 62.10 | -28.11 | 61.05 | 0.5073 | -633.0 | -521.8 | |
| 0.27 | 221.97 | 0.15 | 126.18 | 16.28 | 62.64 | -27.57 | 68.24 | 0.4802 | -94.3 | -281.5 | |
| 1.62 | -15.00 | 0.91 | -15.00 | 16.30 | 62.53 | -27.68 | 68.25 | 0.4819 | 275.8 | 999999 | |
| 28.34 | -15.00 | 16.05 | -15.00 | 16.97 | 62.39 | -27.82 | 67.00 | 0.4869 | -1134.8 | 999999 | |
| 16.47 | -15.00 | 9.38 | -15.00 | 17.73 | 62.05 | -28.16 | 65.72 | 0.4951 | -904.0 | 999999 | |
| 0.00 | 0.54 | 0.00 | 0.31 | 18.24 | 61.63 | -28.58 | 65.01 | 0.5032 | -339.0 | -269.7 | |
| 0.00 | 1.71 | 0.00 | 0.97 | 15.90 | 61.91 | -28.29 | 69.38 | 0.4890 | -348.0 | -243.4 | |
| 0.00 | 2.34 | 0.00 | 1.33 | 15.92 | 61.70 | -28.51 | 69.46 | 0.4922 | 579.0 | 460.9 | |
| 0.00 | 1.26 | 0.00 | 0.72 | 18.37 | 61.17 | -29.04 | 65.04 | 0.5101 | -245.0 | -243.6 | |
| 0.00 | 0.90 | 0.00 | 0.52 | 16.26 | 60.08 | -30.13 | 69.57 | 0.5162 | 606.0 | 504.4 | |
| 0.00 | 1.44 | 0.00 | 0.83 | 16.93 | 59.89 | -30.32 | 68.41 | 0.5214 | 649.0 | 559.6 | |
| 0.00 | 1.62 | 0.00 | 0.94 | 16.28 | 59.86 | -30.35 | 69.64 | 0.5194 | 899.0 | 721.2 | |
| 0.00 | 0.99 | 0.00 | 0.57 | 14.38 | 60.16 | -30.05 | 73.12 | 0.5089 | 770.0 | 480.0 | |
| 0.00 | 0.99 | 0.00 | 0.57 | 16.49 | 59.78 | -30.42 | 69.28 | 0.5212 | 648.0 | 559.9 | |
| 0.00 | 1.17 | 0.00 | 0.68 | 14.50 | 59.49 | -30.72 | 73.15 | 0.5188 | 796.0 | 618.3 | |
| 0.00 | 1.17 | 0.00 | 0.68 | 14.24 | 59.27 | -30.94 | 73.72 | 0.5212 | 771.0 | 699.1 | |
| 0.00 | 2.07 | 0.00 | 1.20 | 14.57 | 59.22 | -30.99 | 73.10 | 0.5228 | 756.0 | 643.0 | |
| 0.00 | 0.63 | 0.00 | 0.37 | 15.69 | 58.78 | -31.43 | 71.19 | 0.5324 | 605.0 | 539.6 | |
| 3.33 | 4.50 | 1.93 | 2.61 | 13.82 | 58.97 | -31.24 | 74.60 | 0.5244 | 832.2 | 677.5 | |
| 0.00 | 1.26 | 0.00 | 0.73 | 14.67 | 58.84 | -31.37 | 73.05 | 0.5285 | 594.0 | 478.1 | |
| 3.06 | 28.25 | 1.79 | 16.48 | 15.16 | 58.72 | -31.49 | 72.19 | 0.5316 | 972.6 | 725.4 | |
| 0.00 | 1.35 | 0.00 | 0.79 | 15.67 | 58.56 | -31.65 | 71.30 | 0.5354 | 771.0 | 646.7 | |
| 0.00 | 1.26 | 0.00 | 0.74 | 16.50 | 58.34 | -31.87 | 69.90 | 0.5412 | 690.0 | 447.4 | |
