SDO HMI 2011-08-21 13:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 74.67 | 293.88 | 42.71 | 168.13 | -21.14 | 53.53 | -10.80 | 159.64 | 0.5025 | -152.4 | -74.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-21 13:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.98 | 0.00 | 1.09 | -18.51 | 62.29 | -2.04 | 175.49 | 0.4320 | 778.0 | 570.0 | |
| 0.00 | 0.72 | 0.00 | 0.39 | -17.07 | 59.00 | -5.33 | 167.64 | 0.4169 | 825.0 | 659.5 | |
| 0.00 | 1.26 | 0.00 | 0.69 | -17.34 | 58.45 | -5.88 | 166.57 | 0.4231 | 797.0 | 635.4 | |
| 0.00 | 1.44 | 0.00 | 0.79 | -17.45 | 57.45 | -6.88 | 164.48 | 0.4288 | 869.0 | 689.2 | |
| 0.99 | 74.27 | 0.56 | 42.26 | -21.81 | 56.70 | -7.63 | 165.57 | 0.4968 | 578.4 | 433.1 | |
| 13.22 | -5.00 | 7.52 | -5.00 | -21.47 | 56.45 | -7.88 | 164.94 | 0.4928 | 1130.3 | 999999 | |
| 0.99 | 2.16 | 0.57 | 1.23 | -21.89 | 55.74 | -8.59 | 163.90 | 0.5019 | 562.7 | 538.9 | |
| 0.00 | 0.99 | 0.00 | 0.55 | -19.12 | 55.89 | -8.44 | 162.41 | 0.4607 | 658.0 | 465.5 | |
| 1.80 | 16.54 | 1.02 | 9.38 | -20.47 | 54.87 | -9.46 | 161.42 | 0.4852 | 847.3 | 786.0 | |
| 5.49 | -9.00 | 3.11 | -9.00 | -20.75 | 54.65 | -9.68 | 161.22 | 0.4902 | 823.9 | 999999 | |
| 4.14 | 4.50 | 2.36 | 2.56 | -21.06 | 54.50 | -9.83 | 161.17 | 0.4955 | 687.7 | 298.5 | |
| 0.00 | 1.17 | 0.00 | 0.67 | -21.10 | 54.20 | -10.13 | 160.67 | 0.4975 | 618.0 | 523.3 | |
| 0.00 | 0.54 | 0.00 | 0.31 | -21.59 | 53.97 | -10.36 | 160.61 | 0.5056 | 517.0 | 543.5 | |
| 0.00 | 0.90 | 0.00 | 0.51 | -21.17 | 53.97 | -10.36 | 160.31 | 0.4998 | 436.0 | 411.3 | |
| 2.43 | 3.78 | 1.39 | 2.16 | -21.45 | 53.75 | -10.58 | 160.13 | 0.5048 | 625.0 | 389.5 | |
| 0.00 | 1.35 | 0.00 | 0.77 | -20.53 | 53.65 | -10.68 | 159.27 | 0.4923 | 622.0 | 412.5 | |
| 5.13 | 152.86 | 2.93 | 87.74 | -20.98 | 53.35 | -10.98 | 159.09 | 0.5003 | -832.6 | -453.0 | |
| 2.97 | 13.67 | 1.69 | 7.78 | -20.40 | 53.36 | -10.97 | 158.66 | 0.4920 | 755.7 | 157.7 | |
| 1.80 | -17.00 | 1.03 | -17.00 | -21.37 | 52.92 | -11.41 | 158.66 | 0.5080 | -793.4 | 999999 | |
| 0.00 | 1.71 | 0.00 | 0.97 | -19.66 | 52.99 | -11.34 | 157.39 | 0.4838 | -426.0 | -429.3 | |
| 4.41 | -17.00 | 2.54 | -17.00 | -21.35 | 52.26 | -12.07 | 157.53 | 0.5115 | -953.6 | 999999 | |
| 0.00 | 1.62 | 0.00 | 0.94 | -22.05 | 51.90 | -12.43 | 157.49 | 0.5232 | -640.0 | -493.1 | |
| 21.04 | -17.00 | 12.08 | -17.00 | -20.92 | 51.93 | -12.40 | 156.62 | 0.5074 | -1166.1 | 999999 | |
| 0.00 | 1.71 | 0.00 | 1.00 | -22.37 | 51.77 | -12.56 | 157.53 | 0.5282 | -708.0 | -489.5 | |
| 5.13 | -17.00 | 2.95 | -17.00 | -21.17 | 51.58 | -12.75 | 156.24 | 0.5129 | -954.4 | 999999 | |
| 5.13 | -17.00 | 2.96 | -17.00 | -21.14 | 51.28 | -13.05 | 155.73 | 0.5144 | -837.7 | 999999 | |
| 0.00 | 0.99 | 0.00 | 0.57 | -21.45 | 51.15 | -13.18 | 155.78 | 0.5194 | -571.0 | -428.7 | |
| 0.00 | 0.81 | 0.00 | 0.47 | -21.91 | 50.84 | -13.49 | 155.67 | 0.5275 | -767.0 | -627.3 | |
| 0.00 | 1.53 | 0.00 | 0.89 | -22.12 | 50.75 | -13.58 | 155.71 | 0.5308 | -643.0 | -528.1 | |
| 0.00 | 1.26 | 0.00 | 0.76 | -24.90 | 48.69 | -15.64 | 154.93 | 0.5793 | -587.0 | -513.1 | |
| 0.00 | 1.26 | 0.00 | 0.74 | -22.49 | 48.98 | -15.35 | 153.32 | 0.5468 | -591.0 | -439.4 | |
| 0.00 | 1.17 | 0.00 | 0.69 | -22.95 | 48.89 | -15.43 | 153.60 | 0.5532 | -634.0 | -412.5 | |
| 0.00 | 1.71 | 0.00 | 1.03 | -24.48 | 48.53 | -15.80 | 154.37 | 0.5749 | -789.0 | -622.1 | |
| 0.00 | 1.98 | 0.00 | 1.19 | -24.06 | 48.24 | -16.09 | 153.61 | 0.5715 | -597.0 | -394.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
