SDO HMI 2011-08-21 21:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 81.62 | 306.87 | 46.04 | 173.42 | -20.99 | 53.70 | -6.20 | 167.93 | 0.4812 | 168.2 | -140.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-21 21:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.71 | 0.00 | 0.92 | -15.77 | 60.96 | 1.05 | 182.63 | 0.3878 | 679.0 | 550.4 | |
| 0.00 | 1.80 | 0.00 | 1.00 | -19.68 | 60.50 | 0.59 | 181.25 | 0.4497 | 744.0 | 457.8 | |
| 0.00 | 1.62 | 0.00 | 0.89 | -18.63 | 58.57 | -1.33 | 177.08 | 0.4336 | 736.0 | 570.7 | |
| 0.00 | 1.17 | 0.00 | 0.64 | -18.43 | 58.48 | -1.42 | 176.85 | 0.4305 | 651.0 | 547.1 | |
| 0.00 | 1.08 | 0.00 | 0.59 | -18.53 | 58.32 | -1.59 | 176.51 | 0.4323 | 673.0 | 601.8 | |
| 0.00 | 2.34 | 0.00 | 1.27 | -17.26 | 58.14 | -1.76 | 175.89 | 0.4124 | 760.0 | 608.5 | |
| 0.00 | 1.08 | 0.00 | 0.59 | -17.97 | 56.89 | -3.02 | 173.22 | 0.4254 | 940.0 | 808.2 | |
| 16.90 | 60.66 | 9.53 | 34.24 | -21.47 | 56.36 | -3.54 | 173.11 | 0.4807 | 1166.8 | 476.6 | |
| 1.80 | 2.79 | 1.02 | 1.58 | -21.96 | 55.66 | -4.24 | 171.91 | 0.4895 | 614.5 | 518.9 | |
| 12.04 | 13.57 | 6.76 | 7.62 | -20.73 | 54.82 | -5.08 | 169.87 | 0.4729 | 967.5 | 665.2 | |
| 2.70 | 7.55 | 1.52 | 4.26 | -21.11 | 54.58 | -5.32 | 169.55 | 0.4793 | 731.1 | 527.4 | |
| 4.22 | 72.89 | 2.37 | 41.08 | -20.56 | 54.34 | -5.57 | 168.86 | 0.4717 | 971.8 | -12.3 | |
| 1.26 | -12.00 | 0.71 | -12.00 | -20.74 | 54.23 | -5.67 | 168.73 | 0.4746 | 722.4 | 999999 | |
| 6.74 | -12.00 | 3.78 | -12.00 | -20.50 | 53.88 | -6.02 | 167.95 | 0.4722 | 846.4 | 999999 | |
| 1.35 | 1.89 | 0.76 | 1.07 | -21.36 | 53.85 | -6.05 | 168.27 | 0.4852 | 711.2 | 532.5 | |
| 0.00 | 2.97 | 0.00 | 1.68 | -21.67 | 53.77 | -6.13 | 168.27 | 0.4901 | 712.0 | 619.0 | |
| 2.07 | -12.00 | 1.16 | -12.00 | -20.85 | 53.64 | -6.26 | 167.64 | 0.4782 | -444.5 | 999999 | |
| 0.81 | -12.00 | 0.46 | -12.00 | -20.75 | 53.55 | -6.35 | 167.42 | 0.4770 | 373.1 | 999999 | |
| 2.52 | -12.00 | 1.41 | -12.00 | -20.47 | 53.33 | -6.57 | 166.86 | 0.4736 | 624.2 | 999999 | |
| 0.00 | 3.42 | 0.00 | 1.91 | -19.86 | 53.16 | -6.74 | 166.21 | 0.4651 | -854.0 | -723.9 | |
| 0.00 | 0.90 | 0.00 | 0.51 | -20.62 | 53.07 | -6.84 | 166.42 | 0.4767 | -309.0 | -330.6 | |
| 1.17 | 6.29 | 0.66 | 3.54 | -20.48 | 52.84 | -7.06 | 165.93 | 0.4755 | 533.7 | 145.0 | |
| 3.68 | 95.53 | 2.09 | 54.20 | -21.07 | 52.42 | -7.48 | 165.46 | 0.4858 | -921.2 | -685.4 | |
| 1.89 | 16.36 | 1.07 | 9.30 | -21.49 | 52.20 | -7.70 | 165.29 | 0.4928 | -877.8 | -554.5 | |
| 0.00 | 2.16 | 0.00 | 1.23 | -21.67 | 51.83 | -8.07 | 164.71 | 0.4969 | -517.0 | -518.0 | |
| 20.13 | -23.00 | 11.41 | -23.00 | -21.01 | 51.83 | -8.07 | 164.34 | 0.4873 | -1113.8 | 999999 | |
| 2.34 | -23.00 | 1.33 | -23.00 | -21.58 | 50.95 | -8.96 | 163.08 | 0.4993 | -1002.0 | 999999 | |
| 0.00 | 1.26 | 0.00 | 0.72 | -21.80 | 50.50 | -9.40 | 162.43 | 0.5044 | -798.0 | -660.5 | |
| 0.00 | 2.16 | 0.00 | 1.24 | -21.63 | 50.15 | -9.75 | 161.71 | 0.5037 | -642.0 | -467.1 | |
| 0.00 | 1.17 | 0.00 | 0.69 | -24.39 | 49.13 | -10.77 | 161.80 | 0.5471 | -778.0 | -595.8 | |
| 0.00 | 2.16 | 0.00 | 1.26 | -23.33 | 49.05 | -10.85 | 160.99 | 0.5328 | -695.0 | -659.0 | |
| 0.00 | 1.26 | 0.00 | 0.75 | -24.79 | 48.48 | -11.42 | 161.05 | 0.5556 | -393.0 | -393.6 | |
| 0.00 | 1.08 | 0.00 | 0.64 | -23.99 | 48.22 | -11.68 | 160.11 | 0.5459 | -448.0 | -431.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