| 0.00 | 0.81 | 0.00 | 0.49 | 20.93 | 57.38 | -32.82 | 62.68 | 0.5720 | 653.0 | 520.2 | |
| 0.00 | 2.52 | 0.00 | 1.48 | 15.45 | 58.38 | -31.83 | 71.79 | 0.5373 | 588.0 | 446.8 | |
| 0.00 | 3.96 | 0.00 | 2.39 | 20.31 | 56.96 | -33.25 | 63.94 | 0.5746 | 691.0 | 568.9 | |
| 0.00 | 0.72 | 0.00 | 0.44 | 20.37 | 56.44 | -33.77 | 64.09 | 0.5815 | 621.0 | 534.1 | |
| 2.34 | 15.39 | 1.42 | 9.35 | 20.06 | 56.47 | -33.74 | 64.59 | 0.5797 | 951.7 | 707.1 | |
| 1.08 | 3.87 | 0.65 | 2.33 | 18.41 | 56.66 | -33.54 | 67.26 | 0.5707 | -434.1 | -200.0 | |
| 0.00 | 1.53 | 0.00 | 0.91 | 16.78 | 56.97 | -33.24 | 69.94 | 0.5609 | 769.0 | 563.7 | |
| 5.67 | -41.00 | 3.45 | -41.00 | 19.88 | 56.24 | -33.97 | 64.98 | 0.5820 | 928.2 | 999999 | |
| 1.62 | 5.22 | 0.97 | 3.12 | 16.43 | 56.77 | -33.44 | 70.63 | 0.5624 | 766.3 | 648.8 | |
| 0.00 | 1.62 | 0.00 | 0.98 | 19.40 | 56.09 | -34.12 | 65.85 | 0.5820 | 786.0 | 632.8 | |
| 0.00 | 3.51 | 0.00 | 2.14 | 19.82 | 55.79 | -34.42 | 65.29 | 0.5875 | 885.0 | 742.3 | |
| 0.00 | 1.53 | 0.00 | 0.94 | 20.04 | 55.73 | -34.47 | 64.97 | 0.5891 | 737.0 | 604.8 | |
| 0.00 | 0.99 | 0.00 | 0.60 | 19.45 | 55.76 | -34.44 | 65.93 | 0.5863 | 672.0 | 658.4 | |
| 0.00 | 1.35 | 0.00 | 0.83 | 19.60 | 55.65 | -34.56 | 65.73 | 0.5884 | 763.0 | 684.5 | |
| 0.00 | 2.16 | 0.00 | 1.32 | 19.90 | 55.46 | -34.75 | 65.33 | 0.5921 | 674.0 | 553.8 | |
| 0.00 | 0.72 | 0.00 | 0.44 | 20.82 | 55.14 | -35.07 | 63.98 | 0.5998 | 579.0 | 491.5 | |
| 34.01 | 191.65 | 20.29 | 114.45 | 14.10 | 56.55 | -33.66 | 74.79 | 0.5592 | 1088.1 | 333.4 | |
| 0.00 | 1.17 | 0.00 | 0.72 | 18.73 | 55.39 | -34.82 | 67.26 | 0.5885 | 626.0 | 550.2 | |
| 0.00 | 2.16 | 0.00 | 1.31 | 16.95 | 55.75 | -34.46 | 70.10 | 0.5778 | 688.0 | 528.7 | |
| 1.35 | -53.00 | 0.81 | -53.00 | 14.56 | 56.02 | -34.19 | 74.13 | 0.5676 | 466.8 | 999999 | |
| 0.00 | 1.35 | 0.00 | 0.83 | 18.65 | 54.58 | -35.63 | 67.72 | 0.5986 | 427.0 | 336.9 | |
| 0.00 | 1.35 | 0.00 | 0.85 | 16.83 | 52.19 | -38.02 | 71.43 | 0.6242 | 680.0 | 446.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
