SDO HMI 2011-08-22 02:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.93 | 46.04 | 19.82 | 40.71 | 18.87 | 0.97 | -56.18 | 71.82 | 0.8278 | -609.8 | -212.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-22 02:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.63 | 0.00 | 0.51 | 16.47 | 4.73 | -52.42 | 74.49 | 0.7909 | -286.0 | -363.9 | |
| 9.89 | 18.88 | 8.44 | 16.10 | 18.91 | 2.32 | -54.83 | 71.69 | 0.8168 | -748.5 | -604.0 | |
| 13.04 | 25.09 | 11.38 | 21.98 | 18.85 | 1.39 | -55.76 | 71.85 | 0.8255 | -610.8 | -6.3 | |
| 0.00 | 1.44 | 0.00 | 2.12 | 19.38 | 345.54 | -71.61 | 71.85 | 0.9435 | 248.0 | 207.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
