SDO HMI 2011-08-20 14:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.83 | 122.88 | 15.08 | 74.84 | -21.14 | 54.89 | -22.10 | 142.90 | 0.5817 | 122.0 | 100.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-20 14:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.25 | 0.00 | 1.29 | -18.86 | 60.69 | -16.31 | 148.26 | 0.5070 | 809.0 | 591.8 | |
| 0.00 | 1.08 | 0.00 | 0.62 | -19.05 | 60.30 | -16.69 | 147.86 | 0.5123 | 388.0 | 421.9 | |
| 0.00 | 1.17 | 0.00 | 0.68 | -19.19 | 60.12 | -16.88 | 147.73 | 0.5156 | 634.0 | 495.5 | |
| 0.00 | 2.25 | 0.00 | 1.29 | -17.07 | 58.60 | -18.40 | 142.96 | 0.5028 | 868.0 | 644.1 | |
| 0.00 | 1.53 | 0.00 | 0.89 | -17.65 | 57.56 | -19.43 | 142.17 | 0.5190 | 499.0 | 535.4 | |
| 0.00 | 1.44 | 0.00 | 0.83 | -17.19 | 57.37 | -19.62 | 141.33 | 0.5154 | 848.0 | 663.8 | |
| 16.01 | 55.94 | 9.61 | 33.58 | -21.23 | 56.79 | -20.20 | 145.25 | 0.5668 | 1066.7 | 439.7 | |
| 0.00 | 1.08 | 0.00 | 0.63 | -17.95 | 56.74 | -20.25 | 141.41 | 0.5299 | 601.0 | 549.8 | |
| 2.79 | 3.78 | 1.69 | 2.29 | -21.70 | 56.17 | -20.83 | 144.95 | 0.5773 | 623.6 | 464.5 | |
| 0.00 | 1.17 | 0.00 | 0.69 | -18.63 | 56.52 | -20.47 | 141.93 | 0.5395 | 657.0 | 515.2 | |
| 0.00 | 0.90 | 0.00 | 0.54 | -21.50 | 56.06 | -20.94 | 144.59 | 0.5760 | 649.0 | 531.9 | |
| 0.00 | 1.26 | 0.00 | 0.74 | -18.21 | 55.52 | -21.48 | 140.08 | 0.5441 | 648.0 | 543.6 | |
| 2.43 | 9.71 | 1.48 | 5.91 | -20.44 | 54.01 | -22.98 | 140.87 | 0.5819 | 728.9 | 351.6 | |
| 0.00 | 8.36 | 0.00 | 5.19 | -21.52 | 52.87 | -24.12 | 140.77 | 0.6033 | -842.0 | -680.5 | |
| 0.00 | 1.08 | 0.00 | 0.67 | -21.07 | 52.95 | -24.04 | 140.35 | 0.5979 | -759.0 | -606.4 | |
| 0.00 | 4.50 | 0.00 | 2.75 | -20.18 | 53.07 | -23.93 | 139.45 | 0.5877 | -311.0 | -458.5 | |
| 0.00 | 0.99 | 0.00 | 0.60 | -19.99 | 52.81 | -24.18 | 138.93 | 0.5881 | -747.0 | -625.1 | |
| 0.00 | 1.35 | 0.00 | 0.84 | -21.84 | 52.13 | -24.86 | 140.29 | 0.6130 | -790.0 | -630.9 | |
| 0.00 | 1.44 | 0.00 | 0.89 | -20.53 | 52.30 | -24.70 | 138.97 | 0.5983 | -804.0 | -708.9 | |
| 0.00 | 0.99 | 0.00 | 0.61 | -19.91 | 52.37 | -24.63 | 138.33 | 0.5914 | -583.0 | -448.2 | |
| 0.00 | 1.89 | 0.00 | 1.23 | -24.61 | 51.31 | -25.68 | 142.38 | 0.6477 | 724.0 | 591.8 | |
| 1.71 | 2.16 | 1.06 | 1.34 | -20.89 | 51.91 | -25.08 | 138.96 | 0.6054 | -713.2 | -616.2 | |
| 0.00 | 1.08 | 0.00 | 0.66 | -20.03 | 52.03 | -24.97 | 138.08 | 0.5958 | -842.0 | -732.2 | |
| 0.00 | 0.45 | 0.00 | 0.28 | -22.07 | 51.65 | -25.34 | 140.02 | 0.6195 | -500.0 | -463.0 | |
| 0.00 | 0.63 | 0.00 | 0.40 | -21.88 | 51.26 | -25.74 | 139.38 | 0.6212 | -285.0 | -316.0 | |
| 0.00 | 0.90 | 0.00 | 0.56 | -20.50 | 51.48 | -25.51 | 138.03 | 0.6056 | -630.0 | -424.8 | |
| 0.00 | 0.99 | 0.00 | 0.65 | -25.04 | 50.51 | -26.49 | 141.99 | 0.6585 | -452.0 | -471.6 | |
| 0.00 | 1.71 | 0.00 | 1.14 | -25.68 | 49.98 | -27.02 | 142.11 | 0.6689 | -642.0 | -557.0 | |
| 0.00 | 1.53 | 0.00 | 0.97 | -21.48 | 50.46 | -26.53 | 138.08 | 0.6244 | -790.0 | -700.1 | |
| 1.89 | 2.07 | 1.24 | 1.36 | -24.48 | 49.77 | -27.22 | 140.67 | 0.6591 | -758.3 | -603.0 | |
| 0.00 | 1.26 | 0.00 | 0.82 | -22.83 | 49.22 | -27.77 | 138.33 | 0.6483 | -767.0 | -668.1 | |
| 0.00 | 0.90 | 0.00 | 0.60 | -24.69 | 48.74 | -28.25 | 139.87 | 0.6695 | -710.0 | -570.6 | |
| 0.00 | 0.63 | 0.00 | 0.41 | -23.48 | 48.96 | -28.03 | 138.78 | 0.6565 | -681.0 | -610.1 | |
| 0.00 | 0.90 | 0.00 | 0.59 | -22.93 | 48.79 | -28.21 | 138.01 | 0.6530 | -582.0 | -470.4 | |
| 0.00 | 0.90 | 0.00 | 0.60 | -24.18 | 48.34 | -28.66 | 138.94 | 0.6683 | -567.0 | -457.1 | |
| 0.00 | 1.62 | 0.00 | 1.07 | -23.97 | 48.27 | -28.72 | 138.66 | 0.6670 | -595.0 | -466.2 | |
| 0.00 | 0.99 | 0.00 | 0.63 | -18.70 | 47.63 | -29.36 | 131.91 | 0.6263 | 609.0 | 490.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
